Gigabyte Radeon RX 9060 XT Gaming 8GB

Name: Gigabyte Radeon RX 9060 XT Gaming 8GB
Brand: Gigabyte
SKU: 7541

Manufacturer: Gigabyte

The Gigabyte Radeon RX 9060 XT Gaming is a mid-range graphics card based on AMD's RDNA 4.0 architecture, manufactured on a 4 nm process with 29.7 billion transistors. It carries a 3130 MHz boost clock alongside a 1700 MHz base frequency, and the card operates within a 150W TDP envelope, making it a relatively contained option in terms of power draw. RGB lighting is included, and the card measures 281 mm in length and 118 mm in height.

On the memory side, the card is equipped with 8GB of GDDR6 running across a 128-bit bus at an effective speed of 20000 MHz, yielding a maximum bandwidth of 322.3 GB/s. Its 2048 shading units, 128 texture mapping units, and 64 render output units contribute to a texture rate of 400.6 GTexels/s and a floating-point throughput of 25.64 TFLOPS. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, ray tracing, AMD FSR4, and AMD SAM, while connectivity is handled through one HDMI 2.1b port and two DisplayPort outputs, supporting up to three displays simultaneously.

Pros

The boost clock of 3130 MHz and 25.64 TFLOPS of floating-point performance indicate strong throughput for demanding rendering workloads
Ray tracing support combined with AMD FSR4 upscaling allows for visually detailed output while managing rendering load
HDMI 2.1b and two DisplayPort outputs enable connection to up to three displays simultaneously
ECC memory support adds a degree of data reliability useful for compute and content creation tasks
A 150W TDP keeps power consumption relatively contained for the level of performance on offer
RGB lighting is built in, giving the card some visual customization potential within a system build

Cons

The 128-bit memory bus is narrow for this class of card, which can limit memory bandwidth in high-resolution scenarios
With only 8GB of VRAM, memory capacity may become a limiting factor in texture-heavy or high-resolution workloads
DLSS and XeSS upscaling are not supported, leaving AMD FSR4 as the only upscaling option
No USB-C output is available, which restricts compatibility with certain modern monitors and display adapters
Water cooling is not supported, so thermal management relies entirely on the air cooler solution

Who is this for?

This card is a solid fit for users engaged in 1080p and 1440p gaming, where its 25.64 TFLOPS of compute throughput, 3130 MHz boost clock, and FSR4 upscaling support can sustain smooth frame delivery across a wide range of titles. The inclusion of ray tracing further suits those who want visually detailed rendering without stepping up to a larger card. Its 150W TDP and compact 281 mm length also make it a practical choice for builds where space or power delivery is constrained, such as mid-tower systems with modest PSU headroom. Users with light compute or content creation needs will additionally benefit from ECC memory support and OpenCL 2.2 compatibility.

Who is this NOT for?

Users targeting 4K gaming or high-resolution content creation are likely to find the 8GB VRAM and 128-bit memory bus limiting, as texture-heavy workloads at elevated resolutions can quickly saturate both capacity and bandwidth. Those who rely on DLSS or XeSS upscaling — common in NVIDIA-optimized or Intel-supported titles — will find neither available here, with FSR4 being the sole upscaling option. The absence of USB-C output also makes this card a poor match for users with modern displays or VR headsets that depend on that connection type, and the air-only cooling solution may not satisfy those building systems where sustained thermal performance under extended load is a priority.

Performance:

GPU clock speed	1700 MHz
GPU turbo	3130 MHz
pixel rate	200.3 GPixel/s
floating-point performance	25.64 TFLOPS
texture rate	400.6 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The Gigabyte Radeon RX 9060 XT Gaming operates at a base clock of 1700 MHz, climbing to a boost frequency of 3130 MHz under load. Its 2048 shading units are paired with 128 texture mapping units and 64 render output units, producing a texture rate of 400.6 GTexels/s and a pixel rate of 200.3 GPixel/s. Floating-point performance reaches 25.64 TFLOPS, while GPU memory runs at 2518 MHz. The card also supports Double Precision Floating Point (DPFP), broadening its utility for compute-oriented workloads.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	322.3 GB/s
VRAM	8GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The card comes equipped with 8GB of GDDR6 VRAM running across a 128-bit memory bus at an effective speed of 20000 MHz, delivering a maximum memory bandwidth of 322.3 GB/s. ECC memory support is also included, which adds a layer of data integrity for workloads where memory accuracy is a priority.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✓
supported displays	3

The Gigabyte Radeon RX 9060 XT Gaming supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of graphics and compute APIs. Ray tracing and stereoscopic 3D are both supported, and AMD FSR4 is available as an upscaling solution, while DLSS and XeSS (XMX) are not supported. The card includes AMD SAM for memory access optimization and does not carry LHR restrictions. Multi-display technology allows for up to three simultaneous displays, and RGB lighting is built into the card's design.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and two DisplayPort outputs, providing a total of three available connections. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	150W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕
width	281 mm
height	118 mm

Built on the RDNA 4.0 architecture and fabricated using a 4 nm process, this card integrates 29,700 million transistors and connects via a PCIe 5 interface. It carries a Thermal Design Power of 150W and relies on air cooling, with no water cooling option included. The card measures 281 mm in width and 118 mm in height.

Final Verdict

The Gigabyte Radeon RX 9060 XT Gaming is a well-defined mid-range graphics card that delivers a coherent set of specifications for users operating at 1080p and 1440p resolutions. Built on AMD's RDNA 4.0 architecture with a 3130 MHz boost clock and 25.64 TFLOPS of floating-point performance, it handles a broad range of rendering workloads competently, and the addition of ray tracing and FSR4 support gives it meaningful feature coverage for modern titles. Its 150W TDP and compact footprint make it accessible to a wide range of system configurations, though users with ambitions toward 4K workloads or those dependent on alternative upscaling technologies should weigh the 8GB VRAM capacity and 128-bit bus width carefully. Taken as a whole, the RX 9060 XT Gaming is a purposeful card that stays within its defined scope and delivers on what its specifications promise.
