PNY GeForce RTX 5060 OC Dual Fan

Manufacturer: PNY

The PNY GeForce RTX 5060 OC Dual Fan is a desktop graphics card built on NVIDIA's Blackwell architecture, manufactured using a 5nm process and housing 21.9 billion transistors. It ships with 8GB of GDDR7 memory across a 128-bit bus, delivering an effective memory speed of 28,000 MHz and a peak bandwidth of 448 GB/s. The card runs at a base clock of 2,280 MHz with a boost target of 2,535 MHz, and its compact 200 × 120 mm footprint keeps the thermal design power at a rated 145W.

On the feature side, the RTX 5060 OC supports DirectX 12 Ultimate and OpenGL 4.6, along with hardware ray tracing and DLSS, making those capabilities available without additional configuration. Display output is handled through one HDMI 2.1b port and three DisplayPort connectors, allowing up to four monitors simultaneously. The card connects via PCIe 5.0, supports Intel Resizable BAR, and carries ECC memory support alongside Double Precision Floating Point. A three-year warranty is included, and the card does not feature RGB lighting or liquid cooling.

Pros

Supports up to four displays simultaneously through a combination of one HDMI 2.1b port and three DisplayPort outputs
The compact 200 × 120 mm footprint makes it suitable for smaller form factor builds
GDDR7 memory delivers a peak bandwidth of 448 GB/s across a 128-bit bus
Hardware ray tracing and DLSS are both supported without additional configuration
Intel Resizable BAR support enables optimized data transfers between CPU and GPU
ECC memory support adds data integrity for workloads that require error correction

Cons

The 128-bit memory bus width is narrow for a card in this category, which constrains memory bandwidth scaling
Only 8GB of VRAM may be limiting for memory-intensive workloads
No USB-C display output is available
Liquid cooling is not included or supported, leaving thermal management entirely dependent on the air-cooling solution
XeSS (XMX) is not supported, restricting upscaling options to DLSS only

Who is this for?

This card is a solid fit for users building compact desktop systems, given its 200 × 120 mm footprint and 145W TDP that keeps power draw manageable. Its support for DLSS and hardware ray tracing makes it well-suited for gamers who want access to modern rendering features without requiring a large chassis or high-capacity power supply. The four-display output capability also makes it a practical choice for multi-monitor productivity setups, and ECC memory support extends its relevance to users running workloads where data integrity matters.

Who is this NOT for?

Users working with memory-intensive applications such as high-resolution texture work, large 3D scenes, or AI inference tasks that demand substantial VRAM will likely find the 8GB limit a constraint. The 128-bit memory bus also means that memory bandwidth, while aided by GDDR7 speeds, cannot scale as freely as wider-bus configurations, which may frustrate users pushing demanding workloads at higher resolutions. Additionally, those who rely on USB-C display connectivity or prefer liquid cooling options will need to look elsewhere, as neither is supported on this model.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2535 MHz
pixel rate	121.7 GPixel/s
floating-point performance	19.47 TFLOPS
texture rate	304.2 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The PNY GeForce RTX 5060 OC Dual Fan operates at a base clock of 2,280 MHz with a boost frequency of 2,535 MHz, backed by a GPU memory speed of 1,750 MHz. It delivers 19.47 TFLOPS of floating-point performance, alongside a texture rate of 304.2 GTexels/s and a pixel rate of 121.7 GPixel/s. The card's shader configuration consists of 3,840 shading units, 120 texture mapping units, and 48 render output units, providing the underlying hardware resources that drive its throughput figures. Double Precision Floating Point is also supported.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus, achieving an effective memory speed of 28,000 MHz and a maximum bandwidth of 448 GB/s. ECC memory support is included, adding a layer of data integrity for workloads that benefit from error correction.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Hardware ray tracing and DLSS are both supported, as is stereoscopic 3D, while XeSS (XMX) is not present. Multi-display output is supported across up to four screens, and Intel Resizable BAR is available for optimized CPU-to-GPU data transfers. LHR is not implemented, and the card does not include RGB lighting.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, totaling four video connectors. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
warranty period	3 years
Has air-water cooling	✕
width	200 mm
height	120 mm

Built on the Blackwell architecture using a 5nm manufacturing process, the GPU integrates 21,900 million transistors and connects to the system via PCIe 5.0. It carries a rated TDP of 145W and measures 200 × 120 mm, with cooling handled entirely by air — liquid cooling is not included. A three-year warranty is provided, and the card does not feature water cooling of any kind.

Final Verdict

The PNY GeForce RTX 5060 OC Dual Fan is a compact, moderately powered graphics card that brings Blackwell architecture and GDDR7 memory technology into a physically restrained package. Its support for hardware ray tracing, DLSS, and DirectX 12 Ultimate ensures access to current-generation rendering features, while the four-display output and Intel Resizable BAR support add practical versatility for both gaming and productivity configurations. The 8GB VRAM ceiling and 128-bit bus do impose real limits on how far the card can be pushed in demanding scenarios, so users with heavier workload requirements should weigh those constraints carefully. For those building space-conscious systems who want modern feature support without high power demands, this card represents a well-rounded, technically current option within its defined scope.
