PNY GeForce RTX 5050 Single Fan

Manufacturer: PNY

The PNY GeForce RTX 5050 Single Fan is a compact graphics card built on NVIDIA's Blackwell architecture, manufactured using a 5nm process with 16.9 billion transistors. It ships with 8GB of GDDR6 memory across a 128-bit bus and is designed around a single-fan cooling solution, keeping its physical footprint modest at 147mm wide and 125mm tall.

On the performance side, the card operates at a base clock of 2317 MHz with a turbo frequency reaching 2572 MHz, delivering 13.17 TFLOPS of floating-point throughput and a texture rate of 205.8 GTexels/s. Its 2560 shading units are paired with 80 TMUs and 32 ROPs, while memory bandwidth reaches 320 GB/s at an effective speed of 20000 MHz. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, ray tracing, DLSS, and Intel Resizable BAR, with connectivity provided through one HDMI 2.1b port and three DisplayPort outputs, supporting up to four displays simultaneously. The card carries a 3-year warranty and draws 130W under load via a PCIe 5.0 interface.

Pros

Supports ray tracing and DLSS, enabling more advanced rendering capabilities for compatible workloads
Can drive up to four displays simultaneously through its combination of one HDMI 2.1b and three DisplayPort outputs
ECC memory support adds a layer of data integrity useful for workloads sensitive to memory errors
Built on a 5nm process with 16,900 million transistors, reflecting a modern and dense chip design
Intel Resizable BAR support allows the CPU to access the full GPU memory pool, which can improve data throughput in supported systems
Comes with a 3-year warranty, offering a solid coverage period for this category of hardware

Cons

128-bit memory bus width is relatively narrow for an 8GB card, which can limit memory bandwidth in bandwidth-intensive scenarios
No USB-C output is available, limiting connectivity options for monitors or devices that rely on that interface
The single-fan cooling solution may struggle to maintain low temperatures under sustained heavy loads compared to multi-fan designs
No RGB lighting for users who factor aesthetics into their build
Does not include water cooling or an air-water hybrid option, restricting thermal management flexibility

Who is this for?

This card is a reasonable fit for users building compact or space-conscious systems, given its modest 147mm x 125mm footprint and single-fan design. Its support for ray tracing and DLSS makes it suitable for those who want access to modern rendering features without stepping into larger, higher-power hardware. The four-display output capability — combining one HDMI 2.1b and three DisplayPort connections — also makes it a practical option for multi-monitor setups in productivity or light creative environments. Additionally, ECC memory support means it can serve users with workloads that require basic memory error correction, such as certain technical or data-sensitive computing tasks.

Who is this NOT for?

Users targeting demanding, sustained workloads will likely find the single-fan thermal solution limiting, as it offers less cooling headroom under prolonged heavy use compared to multi-fan configurations. The 128-bit memory bus may also prove restrictive for bandwidth-intensive tasks such as high-resolution texture rendering or large dataset processing, where wider bus designs provide a tangible advantage. Furthermore, the absence of USB-C output makes this card a poor match for users whose display ecosystem relies on USB-C or Thunderbolt connectivity, as they would need to adapt or replace existing hardware to make it work.

Performance:

GPU clock speed	2317 MHz
GPU turbo	2572 MHz
pixel rate	82.3 GPixel/s
floating-point performance	13.17 TFLOPS
texture rate	205.8 GTexels/s
GPU memory speed	2500 MHz
shading units	2560
texture mapping units (TMUs)	80
render output units (ROPs)	32
Has Double Precision Floating Point (DPFP)	✓

The PNY GeForce RTX 5050 Single Fan runs at a base GPU clock of 2317 MHz, boosting up to 2572 MHz under load, with a GPU memory speed of 2500 MHz. Its 2560 shading units work alongside 80 texture mapping units and 32 render output units to deliver a texture rate of 205.8 GTexels/s and a pixel rate of 82.3 GPixel/s. Overall floating-point performance is rated at 13.17 TFLOPS, and the card includes support for Double Precision Floating Point (DPFP), adding versatility for workloads that require higher numerical precision.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	320 GB/s
VRAM	8GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR6 VRAM running across a 128-bit memory bus at an effective speed of 20000 MHz, yielding a maximum memory bandwidth of 320 GB/s. ECC memory support is also included, which helps detect and correct memory errors for workloads where data integrity is a priority.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

This card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, alongside stereoscopic 3D and multi-display technology spanning up to four simultaneous outputs. Intel Resizable BAR is included to allow the CPU broader access to GPU memory, while XeSS (XMX), LHR, and RGB lighting are not present on this model.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, providing four connections in total. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	130W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	16900 million
warranty period	3 years
Has air-water cooling	✕
width	147 mm
height	125 mm

Built on the Blackwell architecture using a 5nm manufacturing process, the GPU integrates 16,900 million transistors and connects via a PCIe 5.0 interface. It has a Thermal Design Power of 130W and relies on air cooling, with no water cooling option included. The card measures 147mm wide and 125mm tall, and cooling is handled entirely through its air-based solution. A 3-year warranty is included, and the product does not feature air-water cooling.

Final Verdict

The PNY GeForce RTX 5050 Single Fan presents a compact, modern entry built on the Blackwell architecture, offering a well-rounded feature set that includes ray tracing, DLSS, ECC memory support, and multi-display output across four connections. Its 5nm design with 16,900 million transistors reflects a technically current foundation, and the 130W TDP keeps power demands manageable for smaller builds. That said, its single-fan cooling and 128-bit memory bus do impose real-world ceiling on sustained heavy workloads and bandwidth-intensive tasks, meaning it is best understood as a card suited to moderate use cases rather than the most demanding scenarios. For users prioritizing a compact form factor with access to current-generation rendering features and solid connectivity options, it represents a coherent and practical choice within its intended scope.
