MSI GeForce RTX 5060 Gaming OC

Manufacturer: MSI

The MSI GeForce RTX 5060 Gaming OC is a mid-range graphics card built on NVIDIA's Blackwell architecture, manufactured using a 5 nm process and packed with 21,900 million transistors. It ships with 8GB of GDDR7 memory running across a 128-bit bus at an effective speed of 28,000 MHz, delivering up to 448 GB/s of memory bandwidth. The card supports ray tracing, DLSS, DirectX 12 Ultimate, and RGB lighting, while accommodating up to four displays simultaneously.

On the compute side, the RTX 5060 Gaming OC features 3,840 shading units, 120 texture mapping units, and 48 render output units, yielding a texture rate of 315 GTexels/s and a pixel fill rate of 126 GPixel/s. Its base clock sits at 2,280 MHz with a turbo frequency of 2,625 MHz, and the card carries a thermal design power rating of 145W. Connectivity is handled through one HDMI 2.1b port and three DisplayPort outputs, with the card interfacing via PCIe 5.0 and measuring 248 mm in length and 135 mm in height.

Pros

Supports ray tracing and DLSS, enabling hardware-accelerated visual effects and AI-driven upscaling in compatible titles
GDDR7 memory with an effective speed of 28,000 MHz and 448 GB/s of bandwidth provides fast data throughput for graphics workloads
Three DisplayPort outputs plus one HDMI 2.1b port allow connection of up to four displays simultaneously
PCIe 5.0 interface ensures the card is compatible with current-generation motherboard platforms
ECC memory support adds data integrity protection, which is useful for compute and content creation tasks
RGB lighting is included for users who want visual customization in their build

Cons

The 128-bit memory bus is relatively narrow for an 8GB card, which can limit memory throughput in bandwidth-intensive scenarios
No USB-C output is available, reducing flexibility for users with USB-C monitors or VR headsets
Air-water cooling is not supported, so users cannot opt for a liquid cooling solution on this card
With only 8GB of VRAM, memory capacity may become a limiting factor in demanding or high-resolution workloads

Who is this for?

This card is well suited to users who want to run ray tracing and DLSS-enabled titles at moderate resolutions, taking advantage of hardware-accelerated visuals and AI upscaling. Its support for up to four simultaneous displays also makes it a practical choice for multi-monitor setups, whether for productivity or immersive gaming environments. The inclusion of ECC memory support and OpenCL 3 compatibility additionally makes it a reasonable fit for light creative or compute workloads that benefit from data integrity and GPU-accelerated processing.

Who is this NOT for?

Users who regularly work with high-resolution textures, large 3D scenes, or memory-intensive rendering tasks may find the 8GB VRAM ceiling a limiting factor, as such workloads can exhaust available memory quickly. The 128-bit bus width further constrains raw memory throughput in scenarios that demand sustained bandwidth, making the card less suited to demanding professional GPU compute or AI inference workloads. Additionally, the absence of a USB-C output means users relying on USB-C monitors or compatible VR hardware will find the connectivity options insufficient for their setup.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2625 MHz
pixel rate	126 GPixel/s
floating-point performance	20.16 TFLOPS
texture rate	315 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The MSI GeForce RTX 5060 Gaming OC operates at a base clock of 2,280 MHz and reaches a turbo frequency of 2,625 MHz, supported by a GPU memory speed of 1,750 MHz. Its compute resources include 3,840 shading units, 120 texture mapping units, and 48 render output units, translating into a texture rate of 315 GTexels/s and a pixel fill rate of 126 GPixel/s. Overall floating-point performance is rated at 20.16 TFLOPS, and the card includes support for Double Precision Floating Point (DPFP).

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus at an effective speed of 28,000 MHz, resulting in a maximum memory bandwidth of 448 GB/s. ECC memory support is also included, adding a layer of data integrity for workloads that require it.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The MSI GeForce RTX 5060 Gaming OC supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, alongside stereoscopic 3D and multi-display technology spanning up to four screens. Intel Resizable BAR is enabled, while XeSS (XMX) and LHR are not present on this card. RGB lighting is included, rounding out the feature set.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, providing a total of four display connections. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	248 mm
height	135 mm

The MSI GeForce RTX 5060 Gaming OC is built on the Blackwell architecture, fabricated using a 5 nm process and integrating 21,900 million transistors. It connects via PCIe 5.0 and carries a thermal design power rating of 145W, relying on air cooling without a water-cooling option. The card measures 248 mm in width and 135 mm in height, giving a clear indication of its physical footprint.

Final Verdict

The MSI GeForce RTX 5060 Gaming OC is a well-rounded graphics card that brings together the Blackwell architecture, ray tracing, DLSS support, and GDDR7 memory with 448 GB/s of bandwidth in a package suited to mainstream gaming and light compute use. Its four-display output capability and Intel Resizable BAR support add practical versatility, while the 145W TDP keeps power demands measured. The 8GB VRAM and 128-bit bus do place a ceiling on what the card can comfortably handle in the most demanding workloads, so users with heavier professional or high-resolution needs should weigh those constraints carefully. For those whose usage aligns with its strengths, the RTX 5060 Gaming OC represents a focused and capable option within the mid-range graphics card segment.
