The AMD Ryzen Z2 A is built on a 6 nm semiconductor process and operates within a 15W Thermal Design Power (TDP) envelope, reflecting a design oriented toward efficiency. It includes integrated graphics and fully supports 64-bit operation. Connectivity is handled through PCIe version 3, providing the interface support expected for its platform class.
The processor runs four cores at a base speed of 2.8 GHz, supported by 8 threads for handling concurrent workloads, and can reach a turbo clock speed of 3.8 GHz under load. The multiplier is locked, and the chip does not use big.LITTLE heterogeneous core architecture. Cache is organized across three levels: 256 KB of L1, 2 MB of L2 at 0.5 MB per core, and 4 MB of L3 cache at 1 MB per core, providing a structured memory hierarchy to support the processor's throughput.
The integrated graphics unit reaches a GPU turbo frequency of 1800 MHz and is backed by 512 shading units, forming the core of its on-chip rendering capability.
The AMD Ryzen Z2 A supports DDR5 memory, with a maximum RAM speed of 6400 MHz, placing it on a current-generation memory standard that allows for substantial memory bandwidth headroom within its platform.
The processor supports multithreading and includes the NX bit for hardware-level memory protection. Its instruction set support spans MMX, F16C, FMA3, AES, AVX, AVX2, SSE 4.1, and SSE 4.2, covering a broad range of computational and security-oriented extensions that enable efficient handling of floating-point, vector, and encryption workloads.
