Gigabyte X870E Aorus Xtreme X3D AI Top

Name: Gigabyte X870E Aorus Xtreme X3D AI Top
Brand: Gigabyte
SKU: 9898

Manufacturer: Gigabyte

The Gigabyte X870E Aorus Xtreme X3D AI Top is a high-specification E-ATX motherboard built around the AM5 socket and X870 chipset. It supports RGB lighting, includes an easy BIOS reset mechanism, and ships with a three-year warranty. The board measures 305 mm × 285 mm and is designed for overclocking, with native support for that functionality baked into its feature set.

Memory support extends to 256 GB across four DDR5 slots running at up to 5200 MHz natively, or up to 9000 MHz when overclocked, across two channels. Storage options include five M.2 sockets and two SATA 3 connectors, with full RAID 0, 1, 5, and 10 support. The rear I/O panel provides eight USB 3.2 Gen 2 Type-A ports, two USB 4 40 Gbps ports, two Thunderbolt 4 ports, one USB 3.2 Gen 2x2 Type-C port, dual RJ45 LAN ports, and an HDMI 2.1 output. Wireless connectivity covers Wi-Fi 7 (802.11be) alongside Bluetooth 5.4, while onboard audio delivers an 8-channel configuration with a 120 dB signal-to-noise ratio.

Pros

Five M.2 sockets provide ample high-speed storage expansion without relying on slower interfaces
Wi-Fi 7 support alongside full backward compatibility down to Wi-Fi 4 covers a wide range of wireless environments
Two Thunderbolt 4 ports and two USB 4 40Gbps ports offer substantial high-bandwidth connectivity on the rear panel
RAM can be overclocked up to 9000 MHz across four DDR5 slots, with a maximum capacity of 256 GB
Full RAID support across modes 0, 1, 5, and 10 gives flexibility for both performance and data redundancy setups
The 120 dB signal-to-noise ratio on the DAC indicates a clean onboard audio implementation

Cons

Only two SATA 3 connectors limits the number of traditional drives that can be connected directly
No ECC memory support restricts use in workloads that require error-correcting RAM
A single HDMI 2.1 output with no DisplayPort means display configuration options are limited without a discrete GPU
No TPM connector is present, which may be relevant for certain security or enterprise requirements
Dual BIOS is absent, meaning there is no automatic fallback if a BIOS update fails

Who is this for?

This motherboard is well-suited to enthusiast desktop builders and power users who want to push their system to its limits. The support for overclocked DDR5 memory up to 9000 MHz alongside a PCIe 5.0 x16 slot makes it a strong fit for demanding workloads such as high-end gaming, 3D rendering, or video production. Users who rely on fast storage will benefit from the five M.2 sockets, while those needing robust connectivity — including Thunderbolt 4, USB 4 40Gbps, and Wi-Fi 7 — will find the I/O layout accommodating for complex peripheral setups. The full RAID 0, 1, 5, and 10 support also makes it a reasonable choice for creative professionals or small workstation builds where storage redundancy or striping is a priority.

Who is this NOT for?

This board is not a practical fit for users working in environments that require ECC memory support, such as professional data integrity or scientific computing applications, as that capability is absent. Its E-ATX form factor means it will not fit in standard mid-tower or smaller cases, making it unsuitable for anyone building a compact or space-constrained system. Additionally, the lack of a dual BIOS makes it less forgiving for users who frequently experiment with BIOS updates or are less experienced with firmware management, where a recovery fallback would otherwise reduce risk.

General info:

CPU socket	AM5
chipset	X870
form factor	E-ATX
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Has Bluetooth	✓
Bluetooth version	5.4
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✓
Has dual BIOS	✕
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	285 mm
width	305 mm
Has integrated CPU	✕

The Gigabyte X870E Aorus Xtreme X3D AI Top is built around the AM5 socket and is compatible with the X870 chipset, housed in an E-ATX form factor measuring 305 mm × 285 mm. It supports a single CPU and has no integrated processor or integrated graphics. The board includes Wi-Fi across multiple generations — from Wi-Fi 4 (802.11n) through to Wi-Fi 7 (802.11be) — along with Bluetooth 5.4, though aptX is not supported. An HDMI 2.1 output is present for display connectivity. Overclocking is supported with an easy-to-use implementation, and resetting the BIOS is straightforward via a clear CMOS feature, though a dual BIOS setup is not included. RGB lighting is onboard, and the board comes with a 3-year warranty.

