Asus TUF Gaming GeForce RTX 5060

Name: Asus TUF Gaming GeForce RTX 5060
Brand: Asus
SKU: 4247

Manufacturer: Asus

The Asus TUF Gaming GeForce RTX 5060 is a mid-range graphics card from Asus that sits within the company's TUF Gaming lineup, designed around Nvidia's Blackwell architecture. Built on a 5 nm semiconductor process and packing 21,900 million transistors, the card delivers 19.18 TFLOPS of floating-point performance alongside a boost clock of 2497 MHz. It also features RGB lighting and supports up to four displays simultaneously, making it a versatile option for a variety of desktop setups.

On the memory side, the RTX 5060 uses 8GB of GDDR7 VRAM across a 128-bit bus, reaching an effective speed of 28,000 MHz and a maximum bandwidth of 448 GB/s. The card draws 145W TDP and connects via PCIe 5.0, with display output handled through one HDMI 2.1b port and three DisplayPort outputs. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, ray tracing, DLSS, Intel Resizable BAR, and ECC memory, rounding out a specification set oriented toward current-generation rendering and compute workloads.

Pros

Supports ray tracing and DLSS, enabling access to current-generation rendering techniques
GDDR7 memory with an effective speed of 28,000 MHz and 448 GB/s bandwidth provides substantial memory throughput for the VRAM capacity
Four display outputs — one HDMI 2.1b and three DisplayPort — allow flexible multi-monitor configurations up to four screens
Built on a 5 nm process with 21,900 million transistors, reflecting a modern silicon design
ECC memory support adds a layer of data integrity useful for compute-oriented workloads
Intel Resizable BAR support allows the CPU broader access to GPU memory resources

Cons

The 128-bit memory bus width is relatively narrow for an 8GB GDDR7 configuration, which may limit sustained throughput in memory-intensive scenarios
No USB-C display output is available, limiting compatibility with monitors or devices that rely solely on that connector
Water cooling is not supported, leaving thermal management entirely dependent on the air-cooling solution
8GB of VRAM may prove limiting for workloads or rendering tasks that demand larger frame buffers

Who is this for?

This card is well-suited to desktop PC builders looking to run current-generation games with access to ray tracing and DLSS, as both features are supported out of the box. The four display outputs — including three DisplayPort connections and one HDMI 2.1b — make it a practical fit for users who need a multi-monitor setup of up to four screens. Its ECC memory support and DPFP capability also make it a reasonable option for users who occasionally run compute or precision-sensitive workloads alongside standard graphics tasks, while the 145W TDP keeps power draw at a manageable level for mid-range system builds.

Who is this NOT for?

Users working with memory-intensive rendering, AI, or simulation workloads that demand large VRAM allocations may find 8GB limiting as scene complexity or dataset sizes grow. The 128-bit memory bus, while partially offset by GDDR7 speeds, means the card is less suited to workflows that consistently push high-bandwidth, large-frame-buffer operations. Additionally, users who require a USB-C display connection — whether for specific monitors or compact display devices — will find no such port available, making this card a poor match for setups built around USB-C video output.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2497 MHz
pixel rate	119.9 GPixel/s
floating-point performance	19.18 TFLOPS
texture rate	299.6 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The RTX 5060 operates at a base GPU clock of 2280 MHz, boosting up to 2497 MHz under load, while its 3840 shading units, 120 texture mapping units, and 48 render output units underpin a texture rate of 299.6 GTexels/s and a pixel rate of 119.9 GPixel/s. Floating-point performance reaches 19.18 TFLOPS, supported by a GPU memory speed of 1750 MHz. The card also includes Double Precision Floating Point (DPFP) support, extending its usefulness beyond standard rendering tasks to workloads that require higher numerical precision.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The RTX 5060 is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus, with an effective memory speed of 28,000 MHz and a maximum memory bandwidth of 448 GB/s. ECC memory support is also included, which helps detect and correct memory errors — a useful capability for tasks that demand data integrity alongside standard graphics workloads.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The RTX 5060 supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, while XeSS (XMX) is not present. The card handles up to four displays simultaneously via its multi-display technology, and stereoscopic 3D is also supported. Intel Resizable BAR is available to help the CPU access GPU memory more efficiently, and the card does not include LHR. RGB lighting is built in, rounding out the feature set on the physical side.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The RTX 5060 offers a total of four video outputs: one HDMI 2.1b port and three DisplayPort outputs. There are no USB-C, DVI, or mini DisplayPort connections on this card, keeping the output configuration straightforward and focused on the two most widely used modern display interfaces.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	302 mm
height	133.5 mm

The RTX 5060 is built on the Blackwell architecture, manufactured using a 5 nm process and integrating 21,900 million transistors. It connects via PCIe 5.0 and carries a TDP of 145W, with cooling handled by air rather than a water-cooling solution. The card measures 302 mm in width and 133.5 mm in height, giving a clear picture of the physical space it requires within a system.

Final Verdict

The Asus TUF Gaming GeForce RTX 5060 is a well-specified graphics card that brings Nvidia's Blackwell architecture to desktop builds with a modern feature set, including ray tracing, DLSS, and a GDDR7 memory configuration delivering up to 448 GB/s of bandwidth. Its support for up to four simultaneous displays, Intel Resizable BAR, ECC memory, and DirectX 12 Ultimate positions it as a capable option for users seeking current-generation rendering capabilities within a 145W power envelope. That said, the 8GB VRAM ceiling and 128-bit bus width are practical constraints that become relevant as workloads grow more demanding. For users whose needs fall within those boundaries, the RTX 5060 represents a technically coherent and fully featured option from Asus's TUF Gaming line.
