Geekom A6

Name: Geekom A6
Brand: Geekom
SKU: 32420

Manufacturer: Geekom

The Geekom A6 is a compact mini PC built around the Mini-ITX form factor, weighing just 900g and measuring 112.4 × 112.4 × 37mm. Despite its modest footprint, it houses 64GB of DDR5 RAM running at 4800MHz, alongside a 1TB NVMe SSD, making it a well-specified machine for its size class.

The processor runs eight cores at a base clock of 3.2GHz with a turbo ceiling of 4.7GHz, supported by 16 threads and a 16MB L3 cache, with a 45W TDP. Graphics are handled by the integrated Radeon 680M, based on the RDNA 2.0 architecture at 6nm, delivering 3.379 TFLOPS and support for up to four displays simultaneously. Connectivity is broad, including Wi-Fi 6E, Bluetooth 5.2, two HDMI 2.0 ports, one USB 4 40Gbps port, one Thunderbolt 4 port, four USB 3.2 Gen 2 Type-A ports, and a single 2.5GbE RJ45 port.

Pros

64GB of DDR5 RAM running at 4800MHz gives the system substantial memory headroom for multitasking and memory-intensive workloads
Support for up to four simultaneous displays makes it well-suited for multi-monitor desktop setups
The USB port selection is notably broad, including a Thunderbolt 4 port, a USB 4 40Gbps port, and four USB 3.2 Gen 2 Type-A ports
Wi-Fi 6E support ensures fast and low-latency wireless connectivity on compatible networks
The 1TB NVMe SSD provides both generous storage capacity and fast data access
ECC memory support adds a layer of data integrity that is uncommon in compact desktop systems

Cons

The multiplier is locked, leaving no headroom for CPU frequency adjustments
DLSS is not supported by the integrated GPU, limiting upscaling options for graphically demanding tasks
There are no DisplayPort outputs, which may require adapters for monitors that lack HDMI inputs
The single USB 2.0 port is a legacy inclusion that offers significantly lower transfer speeds than the other available ports
Air or water cooling is not supported, limiting thermal management options to the built-in solution

Who is this for?

The Geekom A6 is well-matched for users who need a capable desktop system in a minimal footprint, particularly those building compact multi-monitor workstations — the integrated GPU supports up to four simultaneous displays, which suits productivity-focused setups. With 64GB of DDR5 RAM and a 1TB NVMe SSD, it handles memory-intensive workflows such as data processing, software development, or content management without storage or memory becoming a bottleneck. The broad connectivity suite, including Thunderbolt 4, USB 4 40Gbps, and Wi-Fi 6E, also makes it a practical fit for users who regularly work with high-speed peripherals or external storage devices.

Who is this NOT for?

Users looking for a system capable of handling demanding GPU workloads or modern gaming at higher settings will find the integrated Radeon 680M limiting, as it lacks DLSS support and does not offer the raw graphical output of a discrete card. The locked CPU multiplier makes this a poor fit for anyone interested in overclocking or manual frequency tuning. Similarly, users who rely on DisplayPort monitors will face compatibility constraints, as there are no DisplayPort outputs on the unit, and those requiring S/PDIF audio output for specific home theatre or professional audio setups will find that connectivity absent as well.

General info:

SSD storage capacity	1000GB
form factor	Mini-ITX
Is an NVMe SSD	✓
thickness	112.4 mm
height	37 mm
width	112.4 mm
weight	900 g
volume	467.44912 cm³

The Geekom A6 follows the Mini-ITX form factor, measuring 112.4 × 112.4 × 37mm with a total volume of roughly 467.45cm³ and a weight of 900g, making it a notably compact unit. Storage is provided by a 1TB NVMe SSD, offering both solid capacity and fast read/write performance through the NVMe interface. These physical and storage characteristics together define a machine designed to occupy minimal desk space without sacrificing on-board storage headroom.

CPU:

Thermal Design Power (TDP)	45W
CPU speed	8 x 3.2 GHz
turbo clock speed	4.7GHz
CPU threads	16 threads
Has integrated graphics	✓
uses multithreading	✓
L3 cache	16 MB
L2 cache	4 MB
L1 cache	512 KB
L2 core	0.5 MB/core
L3 core	2 MB/core
clock multiplier	32
Has an unlocked multiplier	✕
Supports 64-bit	✓
CPU temperature	95 °C

The CPU in the Geekom A6 features 8 cores running at 3.2GHz with a turbo boost up to 4.7GHz, supported by 16 threads through multithreading for handling parallel workloads. It carries a 45W TDP and a maximum operating temperature of 95°C, with a clock multiplier of 32 that remains locked. Cache memory is organized across three levels — 512KB of L1, 4MB of L2 at 0.5MB per core, and 16MB of L3 at 2MB per core — providing a reasonable hierarchy for data access. The processor supports 64-bit computing and includes integrated graphics, rounding out a well-specified CPU configuration for a compact system.