Memory:

maximum memory amount	256GB
RAM speed (max)	5200 MHz
overclocked RAM speed	9000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

This motherboard supports DDR5 memory across four slots in a dual-channel configuration, with a maximum capacity of 256 GB. Native RAM speeds reach up to 5200 MHz, while overclocking can push that figure to 9000 MHz. ECC memory is not supported.

Ports:

USB 3.2 Gen 2 ports (USB-A)	8
USB 3.2 Gen 1 ports (USB-A)	0
USB 3.2 Gen 2 ports (USB-C)	1
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	0
USB 3.2 Gen 2x2 ports	1
USB 4 40Gbps ports	2
USB 4 20Gbps ports	0
Thunderbolt 4 ports	2
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	0
RJ45 ports	2
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The rear I/O panel offers a substantial USB lineup, led by eight USB 3.2 Gen 2 Type-A ports, one USB 3.2 Gen 2 Type-C port, and one USB 3.2 Gen 2x2 Type-C port. At the higher end, there are two USB 4 40Gbps ports and two Thunderbolt 4 ports, while USB 4 20Gbps, USB 3.2 Gen 1, and USB 2.0 ports are absent. Display output is handled solely by a single HDMI connection, with no DisplayPort, DVI, or VGA outputs present. Network connectivity is covered by two RJ45 ports, and there are no eSATA or PS/2 ports included.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	4
USB 3.2 Gen 2 ports (through expansion)	0
USB 3.2 Gen 2x2 ports (through expansion)	1
USB-C 3.2 Gen 2 ports (through expansion)	1
USB 2.0 ports (through expansion)	4
SATA 3 connectors	2
fan headers	6
M.2 sockets	5
Has TPM connector	✕
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

For internal expansion, the board provides four USB 3.2 Gen 1 headers and four USB 2.0 headers, along with one USB 3.2 Gen 2x2 connector and one USB-C 3.2 Gen 2 connector; there are no USB 3.2 Gen 2 headers available. Storage connectivity includes five M.2 sockets and two SATA 3 connectors, while SATA 2, U.2, and mSATA connections are not present. Cooling is handled through six fan headers, and there is no TPM connector on board.

Expansion slots:

PCIe 4.0 x16 slots	0
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	0
PCIe x1 slots	0
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	1
PCIe x8 slots	1

The board offers three PCIe slots in total: one PCIe 5.0 x16 slot for the primary graphics card or other full-bandwidth add-in cards, one PCIe x8 slot, and one PCIe x4 slot. There are no PCIe 4.0, 3.0, or 2.0 x16 slots, and no PCIe x1 or legacy PCI slots are present.

Audio:

Signal-to-Noise ratio (DAC)	120 dB
audio channels	8
Has S/PDIF Out port	✕
audio connectors	2

The onboard audio supports 8 channels and delivers a signal-to-noise ratio of 120 dB from the DAC, with two audio connectors available on the rear panel. An S/PDIF Out port is not included.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✓
Supports RAID 0	✓
Supports RAID 0+1	✕

The board supports RAID 0, 1, 5, and 10 (1+0) configurations, covering a broad range of performance and redundancy setups. RAID 0+1 is not supported.

Final Verdict

The Gigabyte X870E Aorus Xtreme X3D AI Top is a feature-dense E-ATX motherboard that targets enthusiast builders who want a well-equipped platform built around the AM5 socket. Its standout connectivity — including Thunderbolt 4, USB 4 40Gbps, and Wi-Fi 7 — combined with five M.2 sockets and robust DDR5 overclocking headroom, makes it a capable foundation for demanding desktop builds. Some limitations, such as the absence of ECC support, a dual BIOS, and restricted SATA connectivity, mean it is better aligned with high-performance consumer use than professional or mission-critical workstation environments. For users who need a feature-rich AM5 platform with extensive high-speed I/O and strong storage expansion potential, this board covers most bases with confidence.
