The Palit GeForce RTX 4080 Super Infinity 3 OC runs at a base GPU clock of 2,295 MHz, boosting up to a turbo frequency of 2,580 MHz. Its 10,240 shading units and 320 texture mapping units deliver a floating-point throughput of 52.84 TFLOPS and a texture rate of 825.6 GTexels/s, while 112 render output units contribute to a pixel rate of 289 GPixel/s. GPU memory operates at 1,438 MHz, and the card supports Double Precision Floating Point (DPFP), broadening its suitability for compute-oriented tasks alongside standard graphics workloads.
This card is equipped with 16GB of GDDR6X VRAM running at an effective memory speed of 23,000 MHz across a 256-bit bus, yielding a maximum memory bandwidth of 736 GB/s. ECC memory support is also included, which helps detect and correct memory errors during operation.
The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, alongside stereoscopic 3D and multi-display technology spanning up to four screens simultaneously. Intel Resizable BAR is included, while XeSS (XMX) and LHR are not present. The card does not feature RGB lighting.
The card's output configuration consists of one HDMI 2.1a port and three DisplayPort outputs, providing a total of four available display connections. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.
Built on the Ada Lovelace architecture, the GPU is fabricated using a 5 nm process and integrates 45,900 million transistors, with a Thermal Design Power of 320W. It connects via PCIe 4 and measures 294 mm in width and 116 mm in height. The card relies solely on air cooling, as water cooling is not supported.
