Asus TUF Gaming B650E-E Wi-Fi

Name: Asus TUF Gaming B650E-E Wi-Fi
Brand: Asus
SKU: 5435

Manufacturer: Asus

The Asus TUF Gaming B650E-E Wi-Fi motherboard is designed for gamers and PC builders, featuring an AM5 CPU socket and support for Wi-Fi 6E. With a robust ATX form factor, this motherboard is built to accommodate high-performance components. It also includes RGB lighting to enhance the aesthetic appeal of your build.

For memory, the board supports up to 256GB of DDR5 RAM, with overclocked speeds reaching 8000 MHz. It has four memory slots and dual-channel configuration. Connectivity options include multiple USB ports, HDMI 2.1, and DisplayPort outputs, along with a total of six fan headers for cooling. Storage-wise, it supports several RAID configurations, including RAID 0, 1, 5, and 10.

Pros

Supports up to 256GB of DDR5 RAM for high memory capacity.
Includes multiple expansion options with both PCIe 5.0 and PCIe 4.0 x16 slots.
Offers flexible storage configurations with support for RAID 0, 1, 5, and 10.
Comes with RGB lighting for customizable aesthetics.
Supports Wi-Fi 6E for modern wireless connectivity.

Cons

Does not support ECC memory, limiting its use in error-sensitive applications.
Lacks support for Thunderbolt ports, limiting high-speed peripheral connectivity.
Does not have an S/PDIF Out port for digital audio output.
No integrated graphics, requiring a discrete GPU for display.
Does not support RAID 0+1, which could limit some mirrored/striped storage setups.

Who is this for?

The Asus TUF Gaming B650E-E Wi-Fi motherboard is well-suited for gamers and PC builders looking for high-speed performance and future-proof features. It offers PCIe 5.0 and PCIe 4.0 x16 slots for expansion, making it ideal for users who want to install the latest graphics cards or other high-bandwidth peripherals. Additionally, its support for RAID 0, 1, 5, and 10 provides flexible storage options, while its Wi-Fi 6E capability ensures fast, modern wireless connectivity for a seamless gaming experience.

Who is this NOT for?

This motherboard may not be ideal for users who require highly reliable error-correcting memory, as it does not support ECC memory. Furthermore, users looking for advanced audio or video output options may be disappointed, as it lacks an S/PDIF Out port and does not include integrated graphics. Additionally, those seeking a more extensive range of high-speed connectivity options may find the absence of Thunderbolt ports limiting.

General info:

CPU socket	AM5
chipset	B650
form factor	ATX
release date	June 2025
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Has Bluetooth	✓
Bluetooth version	5.3
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✕
Has dual BIOS	✕
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	244 mm
width	305 mm
Has integrated CPU	✕

The Asus TUF Gaming B650E-E Wi-Fi motherboard is equipped with an AM5 CPU socket and supports the B650 chipset. Its ATX form factor ensures compatibility with a wide range of PC builds. The board supports Wi-Fi 6E, offering a variety of wireless standards, from Wi-Fi 4 to the latest Wi-Fi 6E, and also features Bluetooth 5.3 for seamless wireless connectivity. While it lacks integrated graphics and a built-in CPU, it includes RGB lighting for a customizable aesthetic and makes overclocking easy for performance enthusiasts. The motherboard also comes with a 3-year warranty.

Memory:

maximum memory amount	256GB
overclocked RAM speed	8000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

The Asus TUF Gaming B650E-E Wi-Fi motherboard supports up to 256GB of DDR5 memory, allowing for ample capacity in demanding setups. With four memory slots and dual-channel support, this board is designed to handle high-performance RAM, including speeds of up to 8000 MHz when overclocked. However, it does not support ECC memory, making it less suitable for error-sensitive applications.

Ports:

USB 3.2 Gen 2 ports (USB-A)	1
USB 3.2 Gen 1 ports (USB-A)	3
USB 3.2 Gen 2 ports (USB-C)	1
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	3
USB 3.2 Gen 2x2 ports	0
USB 4 40Gbps ports	0
USB 4 20Gbps ports	0
Thunderbolt 4 ports	0
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	1
RJ45 ports	1
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The Asus TUF Gaming B650E-E Wi-Fi motherboard offers a wide range of connectivity options, including USB Type-C support and a total of four USB-A ports, with one of them being USB 3.2 Gen 2. It also includes an HDMI output and a DisplayPort output for video connectivity, alongside an RJ45 port for network connectivity. However, it does not feature Thunderbolt, eSATA, or VGA connectors, and lacks USB 4.0 support.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	2
USB 3.2 Gen 2x2 ports (through expansion)	1
USB 2.0 ports (through expansion)	4
SATA 3 connectors	4
fan headers	6
USB 3.0 ports (through expansion)	2
M.2 sockets	3
Has TPM connector	✕
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

The Asus TUF Gaming B650E-E Wi-Fi motherboard includes a range of connectors to enhance system expandability. It offers three M.2 sockets for fast storage, along with four SATA 3 connectors for additional drives. The board also provides six fan headers for comprehensive cooling, and multiple USB expansion options, including two USB 3.2 Gen 1 connectors, one USB 3.2 Gen 2x2 connector, and four USB 2.0 ports. It does not support TPM, mSATA, or U.2 connectors.

Expansion slots:

PCIe 4.0 x16 slots	1
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	0
PCIe x1 slots	1
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x8 slots	0

The Asus TUF Gaming B650E-E Wi-Fi motherboard offers a versatile selection of expansion slots, including one PCIe 5.0 x16 slot and one PCIe 4.0 x16 slot for high-bandwidth devices. It also features one PCIe x1 slot for smaller expansion cards. This board does not support older PCIe versions such as PCIe 2.0 or PCIe 3.0 x16, nor does it include any PCI or PCIe x8 slots.

Audio:

audio channels	7.1
Has S/PDIF Out port	✕
audio connectors	3

The Asus TUF Gaming B650E-E Wi-Fi motherboard features 7.1 audio channels, delivering immersive sound quality for a wide range of audio setups. It includes three audio connectors for flexible speaker or headphone connections but does not include an S/PDIF Out port for digital audio output.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✓
Supports RAID 0	✓
Supports RAID 0+1	✕

The Asus TUF Gaming B650E-E Wi-Fi motherboard supports a variety of RAID configurations, including RAID 0, 1, 5, and 10, allowing for flexible storage setups. However, it does not support the RAID 0+1 configuration, offering fewer options for certain types of mirrored or striped setups.

Final Verdict

The Asus TUF Gaming B650E-E Wi-Fi motherboard offers solid performance and future-proofing for gamers and PC enthusiasts. With support for PCIe 5.0, RAID 0, 1, 5, and 10, and Wi-Fi 6E, it provides the necessary features for modern gaming setups and high-speed storage. While it lacks certain features like Thunderbolt ports and ECC memory support, its robust expansion options and advanced connectivity make it a reliable choice for users seeking a high-performance, well-rounded motherboard for their builds.
