The Xiaomi TV A Pro features a 75″ QLED, LED-backlit LCD panel with a 4K (UHD) resolution of 3840 x 2160 pixels at 59 ppi, rendering up to 1070 million colors at 10-bit depth. It operates at a 60Hz refresh rate and supports a comprehensive set of HDR formats — HDR10, HDR10+, Dolby Vision, and HLG — allowing it to handle a wide range of HDR content. Both the horizontal and vertical viewing angles reach 178°, while an anti-reflection coating and a built-in ambient light sensor help maintain picture clarity across different lighting conditions.
The Xiaomi TV A Pro offers a well-rounded connectivity setup built around three HDMI 2.1 ports and two USB ports, alongside a single RJ45 Ethernet port for wired networking. Wireless connectivity is handled by Wi-Fi 4 (802.11n) and Wi-Fi 5 (802.11ac), with Bluetooth 5 also on board; Miracast is supported for wireless screen mirroring. A 3.5mm headset jack is included, while the TV does not feature a VGA connector, a DVI connector, or an external memory slot. On the broadcast side, the tuner covers DVB-C, DVB-S, DVB-S2, DVB-T, and DVB-T2 standards.
Audio on the Xiaomi TV A Pro is delivered through a stereo speaker system rated at 2 x 10W, without a subwoofer or SRS TheaterSound HD. The TV supports Dolby Audio, Dolby Virtual, and DTS:X decoding, covering a broad range of audio formats for both streaming and broadcast content. Digital Out is available for routing audio to external equipment, and the HDMI implementation includes both ARC and eARC, allowing compatible soundbars or receivers to be connected with return-channel audio over a single HDMI cable.
The Xiaomi TV A Pro measures 1668 mm wide, 964 mm tall, and 85 mm thick, with a total volume of 136,675.92 cm³ and a weight of 22,450 g. It supports VESA mounting, providing flexibility for wall installation. The TV is rated to operate within a temperature range of 0 °C to 40 °C.
The Xiaomi TV A Pro ships with a built-in smart TV platform and supports Chromecast built-in as well as AirPlay, covering both Android and Apple ecosystem casting without additional hardware. Voice control is available through Google Assistant and Amazon Alexa, though Siri and Apple HomeKit are not supported. The TV can also be operated via a smartphone used as a remote, and includes voice commands as a standard input method; the physical remote control, however, is not rechargeable. Additional everyday features include a built-in web browser, sleep timer, child lock, and USB recording, while standby power consumption is rated at 0.5W.