Graphics card:

floating-point performance	3.379 TFLOPS
GPU clock speed	2000 MHz
GPU turbo	2200 MHz
texture rate	105.6 GTexels/s
pixel rate	70.4 GPixel/s
supports ray tracing	✓
supports DLSS	✕
PCI Express (PCIe) version	4
texture mapping units (TMUs)	48
shading units	768
render output units (ROPs)	32
DirectX version	DirectX 12
OpenGL version	4.6
OpenCL version	2.2
semiconductor size	6 nm
supported displays	4
has LHR	✕
Supports multi-display technology	✓
Has Double Precision Floating Point (DPFP)	✓
number of transistors	13100 million

The integrated GPU delivers 3.379 TFLOPS of floating-point performance, clocking at 2000MHz with a turbo ceiling of 2200MHz, and is built on a 6nm process housing 13,100 million transistors. It features 768 shading units, 48 texture mapping units producing a texture rate of 105.6 GTexels/s, and 32 ROPs yielding a pixel rate of 70.4 GPixel/s. The GPU supports ray tracing, DirectX 12, OpenGL 4.6, OpenCL 2.2, and double precision floating point, while DLSS is not supported. It connects via PCIe 4.0, does not use LHR, and can drive up to four displays simultaneously through its multi-display support.

Memory:

RAM	64GB
RAM speed	4800 MHz
DDR memory version	5

The Geekom A6 is equipped with 64GB of DDR5 RAM running at 4800MHz, placing it at the upper end of what compact systems typically offer in terms of both capacity and memory generation.

Connectivity:

Wi-Fi version	Wi-Fi 6E (802.11ax), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
supports Wi-Fi	✓
Has Bluetooth	✓
Bluetooth version	5.2
USB 2.0 ports	1
USB 3.2 Gen 2 ports (USB-A)	4
USB 3.2 Gen 1 ports (USB-A)	0
USB 3.2 Gen 2 ports (USB-C)	1
USB 4 40Gbps ports	1
USB 4 20Gbps ports	0
USB 3.2 Gen 2x2 ports	0
USB 3.2 Gen 1 ports (USB-C)	0
Thunderbolt 4 ports	1
Thunderbolt 3 ports	0
DisplayPort outputs	0
HDMI version	HDMI 2.0
HDMI ports	2
RJ45 ports	1
has an AUX input	✓
has a socket for a 3.5 mm audio jack	✓
has a VGA connector	✕
Has S/PDIF Out port	✕

Wireless connectivity covers Wi-Fi 6E (802.11ax) along with backward-compatible Wi-Fi 6, 5, and 4 standards, paired with Bluetooth 5.2 for peripheral connections. On the wired side, there is one RJ45 port for network access, two HDMI 2.0 outputs for display, and no DisplayPort or VGA outputs. The USB port selection includes four USB 3.2 Gen 2 Type-A ports, one USB 3.2 Gen 2 Type-C port, one USB 4 40Gbps port, one Thunderbolt 4 port, and one legacy USB 2.0 port; there are no USB 3.2 Gen 1, Gen 2x2, or Thunderbolt 3 ports. Audio connectivity is handled through a 3.5mm headset jack and an AUX input, while S/PDIF output is absent.

Benchmarks:

PassMark result	23052
PassMark result (single)	3210
Geekbench 6 result (multi)	8905
Geekbench 6 result (single)	1851
Cinebench R20 (multi) result	5074
Cinebench R20 (single) result	587

In benchmark testing, the Geekom A6 records a PassMark multi-core score of 23,052 alongside a single-core result of 3,210, reflecting its multi-threaded capabilities relative to single-thread workloads. Geekbench 6 returns a multi-core result of 8,905 and a single-core score of 1,851, while Cinebench R20 produces a multi-core result of 5,074 and a single-core score of 587, rounding out a consistent picture of the system's measured CPU performance across all three test suites.

Miscellaneous:

maximum memory amount	64GB
has an external memory slot	✓
GPU name	Radeon 680M
Supports ECC memory	✓
Has NX bit	✓
GPU execution units	12
memory channels	2
Type	Laptop
instruction sets	SSE 4.2, SSE 4.1, AVX, AES, FMA3, F16C, MMX
RAM speed (max)	6400 MHz
GPU architecture	RDNA 2.0
Has air-water cooling	✕
Supports 3D	✓
has XeSS (XMX)	✕
Uses flash storage	✓

The system uses a laptop-class CPU paired with a Radeon 680M GPU built on the RDNA 2.0 architecture with 12 execution units, and stores data on flash-based storage. Memory tops out at 64GB across two channels, with a maximum supported RAM speed of 6400MHz, and the system is compatible with ECC memory. An external memory slot is present for additional storage expansion. The CPU includes the NX bit for hardware-level security and supports a range of instruction sets including SSE 4.1, SSE 4.2, AVX, AES, FMA3, F16C, and MMX. Stereoscopic 3D is supported, while XeSS (XMX) and air-water cooling are not available on this unit.

Final Verdict

The Geekom A6 presents a well-rounded mini PC that punches above its physical dimensions, combining 64GB of DDR5 RAM with a broad, modern connectivity suite — including Thunderbolt 4, USB 4 40Gbps, and Wi-Fi 6E — in a chassis weighing under a kilogram. It is clearly aimed at productivity-oriented users who need a space-efficient desktop capable of driving multiple displays and handling memory-intensive workloads without compromise. Where it falls short, notably in GPU-heavy tasks and the absence of overclocking flexibility, reflects the inherent boundaries of an integrated graphics solution in a compact form factor rather than any oversight in the overall design. For users whose priorities align with its strengths, the A6 makes a coherent and capable case for itself as a serious compact desktop.
