The Gigabyte B760 DS3H AX motherboard features an LGA 1700 CPU socket, compatible with Intel processors, and is built in an ATX form factor. It offers modern connectivity with support for Wi-Fi 6E and Bluetooth 5.3, enabling fast wireless performance. The board also includes HDMI 2.1 output, though it lacks integrated graphics, dual BIOS, and easy overclocking. It has a 3-year warranty, with dimensions of 244 mm in height and 305 mm in width.
The Gigabyte B760 DS3H AX motherboard supports up to 256GB of DDR5 RAM across four memory slots, with a maximum RAM speed of 4800 MHz, which can be overclocked to 7600 MHz. It features dual memory channels to improve performance and does not support ECC memory, ensuring stable and high-speed operations for demanding tasks.
The Gigabyte B760 DS3H AX motherboard offers a variety of connectivity options, including 1 USB 3.2 Gen 2 USB-A port, 4 USB 2.0 ports, and a USB Type-C connector for modern peripherals. It also features an HDMI output, 1 DisplayPort output, and 1 RJ45 port for network connectivity. Additionally, it includes a PS/2 port for legacy devices, but lacks Thunderbolt, VGA, and eSATA ports.
The Gigabyte B760 DS3H AX motherboard offers various connectors for expanding your system. It includes 2 USB 3.2 Gen 1 ports and 4 additional USB 2.0 ports through expansion, as well as 2 M.2 sockets for fast storage. The board also supports up to 6 fan headers, has 4 SATA 3 connectors for traditional storage drives, and includes a TPM connector for enhanced security. It does not feature mSATA or U.2 connectors.
The Gigabyte B760 DS3H AX motherboard includes 1 PCIe 4.0 x16 slot for high-speed graphics cards and 4 PCIe x1 slots for additional expansion cards. It does not feature PCIe 5.0 x16, PCIe 3.0 x16, or PCIe x4 slots, making it suitable for users looking for solid, but not the latest, expansion options.
The Gigabyte B760 DS3H AX motherboard supports 7.1 audio channels for immersive sound, providing high-quality audio output through its 3 dedicated audio connectors. However, it does not include an S/PDIF Out port for digital audio transmission.
The Gigabyte B760 DS3H AX motherboard supports several RAID configurations for flexible storage setups, including RAID 1, RAID 10, RAID 5, and RAID 0. However, it does not support RAID 0+1, limiting certain high-availability configurations.
