ASRock X870 Taichi Creator

Name: ASRock X870 Taichi Creator
Brand: ASRock
SKU: 7826

Manufacturer: ASRock

The ASRock X870 Taichi Creator is an ATX form factor motherboard designed around AMD's AM5 socket and the X870 chipset. It ships with Wi-Fi 7 (802.11be) support alongside Bluetooth 5.4, making it well-suited for builds where wireless connectivity is a priority. The board includes RGB lighting, a dual BIOS setup, and an easy CMOS reset mechanism, backed by a three-year warranty.

On the memory side, the board provides four DDR5 slots across two channels, supporting up to 256GB with overclocked speeds reaching 8000 MHz. Expansion is handled by two PCIe 5.0 x16 slots and one PCIe 3.0 x16 slot, while storage options include four M.2 sockets and four SATA 3 connectors with RAID 0, 1, and 10 support. The rear I/O offers two Thunderbolt 4 ports, two USB 4 40Gbps ports, dual RJ45 LAN ports, and an HDMI 2.1 output, complemented by a 7.1-channel audio solution with a 130 dB signal-to-noise ratio.

Pros

Four M.2 sockets provide substantial high-speed storage expansion without relying on older SATA connections
Two Thunderbolt 4 and two USB 4 40Gbps ports offer high-bandwidth connectivity for demanding peripherals
Wi-Fi 7 support ensures the board is ready for the latest wireless networking standards
Dual BIOS configuration adds a layer of resilience against failed firmware updates
Seven fan headers give meaningful control over system cooling across multiple zones
A 130 dB signal-to-noise ratio on the onboard DAC indicates a clean audio output for a motherboard-level solution

Cons

No PCIe 4.0 x16 slot available, limiting flexibility when mixing expansion cards of different generations
ECC memory is not supported, which rules out use in workloads requiring error-correcting RAM
Only two analog audio connectors on the rear panel may be insufficient for multi-output audio setups
No USB 3.2 Gen 2 or Gen 1 ports in USB-C form factor on the rear I/O, despite having USB Type-C connectivity only through Thunderbolt 4
RAID 5 and RAID 0+1 are not supported, narrowing storage redundancy options

Who is this for?

This board is well-matched for enthusiast desktop builders and content creators working on the AM5 platform who need substantial connectivity and storage headroom. The four M.2 sockets, two PCIe 5.0 x16 slots, and dual Thunderbolt 4 ports make it a strong fit for users running multiple fast storage drives alongside high-bandwidth peripherals or capture cards. The inclusion of Wi-Fi 7 and Bluetooth 5.4 alongside dual RJ45 ports also suits setups where both wired and wireless networking are in active use, and the seven fan headers make it practical for thermally demanding builds with complex cooling arrangements.

Who is this NOT for?

Users who require ECC memory support for error-sensitive workloads such as scientific computing or certain professional data applications will find this board unsuitable, as that capability is absent. It is also a poor fit for anyone needing RAID 5 configurations for larger storage redundancy arrays, since only RAID 0, 1, and 10 are supported. Additionally, the lack of USB 3.2 Gen 2 USB-C rear ports — with USB-C access limited to Thunderbolt 4 — may frustrate users who rely on a wider range of USB-C devices that do not leverage the Thunderbolt protocol.

General info:

CPU socket	AM5
chipset	X870
form factor	ATX
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Has Bluetooth	✓
Bluetooth version	5.4
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✓
Has dual BIOS	✓
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	244 mm
width	305 mm
Has integrated CPU	✕

The ASRock X870 Taichi Creator is built around the AM5 socket with X870 chipset compatibility and follows the standard ATX form factor, measuring 305 mm wide and 244 mm tall. It accommodates a single CPU and does not include an integrated processor or integrated graphics. Wireless connectivity spans Wi-Fi 4 through Wi-Fi 7 (802.11be), and Bluetooth 5.4 is also present, though aptX is not supported. The board outputs video via HDMI 2.1 and features RGB lighting for visual customization. Practical usability is aided by easy overclocking support, a dual BIOS configuration, and a straightforward CMOS reset option. ASRock backs the board with a three-year warranty.

