Gainward GeForce RTX 5060 Ti Ghost OC 8GB

Name: Gainward GeForce RTX 5060 Ti Ghost OC 8GB
Brand: Gainward
SKU: 1880

Manufacturer: Gainward

The Gainward GeForce RTX 5060 Ti Ghost OC 8GB is a mid-range graphics card based on NVIDIA's Blackwell architecture, manufactured on a 5nm process and housing 21,900 million transistors. It ships with 8GB of GDDR7 VRAM across a 128-bit memory bus, delivering an effective memory speed of 28,000 MHz and a maximum bandwidth of 448 GB/s. The card operates at a base clock of 2,407 MHz, reaching a boosted frequency of 2,632 MHz, and carries a thermal design power rating of 180W.

On the feature side, the RTX 5060 Ti Ghost OC supports DirectX 12 Ultimate alongside OpenGL 4.6 and OpenCL 3, and includes hardware-accelerated ray tracing, DLSS, and Intel Resizable BAR. Its 4,608 shading units are complemented by 144 texture mapping units and 48 render output units, yielding a floating-point throughput of 24.26 TFLOPS and a texture rate of 379 GTexels/s. Connectivity covers four displays simultaneously through one HDMI 2.1b port and three DisplayPort outputs, while PCIe 5 ensures compatibility with current-generation platforms. RGB lighting is present, and the card measures 262.1 mm in length and 126.3 mm in height.

Pros

Supports up to four displays simultaneously through a combination of one HDMI 2.1b port and three DisplayPort outputs
GDDR7 memory delivers an effective speed of 28,000 MHz and a maximum bandwidth of 448 GB/s over a 128-bit bus
Hardware ray tracing and DLSS are both supported, enabling access to two significant rendering features
ECC memory support adds a layer of data integrity for workloads where memory errors are a concern
Intel Resizable BAR is included, allowing the CPU broader access to GPU memory during operation
RGB lighting is built into the card for users who prefer an illuminated build aesthetic

Cons

The 128-bit memory bus width is relatively narrow for an 8GB card, which can limit memory throughput headroom
No USB-C output is available, restricting connectivity options for certain modern displays and devices
Water cooling is not supported; the card relies entirely on air cooling regardless of thermal conditions
With only 8GB of VRAM, memory capacity may become a limiting factor in particularly demanding or memory-intensive workloads

Who is this for?

This card is a reasonable fit for users building a capable gaming or general-purpose desktop system who want access to modern rendering features without excessive power draw. The support for hardware ray tracing and DLSS makes it well-suited for those who want to take advantage of current-generation rendering technologies, while the HDMI 2.1b and three DisplayPort outputs cater well to users who need multi-monitor setups of up to four displays. Its PCIe 5 interface and Intel Resizable BAR support also make it a good match for users pairing it with a contemporary platform who want to keep their system reasonably future-oriented.

Who is this NOT for?

Users engaged in heavily memory-bound tasks — such as working with large textures, high-resolution assets, or memory-intensive compute workloads — may find the combination of 8GB VRAM and a 128-bit memory bus restrictive over time. The card is equally unsuitable for those seeking flexible display connectivity, as the complete absence of USB-C output rules it out for users relying on modern monitors or devices that depend on that interface. Additionally, users operating in thermally constrained environments or those who prefer liquid cooling solutions will find no support for water cooling here, making it a poor fit for compact or high-ambient-temperature builds.

Performance:

GPU clock speed	2407 MHz
GPU turbo	2632 MHz
pixel rate	126.3 GPixel/s
floating-point performance	24.26 TFLOPS
texture rate	379 GTexels/s
GPU memory speed	1750 MHz
shading units	4608
texture mapping units (TMUs)	144
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The GPU runs at a base clock of 2,407 MHz, boosting up to 2,632 MHz under load, while the memory operates at 1,750 MHz. Backed by 4,608 shading units, 144 texture mapping units, and 48 render output units, the card delivers a floating-point throughput of 24.26 TFLOPS alongside a texture rate of 379 GTexels/s and a pixel rate of 126.3 GPixel/s. Double Precision Floating Point (DPFP) is also supported, adding utility for workloads that benefit from higher numerical precision.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus, reaching an effective memory speed of 28,000 MHz and a maximum bandwidth of 448 GB/s. ECC memory support is included, which helps maintain data integrity in workloads sensitive to memory errors.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. Hardware-accelerated ray tracing and DLSS are both present, while stereoscopic 3D and multi-display technology round out the visual feature set, with support for up to four simultaneous displays. Intel Resizable BAR is included for improved CPU-to-GPU data throughput, and RGB lighting is built into the card's design. XeSS (XMX) and LHR are not supported on this model.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, providing a total of four connection options for display setups. USB-C, DVI, and mini DisplayPort outputs are not present on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	180W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	262.1 mm
height	126.3 mm

Built on the Blackwell architecture and fabricated using a 5nm process, the GPU integrates 21,900 million transistors and connects to the system via a PCIe 5 interface. It carries a thermal design power rating of 180W and relies solely on air cooling, with no water-cooling option included. The card measures 262.1 mm in width and 126.3 mm in height.

Final Verdict

The Gainward GeForce RTX 5060 Ti Ghost OC 8GB positions itself as a current-generation graphics card that brings meaningful modern features — including hardware ray tracing, DLSS, and GDDR7 memory with 448 GB/s of bandwidth — to users building or upgrading a contemporary desktop system. Its support for up to four displays, PCIe 5 compatibility, and Intel Resizable BAR reflect a well-rounded feature set for its class, though the 8GB VRAM capacity and 128-bit bus width do place practical ceilings on its scalability in more demanding scenarios. For users whose workloads and display needs align with what this card offers, it represents a focused and technically current option; those with higher memory demands or specific connectivity requirements may find its limitations more consequential over time.
