PNY GeForce RTX 5060 Dual Fan

Manufacturer: PNY

The PNY GeForce RTX 5060 Dual Fan is a graphics card based on NVIDIA's Blackwell architecture, manufactured on a 5 nm process with 21,900 million transistors. It operates at a base clock of 2280 MHz and reaches a turbo speed of 2497 MHz, delivering 19.18 TFLOPS of floating-point performance alongside a pixel rate of 119.9 GPixel/s and a texture rate of 299.6 GTexels/s. The card has a TDP of 145W and connects via PCIe 5.0, fitting into a compact 200 × 120 mm footprint.

On the memory side, the card carries 8GB of GDDR7 VRAM on a 128-bit bus running at an effective speed of 28,000 MHz, yielding up to 448 GB/s of bandwidth with ECC support included. Display output is handled through one HDMI 2.1b port and three DisplayPort connectors, supporting up to four simultaneous displays. Feature support spans DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, DLSS, Intel Resizable BAR, and stereoscopic 3D, while the card carries a 3-year warranty from PNY.

Pros

Supports up to four simultaneous displays through one HDMI 2.1b port and three DisplayPort outputs
GDDR7 memory delivers an effective speed of 28,000 MHz and 448 GB/s of bandwidth on a 128-bit bus
Includes hardware ray tracing and DLSS support for compatible rendering workloads
ECC memory support adds a layer of data integrity for error-sensitive tasks
Compatible with Intel Resizable BAR, allowing the CPU to access the full GPU frame buffer
Compact dimensions of 200 x 120 mm make it suitable for smaller form factor builds

Cons

128-bit memory bus width is relatively narrow, which can limit memory throughput headroom
Only 8GB of VRAM may be restrictive for high-resolution textures or memory-intensive workloads
No USB-C output, limiting direct connectivity to certain modern displays and devices
Does not include water cooling support, relying solely on air cooling for thermal management
No RGB lighting for users who factor case aesthetics into their build

Who is this for?

This card is well suited to users building a compact desktop system who need capable rasterization performance alongside modern features like hardware ray tracing and DLSS. Its four-display output configuration — one HDMI 2.1b and three DisplayPort connectors — makes it a practical choice for multi-monitor productivity setups. The inclusion of ECC memory support and Double Precision Floating Point also means it can serve users running compute or data-integrity-sensitive workloads alongside everyday graphics tasks. Its 200 x 120 mm footprint fits comfortably in smaller cases where larger cards would not.

Who is this NOT for?

Users targeting high-resolution gaming or professional visualization workloads with large texture assets may find the 8GB VRAM ceiling limiting, particularly as scene complexity and resolution increase. The 128-bit memory bus, while paired with fast GDDR7, leaves less headroom for sustained bandwidth-heavy workloads compared to wider-bus configurations. Additionally, the absence of water cooling support means users building into thermally constrained environments or seeking near-silent operation under sustained load will need to rely entirely on the card's air cooling solution. Those requiring USB-C display output for direct connection to certain modern monitors will also need an adapter.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2497 MHz
pixel rate	119.9 GPixel/s
floating-point performance	19.18 TFLOPS
texture rate	299.6 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The Performance section of the PNY GeForce RTX 5060 Dual Fan centers on a base GPU clock of 2280 MHz that boosts up to 2497 MHz, supported by 3,840 shading units, 120 texture mapping units, and 48 render output units. These combine to deliver a texture rate of 299.6 GTexels/s and a pixel rate of 119.9 GPixel/s, while overall compute throughput reaches 19.18 TFLOPS of floating-point performance. GPU memory operates at 1750 MHz, and the card includes support for Double Precision Floating Point (DPFP), broadening its suitability beyond purely graphics-oriented workloads.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The PNY GeForce RTX 5060 Dual Fan is equipped with 8GB of GDDR7 VRAM running at an effective speed of 28,000 MHz across a 128-bit memory bus, resulting in a maximum memory bandwidth of 448 GB/s. The card also supports ECC memory, which helps detect and correct data errors during operation.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The PNY GeForce RTX 5060 Dual Fan supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. It includes hardware-level ray tracing, DLSS, and stereoscopic 3D support, while XeSS (XMX) is not present. Multi-display technology is supported across up to four simultaneous displays, and the card is compatible with Intel Resizable BAR for improved CPU-to-GPU data throughput. LHR and RGB lighting are not featured on this model.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The PNY GeForce RTX 5060 Dual Fan offers a total of four video outputs: one HDMI 2.1b port and three DisplayPort connectors. There are no USB-C, DVI, or mini DisplayPort outputs on this card.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
warranty period	3 years
Has air-water cooling	✕
width	200 mm
height	120 mm

The PNY GeForce RTX 5060 Dual Fan is built on the Blackwell architecture, fabricated using a 5 nm process with 21,900 million transistors, and connects via PCIe 5.0. It carries a TDP of 145W and relies on air cooling, as water cooling is not supported. The card measures 200 mm in width and 120 mm in height, and does not include a water-cooling solution. PNY backs it with a 3-year warranty.

Final Verdict

The PNY GeForce RTX 5060 Dual Fan presents a well-defined specification set built around NVIDIA's Blackwell architecture, combining modern feature support — ray tracing, DLSS, Intel Resizable BAR, and ECC memory — with a compact physical footprint that suits space-conscious builds. Its GDDR7 memory delivering 448 GB/s of bandwidth gives it a strong foundation for its class, and the four-display output configuration adds genuine versatility for multi-monitor users. That said, the 8GB VRAM capacity and 128-bit bus mean it is best matched to moderate workloads rather than the most demanding high-resolution or memory-intensive scenarios. Overall, this card is a focused option for users who prioritize modern feature compatibility, compute reliability, and compact form factor over raw memory capacity headroom.
