The AX Gaming Rebel GeForce RTX 5070 X2W operates at a base GPU clock of 2325 MHz, climbing to 2512 MHz under boost conditions, while the GPU memory runs at 1750 MHz. With 6,144 shading units, 192 texture mapping units, and 80 render output units, the card achieves a texture rate of 482.3 GTexels/s and a pixel rate of 201 GPixel/s. Floating-point performance is rated at 30.87 TFLOPS, and the card includes support for Double Precision Floating Point (DPFP), broadening its suitability for compute-oriented workloads alongside standard rendering tasks.
The card is equipped with 12GB of GDDR7 VRAM running across a 192-bit memory bus, reaching an effective memory speed of 28,000 MHz and delivering a maximum memory bandwidth of 672 GB/s. ECC memory support is also included, adding a layer of data integrity protection that can be beneficial in error-sensitive workloads.
The AX Gaming Rebel GeForce RTX 5070 X2W supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, alongside stereoscopic 3D and multi-display technology spanning up to four simultaneous outputs. The card implements Intel Resizable BAR for optimized CPU-to-GPU data access and includes RGB lighting, but does not feature XeSS (XMX) or LHR.
The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, totaling four available display connections. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.
The AX Gaming Rebel GeForce RTX 5070 X2W is built on the Blackwell architecture, fabricated using a 5 nm process and integrating 31,100 million transistors. It connects via PCIe 5.0 and carries a TDP of 250W, with dimensions of 240 mm in width and 120 mm in height. The card does not include air-water cooling.
