AMD Radeon RX 9060

Manufacturer: AMD

The AMD Radeon RX 9060 is a mid-range graphics card based on the RDNA 4.0 architecture, manufactured on a 4nm process node and packing 29,700 million transistors. It supports ray tracing, AMD FSR4, and DirectX 12 Ultimate, making it a capable option for modern rendering workloads. The card connects via PCIe 5.0 and offers a boost clock of up to 2990 MHz, reflecting its relatively lean thermal envelope of just 132W.

On the memory side, the RX 9060 features 8GB of GDDR6 VRAM running at an effective speed of 18,000 MHz across a 128-bit bus, yielding up to 288 GB/s of bandwidth. Its 1792 shading units are complemented by 112 texture mapping units and 64 render output units, producing a texture rate of 334.9 GTexels/s and a pixel rate of 191.4 GPixel/s. For display output, the card provides one HDMI 2.1b port and two DisplayPort connections, with support for multi-display configurations and AMD SAM. ECC memory support and double-precision floating-point capability are also present in the feature set.

Pros

Supports ray tracing and DirectX 12 Ultimate, enabling compatibility with modern rendering features in current-generation titles and applications
FSR4 upscaling is included, allowing for resolution scaling without relying on third-party or competing technologies
ECC memory support adds a layer of data integrity useful for compute and workstation-adjacent workloads
Built on a 4nm process with RDNA 4.0 architecture, integrating 29,700 million transistors within a 132W thermal envelope
PCIe 5.0 interface ensures compatibility with current-generation platforms without bandwidth constraints
Double-precision floating-point support extends the card's utility beyond gaming into compute tasks

Cons

The 128-bit memory bus width is narrow for this VRAM tier, which can limit memory throughput in bandwidth-sensitive scenarios
Only 8GB of VRAM may prove restrictive for workloads or applications that demand larger frame buffers
DLSS is not supported, limiting upscaling options to AMD FSR4 only
No USB-C display output is available, which may reduce compatibility with certain modern monitors and displays
The card does not include an integrated air-water cooling solution, leaving thermal management entirely dependent on the board partner's cooler design

Who is this for?

The RX 9060 is well-suited for users who primarily engage in mainstream gaming and ray-traced rendering, where its DirectX 12 Ultimate support, FSR4 upscaling, and 21.4 TFLOPS of compute throughput provide a capable foundation. Its 132W TDP makes it a practical fit for compact or power-conscious system builds where thermal headroom is limited. The inclusion of ECC memory support and double-precision floating-point also makes it a reasonable choice for users who occasionally run light compute or workstation-adjacent workloads alongside conventional graphical tasks.

Who is this NOT for?

Users pursuing high-resolution content creation or memory-intensive rendering pipelines may find the 8GB VRAM and 128-bit bus width insufficient, as these configurations often demand larger frame buffers and greater memory throughput than this card provides. The absence of DLSS support makes it a poor match for users who are specifically invested in that upscaling ecosystem. Additionally, those requiring multi-monitor setups with USB-C display connectivity will find the port selection limiting, as the card offers no USB-C outputs and only three display connections in total.

Performance:

GPU clock speed	1700 MHz
GPU turbo	2990 MHz
pixel rate	191.4 GPixel/s
floating-point performance	21.4 TFLOPS
texture rate	334.9 GTexels/s
GPU memory speed	2518 MHz
shading units	1792
texture mapping units (TMUs)	112
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The AMD Radeon RX 9060 operates at a base GPU clock of 1700 MHz, scaling up to 2990 MHz in boost mode, while the memory runs at 2518 MHz. Its 1792 shading units are backed by 112 texture mapping units and 64 render output units, delivering a texture rate of 334.9 GTexels/s and a pixel rate of 191.4 GPixel/s. Floating-point performance sits at 21.4 TFLOPS, and the card includes support for double-precision floating-point operations, adding versatility for compute-oriented tasks alongside traditional rendering workloads.

Memory:

effective memory speed	18000 MHz
maximum memory bandwidth	288 GB/s
VRAM	8GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The RX 9060 is equipped with 8GB of GDDR6 VRAM running across a 128-bit memory bus, reaching an effective memory speed of 18,000 MHz and delivering a maximum bandwidth of 288 GB/s. The card also supports ECC memory, which helps detect and correct memory errors during operation — a useful capability for tasks that benefit from improved data integrity.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✕

The RX 9060 supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of modern graphics and compute APIs. Ray tracing, stereoscopic 3D, and multi-display output are all supported, alongside AMD FSR4 for upscaling and AMD SAM for CPU-GPU memory access optimization. The card does not include DLSS, XeSS (XMX), LHR, or RGB lighting, and it carries no hash rate limiter.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The RX 9060 provides a total of three display outputs: one HDMI 2.1b port and two DisplayPort outputs. There are no USB-C, DVI, or mini DisplayPort connections on this card.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	132W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕

The RX 9060 is built on the RDNA 4.0 architecture, fabricated using a 4nm process node and integrating 29,700 million transistors. It connects via PCIe 5.0 and carries a Thermal Design Power of 132W. The card does not include an integrated air-water cooling solution.

Final Verdict

The AMD Radeon RX 9060 presents a focused specification set built around the RDNA 4.0 architecture, offering meaningful capabilities for mainstream gaming and light compute tasks within a restrained 132W power profile. Its support for ray tracing, DirectX 12 Ultimate, and AMD FSR4 upscaling positions it well for users working within modern rendering pipelines, while ECC memory support and double-precision floating-point capability add a degree of versatility beyond conventional gaming workloads. That said, the 8GB VRAM ceiling and 128-bit bus will naturally constrain its reach in more demanding or memory-intensive scenarios. For users whose workloads align with its strengths, the RX 9060 is a coherent and technically grounded option — most effective when paired with a system build that matches its power and connectivity profile.
