Galax GeForce RTX 5050 1-Click OC

Name: Galax GeForce RTX 5050 1-Click OC
Brand: Galax
SKU: 5643

Manufacturer: Galax

The Galax GeForce RTX 5050 1-Click OC is a graphics card based on NVIDIA's Blackwell architecture, manufactured using a 5nm process and housing 16,900 million transistors. It ships with 8GB of GDDR6 memory across a 128-bit bus, delivering a maximum memory bandwidth of 320 GB/s at an effective memory speed of 20,000 MHz. With RGB lighting and support for up to four simultaneous displays, the card targets users who want both visual customization and multi-monitor flexibility.

On the performance side, the RTX 5050 1-Click OC runs at a base GPU clock of 2,317 MHz, with a turbo frequency reaching 2,587 MHz, contributing to a floating-point throughput of 13.25 TFLOPS and a texture rate of 207 GTexels/s. It includes 2,560 shading units, 80 TMUs, and 32 ROPs, and carries a TDP of 130W over a PCIe 5.0 interface. Feature support spans DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, DLSS, Intel Resizable BAR, and ECC memory, while connectivity is handled through two HDMI 2.1b ports and two DisplayPort outputs.

Pros

Supports up to four simultaneous displays, making it suited for multi-monitor setups
Includes ray tracing and DLSS support, enabling access to modern rendering features
Comes with RGB lighting built in, adding visual customization without requiring additional hardware
Offers four video output ports — two HDMI 2.1b and two DisplayPort — covering a range of modern display connectivity needs
ECC memory support adds a layer of data integrity for workloads that benefit from error correction
Intel Resizable BAR support allows the CPU to access the full GPU frame buffer, which can improve data transfer efficiency

Cons

128-bit memory bus width is relatively narrow for an 8GB card, which may limit memory throughput headroom
No USB-C output is available, limiting compatibility with displays or devices that rely on that connector
Water cooling is not supported; the card relies solely on air cooling
8GB of VRAM may prove restrictive for memory-intensive workloads at higher resolutions
No DVI or mini DisplayPort outputs, which could be a limitation for users with older display hardware

Who is this for?

This card is a reasonable fit for users building compact or mid-range desktop systems who want access to modern graphics features without a high power draw, given its 130W TDP and relatively modest physical dimensions of 234mm x 129.5mm. It suits those who need multi-monitor productivity setups, as it supports up to four displays through a combination of HDMI 2.1b and DisplayPort outputs. Users interested in current rendering technologies such as ray tracing and DLSS will find both supported here, along with DirectX 12 Ultimate and OpenCL 3 for workloads that span gaming and general compute tasks.

Who is this NOT for?

Users with demanding workflows that require moving large data sets across the memory subsystem may find the 128-bit memory bus a limiting factor, as it constrains peak bandwidth despite the 8GB GDDR6 configuration. The card is also not well suited for those who rely on USB-C display connectivity, since no such output is present. Additionally, users running memory-intensive applications at high resolutions — where VRAM headroom becomes critical — may find that 8GB of VRAM falls short of what is needed to handle large textures or complex scene data without compromise.

Performance:

GPU clock speed	2317 MHz
GPU turbo	2587 MHz
pixel rate	82.78 GPixel/s
floating-point performance	13.25 TFLOPS
texture rate	207 GTexels/s
GPU memory speed	2500 MHz
shading units	2560
texture mapping units (TMUs)	80
render output units (ROPs)	32
Has Double Precision Floating Point (DPFP)	✓

The Performance section of the Galax GeForce RTX 5050 1-Click OC reveals a GPU base clock of 2,317 MHz that boosts up to 2,587 MHz under load, supported by 2,560 shading units, 80 texture mapping units, and 32 render output units. These combine to produce a texture rate of 207 GTexels/s and a pixel rate of 82.78 GPixel/s, while overall floating-point performance reaches 13.25 TFLOPS. The GPU memory operates at 2,500 MHz, and the card includes support for Double Precision Floating Point (DPFP), rounding out a performance profile suited to a range of compute and graphics workloads.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	320 GB/s
VRAM	8GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The Galax GeForce RTX 5050 1-Click OC is equipped with 8GB of GDDR6 VRAM running across a 128-bit memory bus, with an effective memory speed of 20,000 MHz that translates to a maximum memory bandwidth of 320 GB/s. The card also supports ECC memory, which enables error detection and correction during memory operations, adding a layer of data integrity for relevant workloads.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The Galax GeForce RTX 5050 1-Click OC supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. It includes hardware-level ray tracing, DLSS, and stereoscopic 3D support, while XeSS (XMX) and LHR are not present on this card. Multi-display technology is supported with a maximum of four simultaneous displays, and Intel Resizable BAR is available for improved CPU-to-GPU data access. The card also features RGB lighting for visual customization.

Ports:

has an HDMI output	✓
HDMI ports	2
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The Galax GeForce RTX 5050 1-Click OC offers a total of four video outputs, consisting of two HDMI 2.1b ports and two DisplayPort outputs. There are no USB-C, DVI, or mini DisplayPort connectors on this card, keeping the output configuration straightforward and focused on the two most widely used modern display interfaces.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	130W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	16900 million
Has air-water cooling	✕
width	234 mm
height	129.5 mm

The Galax GeForce RTX 5050 1-Click OC is built on the Blackwell architecture, fabricated using a 5nm process and integrating 16,900 million transistors. It connects via a PCIe 5.0 interface and carries a Thermal Design Power of 130W, with cooling handled exclusively by air — water cooling is not supported. The card measures 234mm in width and 129.5mm in height, giving a sense of its physical footprint within a system.

Final Verdict

The Galax GeForce RTX 5050 1-Click OC presents itself as a compact, energy-efficient graphics card built on the Blackwell architecture, offering a well-rounded feature set that includes ray tracing, DLSS, DirectX 12 Ultimate, and support for up to four displays — all within a 130W power envelope. Its modern connectivity with dual HDMI 2.1b and dual DisplayPort outputs makes it a practical choice for multi-monitor users, while ECC memory support and Intel Resizable BAR add functional depth beyond typical consumer use. That said, the 128-bit memory bus and 8GB VRAM ceiling mean it is best matched to moderate workloads rather than the most demanding graphics or compute tasks. Overall, the RTX 5050 1-Click OC is a focused, feature-complete card that serves users who prioritize efficiency, contemporary API support, and display versatility over raw throughput capacity.