Memory:

maximum memory amount	256GB
overclocked RAM speed	8000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

The board supports DDR5 memory across four slots arranged in a dual-channel configuration, with a maximum capacity of 256GB. Overclocked RAM speeds can reach 8000 MHz, providing headroom for enthusiast memory kits. ECC memory is not supported on this board.

Ports:

USB 3.2 Gen 2 ports (USB-A)	2
USB 3.2 Gen 1 ports (USB-A)	6
USB 3.2 Gen 2 ports (USB-C)	0
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	2
USB 3.2 Gen 2x2 ports	0
USB 4 40Gbps ports	2
USB 4 20Gbps ports	0
Thunderbolt 4 ports	2
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	0
RJ45 ports	2
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The rear I/O offers a well-rounded port selection, anchored by two Thunderbolt 4 ports and two USB 4 40Gbps ports, all of which are USB Type-C. For USB-A connectivity, there are two USB 3.2 Gen 2 ports and six USB 3.2 Gen 1 ports, along with two USB 2.0 ports. Video output is handled solely by an HDMI connector, as DisplayPort, DVI, and VGA outputs are absent. Networking is covered by two RJ45 ports, and there are no eSATA or PS/2 ports on this board.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	4
USB 3.2 Gen 2x2 ports (through expansion)	1
USB 2.0 ports (through expansion)	6
SATA 3 connectors	4
fan headers	7
USB 3.0 ports (through expansion)	4
M.2 sockets	4
Has TPM connector	✕
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

Internal connectivity is well-provisioned, with four M.2 sockets and four SATA 3 connectors available for storage expansion, while SATA 2, U.2, and mSATA connectors are absent. USB expansion headers include four USB 3.2 Gen 1 ports, four USB 3.0 ports, one USB 3.2 Gen 2x2 port, and six USB 2.0 ports accessible through internal connectors. Cooling is supported by seven fan headers in total. There is no TPM connector on this board.

Expansion slots:

PCIe 4.0 x16 slots	0
PCIe 5.0 x16 slots	2
PCIe 3.0 x16 slots	1
PCIe x1 slots	0
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	0
PCIe x8 slots	0

The board provides three full-length expansion slots in total: two PCIe 5.0 x16 slots for high-bandwidth add-in cards and one PCIe 3.0 x16 slot for additional expansion. There are no PCIe 4.0, PCIe 2.0, PCIe x1, PCIe x4, PCIe x8, or legacy PCI slots present.

Audio:

Signal-to-Noise ratio (DAC)	130 dB
audio channels	7.1
Has S/PDIF Out port	✓
audio connectors	2

The onboard audio solution supports 7.1-channel output and delivers a DAC signal-to-noise ratio of 130 dB, indicating a clean audio signal with minimal background noise. Two analog audio connectors are available on the rear panel, and an S/PDIF Out port is included for digital audio passthrough to external receivers or DACs.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✕
Supports RAID 0	✓
Supports RAID 0+1	✕

The board supports RAID 0, RAID 1, and RAID 10 configurations for flexible storage setup, whether the priority is performance, redundancy, or a combination of both. RAID 5 and RAID 0+1 are not supported.

Final Verdict

The ASRock X870 Taichi Creator is a feature-dense ATX motherboard that covers a wide range of demanding desktop use cases on the AM5 platform. Its combination of two PCIe 5.0 x16 slots, four M.2 sockets, and dual Thunderbolt 4 ports positions it firmly in the enthusiast and content creation space, where connectivity depth and storage expandability matter. Wi-Fi 7, dual LAN, and a 130 dB onboard DAC round out a specification set that leaves little wanting for most high-end builds, though users with specific needs around ECC memory or advanced RAID configurations will want to look elsewhere. For those building a capable, well-connected AM5 system without those niche requirements, the X870 Taichi Creator presents a thorough and well-considered specification package.
