Intel Core i5-110

Name: Intel Core i5-110
Brand: Intel
SKU: 7556

Manufacturer: Intel

The Intel Core i5-110 is a laptop-oriented processor that brings together a balanced combination of multi-core throughput and integrated graphics capability within a 65W thermal design envelope. Built on a 14nm process node and socketed in the LGA 1200 format, it supports 64-bit computing and PCIe 3.0, making it a straightforward fit for mainstream computing platforms.

On the performance side, the chip runs six cores across 12 threads at a base speed of 2.9GHz per core, with Turbo Boost 2.0 pushing individual clocks up to 4.3GHz under load. A 12MB L3 cache (2MB per core) helps sustain data throughput across threads. The integrated UHD Graphics 630 runs at 350MHz base and up to 1100MHz boost, supporting up to three displays, DirectX 12, OpenGL 4.5, and 192 shading units. Memory support extends to DDR4 at 2666MHz across two channels, with a maximum capacity of 128GB and a peak bandwidth of 41.6GB/s.

Pros

Supports up to 128GB of DDR4 RAM across two channels, providing substantial headroom for memory-intensive workloads
The integrated UHD Graphics 630 can drive up to three displays simultaneously with DirectX 12 and OpenGL 4.5 support
Turbo Boost 2.0 allows individual cores to reach 4.3GHz, offering meaningful responsiveness during single-threaded tasks
A 12MB L3 cache spread across six cores helps sustain throughput when handling varied concurrent tasks
A broad set of instruction set extensions including AVX2, FMA3, AES, and SSE 4.2 enables hardware-accelerated handling of encryption and vectorized operations
NX bit support adds a hardware-level layer of protection against certain types of malicious code execution

Cons

The 65W TDP is relatively high for a laptop-class processor, which may place greater demands on cooling and battery life
The multiplier is locked, so clock speed cannot be manually adjusted beyond the factory-set limits
ECC memory is not supported, limiting suitability for applications that require error-correcting RAM
The GPU base clock of 350MHz is modest, and the 192 shading units may limit capability for more graphically demanding tasks
Built on a 14nm process node, which is less power-efficient compared to smaller semiconductor geometries
PCIe version 3 limits the available bandwidth for connected expansion devices relative to newer interface versions

Who is this for?

This processor is a reasonable fit for everyday laptop use cases such as office productivity, web browsing, and light content consumption, where its six-core, 12-thread configuration provides enough headroom for smooth multitasking. Users who need to connect multiple screens will benefit from the integrated UHD Graphics 630's ability to drive up to three displays simultaneously, making it a workable option for basic multi-monitor setups. The broad instruction set support — including AES and AVX2 — also makes it a decent choice for users who occasionally run encryption-heavy or data-processing workloads without needing discrete hardware.

Who is this NOT for?

Users with demanding graphical needs will find the integrated UHD Graphics 630 insufficient, as its modest 192 shading units and 350MHz base clock make it ill-suited for gaming, 3D rendering, or GPU-accelerated creative workloads. The locked multiplier means there is no room for manual clock speed tuning, which makes this chip a poor match for anyone seeking overclocking capability. Additionally, the 65W TDP and the absence of ECC memory support limit its appeal for thermally constrained ultra-thin laptops or reliability-critical professional environments where error-correcting memory is a requirement.

General info:

Type	Laptop
CPU socket	LGA 1200
Has integrated graphics	✓
Thermal Design Power (TDP)	65W
semiconductor size	14 nm
CPU temperature	100 °C
PCI Express (PCIe) version	3
Supports 64-bit	✓

The Intel Core i5-110 is a laptop-type processor built on a 14nm semiconductor process and fitted to the LGA 1200 socket. It carries a Thermal Design Power (TDP) of 65W and is rated for a maximum operating temperature of 100°C. The chip includes integrated graphics and fully supports 64-bit computing, while connectivity is handled through PCIe version 3.

Performance:

CPU speed	6 x 2.9 GHz
CPU threads	12 threads
turbo clock speed	4.3GHz
Has an unlocked multiplier	✕
L3 cache	12 MB
L3 core	2 MB/core
Uses big.LITTLE technology	✕
clock multiplier	29
Turbo Boost version	2

The processor features six cores running at a base clock of 2.9GHz each, spreading workloads across 12 threads for efficient multitasking. With a clock multiplier of 29 and support for Turbo Boost version 2, individual cores can ramp up to 4.3GHz under demanding conditions. Each core has access to 2MB of L3 cache, adding up to a total of 12MB of L3 cache shared across the chip. The multiplier is locked, and the processor does not use big.LITTLE technology.

Benchmarks:

Integrated graphics:

GPU clock speed	350 MHz
GPU name	UHD Graphics 630
GPU turbo	1100 MHz
GPU execution units	24
DirectX version	DirectX 12
supported displays	3
OpenGL version	4.5
OpenCL version	3
texture mapping units (TMUs)	24
render output units (ROPs)	3
shading units	192

The integrated UHD Graphics 630 operates at a base clock of 350MHz, with a turbo frequency reaching up to 1100MHz under load. It is built around 24 execution units paired with 24 texture mapping units, 3 render output units, and 192 shading units, providing the fundamental rendering resources for everyday graphics tasks. The GPU supports up to three displays simultaneously and is compatible with DirectX 12, OpenGL 4.5, and OpenCL 3, covering a broad range of graphics and compute workloads.

Memory:

RAM speed (max)	2666 MHz
maximum memory bandwidth	41.6 GB/s
DDR memory version	4
memory channels	2
maximum memory amount	128GB
bus transfer rate	8 GT/s
Supports ECC memory	✕

The processor supports DDR4 memory across two channels, with a maximum RAM speed of 2666MHz and a peak memory bandwidth of 41.6GB/s. The bus transfer rate is rated at 8GT/s, and the chip can address up to 128GB of total system memory. ECC memory is not supported by this processor.

Features:

instruction sets	MMX, F16C, FMA3, AES, AVX, AVX2, SSE 4.1, SSE 4.2
uses multithreading	✓
Has NX bit	✓

The processor includes multithreading support and the NX bit, the latter providing a hardware-level mechanism to help prevent certain types of malicious code execution. On the instruction set side, it covers a broad range of extensions including MMX, AVX, AVX2, FMA3, F16C, AES, SSE 4.1, and SSE 4.2, enabling accelerated handling of tasks such as floating-point math, encryption, and vectorized data processing.

Final Verdict

The Intel Core i5-110 is a laptop processor that covers the fundamentals competently — six cores with 12-thread support, a broad instruction set, and the ability to drive up to three displays through its integrated UHD Graphics 630. Its Turbo Boost 2.0 capability reaching 4.3GHz, combined with 12MB of L3 cache and dual-channel DDR4 support up to 128GB, gives it a solid foundation for everyday computing and moderate multitasking. That said, its locked multiplier, 65W thermal output, and the inherent constraints of integrated graphics mean it is best suited to general-purpose laptop use rather than demanding creative or gaming workloads. For users whose needs align with that scope, the i5-110 delivers a well-rounded and functionally complete specification set.
