OnePlus Ace 5 Pro

The OnePlus Ace 5 Pro has a non-folding, non-rugged form factor, standing 161.7 mm tall, 75.8 mm wide, and 8.1 mm thick, with a total volume of 99.28 cm³ and a weight of 217 g. It carries an IP65 ingress protection rating, confirming it is water resistant, though it does not feature a fully rugged build.

The OnePlus Ace 5 Pro features a 6.78″ OLED/AMOLED touchscreen with a resolution of 1264 x 2780 px and a pixel density of 450 ppi, delivering a sharp and detailed image across its large panel. It runs at a 120Hz refresh rate and reaches a typical brightness of 800 nits, while supporting HDR10, HDR10+, and Dolby Vision for broad high dynamic range compatibility. Always-On Display is available, though the device has no secondary screen and does not use branded damage-resistant glass.

The OnePlus Ace 5 Pro is powered by the Qualcomm Snapdragon 8 Elite, a 3 nm chipset with an 8-thread CPU running at 2 x 4.32 GHz and 6 x 3.53 GHz using big.LITTLE architecture with HMP support, paired with the Adreno 830 GPU clocked at 1100 MHz with 1536 shading units and support for up to 2 displays. The SoC integrates LTE, TrustZone security, 64-bit support, and graphics APIs including DirectX 12, OpenGL 3.2, OpenGL ES 3.2, and OpenCL 3. The device comes with 16 GB of DDR5 RAM running at 5300 MHz across 2 memory channels, a maximum supported memory amount of 24 GB, a memory bandwidth of 85.1 GB/s, ECC memory support, and 1024 GB of internal storage, while the CPU carries an L1 cache of 192 KB, L2 cache of 12 MB, and L3 cache of 8 MB, with a TDP of 8.2W. In benchmark testing, it achieves an AnTuTu score of 3,218,178, a Geekbench 6 multi-core score of 10,059, and a single-core score of 3,234.

The OnePlus Ace 5 Pro features a multi-lens rear camera system with three sensors at 50, 8, and 2 MP, paired with apertures of f/1.8, f/2.2, and f/2.4 respectively, and optical image stabilization on the main shooter. The rear camera uses a CMOS sensor without back-illumination and supports phase-detection autofocus for stills as well as continuous autofocus during video, though laser autofocus is not present. Video recording reaches 2160p at 60 fps, with slow-motion capture also available, while HDR recording in HDR10 or Dolby Vision formats is not supported. Manual controls extend to ISO, exposure, focus, and white balance, but manual shutter speed is absent; additional shooting modes include burst, panorama, timelapse, and RAW capture, while 360° panorama and 3D recording are not available. The flash setup consists of 2 LEDs without dual-tone or RGB configuration, and there is no front-facing flash. The 16 MP single-lens front camera sits at f/2.4 and is not positioned under the display, offering touch autofocus and HDR but no flash or multi-lens arrangement.

The OnePlus Ace 5 Pro runs Android 15 and includes a broad set of privacy controls covering clipboard warnings, location options, and camera and microphone access management, though Mail Privacy Protection and cross-site tracking blocking are not present. On the customization side, it supports theme customization, dynamic theming, dark mode, and extra dim mode, while focus modes and Quick Start are not available. Productivity features include split-screen multitasking, Picture-in-Picture, full-page screenshots, a media picker, sharing intents, customizable notifications, widgets, app offloading, and the ability to play games while they download, though it cannot function as a PC. The system also offers on-device machine learning, offline voice recognition, voice commands, phone tracking, multi-user support, a child lock, battery health check, and Live Text, while Wi-Fi password sharing and direct OS vendor updates are not supported. The OS is free and open source.

The OnePlus Ace 5 Pro is equipped with a 6100 mAh rechargeable, non-removable battery that supports 100W wired fast charging, with a charger included in the box. Wireless charging is not available, but the device does provide a battery level indicator. Charging speed and capacity are its primary strengths in this area.

The OnePlus Ace 5 Pro includes stereo speakers and three microphones, but omits a 3.5 mm headphone jack and has no built-in radio. For wireless audio, it supports aptX and aptX HD, though LDAC, aptX Adaptive, and aptX Lossless are not available.

The OnePlus Ace 5 Pro supports 5G and accommodates two SIM cards, with cellular connectivity complemented by Wi-Fi 4, 5, 6, and 7 and Bluetooth 5.4. It features a USB Type-C port running USB 2.0, NFC, and an infrared sensor, while HDMI output, DLNA certification, and an external memory slot are absent. Download speeds reach 10,000 Mbit/s and upload speeds 3,500 Mbit/s. On the security side, a fingerprint scanner is present, whereas 3D facial recognition and an iris scanner are not included, and no stylus is bundled. Satellite emergency SOS and crash detection are also not available. Sensors on board include a gyroscope, accelerometer, compass, GPS, and Galileo support, while a barometer, heart rate monitor, ANT+, motion tracking, optical tracking, and a built-in projector are all absent.

The OnePlus Ace 5 Pro includes a video light for recording, while its display is flat rather than curved and uses neither sapphire glass nor an e-paper panel.
