Gigabyte GeForce RTX 5050 WindForce OC

Name: Gigabyte GeForce RTX 5050 WindForce OC
Brand: Gigabyte
SKU: 5101

Manufacturer: Gigabyte

The Gigabyte GeForce RTX 5050 WindForce OC is a mid-range graphics card based on NVIDIA's Blackwell architecture, manufactured using a 5nm process node with 16,900 million transistors. It operates at a base clock of 2317 MHz with a boost clock of 2587 MHz, delivering 13.25 TFLOPS of floating-point performance and a texture rate of 206.9 GTexels/s. The card measures 199 mm in width and 116 mm in height, and includes RGB lighting along with support for up to four simultaneous displays.

On the memory side, the card is equipped with 8GB of GDDR6 VRAM across a 128-bit bus, achieving an effective memory speed of 20,000 MHz and a maximum bandwidth of 320 GB/s. It supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, alongside ray tracing and DLSS. Connectivity is handled through two HDMI 2.1b ports and two DisplayPort outputs, with Intel Resizable BAR support also included. The card draws 130W and connects via a PCIe 5.0 interface.

Pros

Supports ray tracing and DLSS, enabling access to advanced rendering and upscaling features
Can drive up to four displays simultaneously through a combination of two HDMI 2.1b and two DisplayPort outputs
ECC memory support adds a layer of reliability for error-sensitive workloads
Intel Resizable BAR support allows the CPU to access the full VRAM pool, which can improve frame delivery in supported scenarios
RGB lighting is built into the card for those who want a visually customized build
Compact dimensions of 199 mm x 116 mm make it suitable for smaller form factor cases

Cons

128-bit memory bus width is relatively narrow, which limits memory bandwidth headroom at 320 GB/s
Only 8GB of VRAM may become a limiting factor in memory-demanding workloads or higher-resolution tasks
No USB-C output is available, restricting connectivity options for displays or devices that rely on that port
Air-water cooling is not supported, so thermal management is limited to the included air cooling solution
32 render output units may constrain fill rate in scenarios that demand high pixel throughput

Who is this for?

This card is a reasonable fit for users building compact systems, given its dimensions of 199 mm x 116 mm, and those who want a capable everyday gaming setup with access to ray tracing and DLSS. The four-display output configuration — two HDMI 2.1b and two DisplayPort — makes it a practical option for multi-monitor workflows that do not demand extreme throughput. ECC memory support also makes it somewhat suitable for light compute or error-sensitive tasks where memory reliability matters.

Who is this NOT for?

Users targeting high-resolution or memory-intensive workloads such as 4K gaming, large texture rendering, or complex 3D scene editing are likely to find the 8GB VRAM and 128-bit memory bus restrictive. The card is also not well-suited for those who require liquid or hybrid cooling solutions, as air-water cooling is not supported, which may be a concern in thermally constrained or high-ambient-temperature environments. Additionally, users who depend on USB-C display connectivity will find no support for that on this card.

Performance:

GPU clock speed	2317 MHz
GPU turbo	2587 MHz
pixel rate	82.78 GPixel/s
floating-point performance	13.25 TFLOPS
texture rate	206.9 GTexels/s
GPU memory speed	1750 MHz
shading units	2560
texture mapping units (TMUs)	80
render output units (ROPs)	32
Has Double Precision Floating Point (DPFP)	✓

The GeForce RTX 5050 WindForce OC runs at a base GPU clock of 2317 MHz, rising to 2587 MHz in turbo mode, while delivering 13.25 TFLOPS of floating-point performance alongside a texture rate of 206.9 GTexels/s and a pixel rate of 82.78 GPixel/s. It is built with 2560 shading units, 80 texture mapping units, and 32 render output units, with a GPU memory speed of 1750 MHz. The card also supports Double Precision Floating Point (DPFP), rounding out a solid set of compute-oriented specifications.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	320 GB/s
VRAM	8GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The RTX 5050 WindForce OC is equipped with 8GB of GDDR6 VRAM running across a 128-bit memory bus, with an effective memory speed of 20,000 MHz and a maximum memory bandwidth of 320 GB/s. ECC memory support is also included, which helps with error correction during memory-intensive workloads.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The RTX 5050 WindForce OC supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. It includes ray tracing and DLSS support, along with stereoscopic 3D and multi-display technology for up to four simultaneous outputs. Intel Resizable BAR is also supported, while XeSS (XMX) and LHR are not present on this card. RGB lighting is built in, rounding out the feature set on the hardware side.

Ports:

has an HDMI output	✓
HDMI ports	2
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The RTX 5050 WindForce OC offers a total of four display outputs, consisting of two HDMI 2.1b ports and two DisplayPort outputs. There are no USB-C, DVI, or mini DisplayPort connections present on this card.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	130W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	16900 million
Has air-water cooling	✕
width	199 mm
height	116 mm

The RTX 5050 WindForce OC is built on the Blackwell architecture, fabricated using a 5nm process with 16,900 million transistors, and connects via a PCIe 5.0 interface. It carries a Thermal Design Power of 130W and does not feature air-water cooling. The card measures 199 mm in width and 116 mm in height, making it a relatively compact design within its category.

Final Verdict

The Gigabyte GeForce RTX 5050 WindForce OC is a compact, feature-complete graphics card built on the Blackwell architecture that covers the essentials for everyday gaming and light compute use. Its support for ray tracing, DLSS, and multi-display output across four ports gives it a practical edge for users who want modern rendering capabilities without a large form factor. That said, the 8GB GDDR6 VRAM and 128-bit memory bus place a ceiling on how far it scales in demanding or high-resolution scenarios, and the absence of liquid cooling support narrows its appeal in thermally challenging builds. For users whose needs align with those boundaries, the RTX 5050 WindForce OC delivers a well-rounded and clearly defined package.
