Gigabyte GeForce RTX 5050 OC Low Profile

Name: Gigabyte GeForce RTX 5050 OC Low Profile
Brand: Gigabyte
SKU: 27307

Manufacturer: Gigabyte

The Gigabyte GeForce RTX 5050 OC Low Profile is a compact graphics card designed around NVIDIA's Blackwell architecture, fabricated on a 5 nm semiconductor process and housing 16,900 million transistors within a low-profile form factor measuring just 182 mm in width and 69 mm in height. It operates at a base clock of 2317 MHz with a turbo frequency of 2587 MHz, and its restrained 130W thermal design power makes it a practical fit for small form factor systems with limited cooling headroom.

On the memory side, the card carries 8GB of GDDR6 across a 128-bit bus, achieving an effective memory speed of 20,000 MHz and a peak bandwidth of 320 GB/s. Its 2560 shading units, 80 texture mapping units, and 32 render output units contribute to a texture rate of 206.9 GTexels/s and a pixel fill rate of 82.78 GPixel/s, while overall floating-point throughput reaches 13.25 TFLOPS. The card supports DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, and DLSS, and connects via PCIe 5.0. Display output options include two HDMI 2.1b ports and two DisplayPort outputs, supporting up to four simultaneous displays.

Pros

The low-profile form factor at 182 mm wide and 69 mm tall makes it suitable for small form factor and slim desktop builds where full-size cards cannot fit
Support for up to four simultaneous displays across two HDMI 2.1b and two DisplayPort outputs offers flexible multi-monitor setups
DLSS and ray tracing support extend the card's capabilities for compatible rendering workloads
ECC memory support adds a layer of data integrity for tasks where memory accuracy matters
Intel Resizable BAR support allows the CPU to access the full VRAM pool, which can improve frame delivery in supported scenarios
RGB lighting is included, giving users some degree of visual customization

Cons

The 128-bit memory bus width is relatively narrow, which limits memory bandwidth headroom as VRAM demands increase
8GB of VRAM may become a constraint in workloads that require larger memory pools
No USB-C output is available, limiting connectivity options for displays or devices that rely on that interface
Air-water cooling is not supported, restricting thermal management to whatever air-cooling solution is included
At 130W TDP, thermal output may be a consideration in compact cases with limited airflow

Who is this for?

This card is well-suited to users building or upgrading a small form factor or slim desktop system where physical space is a hard constraint, given its low-profile dimensions of 182 mm × 69 mm. Its support for ray tracing, DLSS, and DirectX 12 Ultimate makes it a reasonable fit for users engaged in light to moderate gaming or GPU-accelerated creative workloads who need these features within a compact build. The inclusion of ECC memory support and Double Precision Floating Point also makes it relevant for professionals running compute or data-integrity-sensitive tasks from a space-constrained workstation.

Who is this NOT for?

Users pursuing demanding, high-resolution gaming or professional visualization workloads may find the 8GB VRAM capacity and 128-bit memory bus insufficient as scene complexity and texture requirements grow. The absence of USB-C display output makes it a poor match for users who rely on USB-C or Thunderbolt-connected monitors as part of their display setup. Additionally, those building systems with restricted airflow should note that without air-water cooling support, thermal management depends entirely on the card's built-in air cooling, which may be a concern when the 130W TDP is sustained in thermally constrained enclosures.

Performance:

GPU clock speed	2317 MHz
GPU turbo	2587 MHz
pixel rate	82.78 GPixel/s
floating-point performance	13.25 TFLOPS
texture rate	206.9 GTexels/s
GPU memory speed	1750 MHz
shading units	2560
texture mapping units (TMUs)	80
render output units (ROPs)	32
Has Double Precision Floating Point (DPFP)	✓

The Performance section of this card centers on a base GPU clock of 2317 MHz that boosts up to 2587 MHz, supported by 2560 shading units, 80 texture mapping units, and 32 render output units. Together these contribute to a texture rate of 206.9 GTexels/s and a pixel fill rate of 82.78 GPixel/s, while overall floating-point throughput reaches 13.25 TFLOPS. The GPU memory runs at 1750 MHz, and the card includes support for Double Precision Floating Point (DPFP), broadening its utility beyond standard rendering workloads.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	320 GB/s
VRAM	8GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

This card is equipped with 8GB of GDDR6 VRAM running across a 128-bit memory bus at an effective speed of 20,000 MHz, delivering a maximum memory bandwidth of 320 GB/s. It also supports ECC memory, which enables error detection and correction for workloads where data integrity is a priority.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. Ray tracing and DLSS are both supported, while XeSS (XMX) is not included. It is compatible with Intel Resizable BAR and does not carry LHR restrictions. Multi-display technology is supported across up to four simultaneous displays, stereoscopic 3D is available, and the card features RGB lighting. XeSS (XMX) support is absent from this configuration.

Ports:

has an HDMI output	✓
HDMI ports	2
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of two HDMI 2.1b ports and two DisplayPort outputs, providing four physical connections in total. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	130W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	16900 million
Has air-water cooling	✕
width	182 mm
height	69 mm

Built on the Blackwell architecture and manufactured using a 5 nm process, this card integrates 16,900 million transistors and connects via PCIe 5.0. It carries a thermal design power of 130W and does not include air-water cooling. The physical footprint measures 182 mm in width and 69 mm in height, consistent with a low-profile form factor.

Final Verdict

The Gigabyte GeForce RTX 5050 OC Low Profile is a graphics card that makes a clear case for itself in one specific context: delivering modern GPU features within a low-profile, space-constrained build. Built on the Blackwell architecture with ray tracing, DLSS, DirectX 12 Ultimate, and ECC memory support, it brings a capable feature set to systems where full-size cards simply cannot go. That focus, however, comes with natural trade-offs — the 128-bit bus and 8GB VRAM ceiling mean it is not intended for users pushing demanding, high-resolution workloads. For small form factor system builders or compact workstation users who need a modern, feature-complete GPU within tight physical and thermal boundaries, it represents a well-defined solution that delivers where it is designed to.
