Asus TUF Gaming GeForce RTX 5060 OC Edition

Name: Asus TUF Gaming GeForce RTX 5060 OC Edition
Brand: Asus
SKU: 3916

Manufacturer: Asus

The Asus TUF Gaming GeForce RTX 5060 OC Edition is a mid-range graphics card built on NVIDIA's Blackwell architecture, targeting gamers who want modern feature support without stepping into flagship territory. Manufactured on a 5 nm process with 21.9 billion transistors, it ships with a factory-overclocked boost clock of 2640 MHz, sitting above the standard reference specification. RGB lighting and a multi-display setup supporting up to four screens round out its feature set for both gaming and productivity arrangements.

On the memory side, the card carries 8GB of GDDR7 VRAM across a 128-bit bus, delivering an effective memory speed of 28000 MHz and a peak bandwidth of 448 GB/s. Its 3840 shading units are paired with 120 texture mapping units and 48 ROPs, yielding a texture rate of 316.8 GTexels/s. The card carries a 145W TDP and connects via PCIe 5.0, while its output options include one HDMI 2.1b port and three DisplayPort connectors. Hardware-level ray tracing, DLSS support, DirectX 12 Ultimate compliance, and Intel Resizable BAR compatibility are all present, alongside ECC memory support and Double Precision Floating Point capability.

Pros

Supports up to four simultaneous displays, making it well-suited for multi-monitor setups
GDDR7 memory delivers an effective speed of 28000 MHz and 448 GB/s of bandwidth, which is notably high for a 128-bit bus configuration
Hardware ray tracing and DLSS support are both present, enabling modern rendering techniques in compatible titles
PCIe 5.0 connectivity ensures the card is compatible with current-generation motherboard platforms without bandwidth constraints
RGB lighting is built in, allowing visual customization within a system build
ECC memory support adds a layer of data reliability useful for compute-adjacent workloads

Cons

The 128-bit memory bus is relatively narrow and may limit sustained throughput in bandwidth-intensive scenarios
VRAM capacity is limited to 8GB, which can be restrictive in memory-heavy workloads or high-resolution texture scenarios
No USB-C output is available, limiting direct connection to displays or devices that rely on that interface
Water cooling is not supported, leaving air cooling as the only thermal management option
A card width of 302 mm may not fit comfortably in compact or smaller mid-tower cases

Who is this for?

This card is a solid fit for gamers who want access to hardware ray tracing and DLSS in modern titles without stepping into high-end GPU territory. Its support for up to four displays simultaneously also makes it a practical choice for users who need a multi-monitor desktop setup for productivity or sim-racing environments. The combination of PCIe 5.0 compatibility and GDDR7 memory technology means it slots naturally into current-generation builds, and the inclusion of ECC memory support gives it some utility for users running light compute or creative workloads alongside gaming.

Who is this NOT for?

Users working with high-resolution textures, large 3D scenes, or memory-intensive rendering tasks may find the 8GB VRAM ceiling a limiting factor, as such workloads can exhaust that capacity relatively quickly. The 128-bit memory bus, while partially offset by GDDR7 speeds, makes this card less suited for tasks that demand sustained, high-bandwidth data throughput. Additionally, those building in compact small-form-factor cases should be aware of the 302 mm card length, and anyone requiring a USB-C display output will find that option absent here.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2640 MHz
pixel rate	126.7 GPixel/s
floating-point performance	20.28 TFLOPS
texture rate	316.8 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The card operates at a base GPU clock of 2280 MHz, rising to a boost frequency of 2640 MHz under load, while the GPU memory runs at 1750 MHz. Its 3840 shading units work alongside 120 texture mapping units and 48 render output units, producing a texture rate of 316.8 GTexels/s and a pixel rate of 126.7 GPixel/s. Overall floating-point throughput reaches 20.28 TFLOPS, and the chip also supports Double Precision Floating Point operations, adding versatility beyond standard gaming workloads.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus, reaching an effective memory speed of 28000 MHz and a peak bandwidth of 448 GB/s. ECC memory support is included, which helps maintain data integrity during computation-heavy tasks.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of modern graphics and compute APIs. Hardware ray tracing and DLSS are both present, while stereoscopic 3D and multi-display technology are also supported, with up to four displays connectable simultaneously. Intel Resizable BAR is enabled for improved CPU-to-GPU data throughput, and RGB lighting is built in. XeSS (XMX) and LHR are not featured on this card.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, giving a total of four video connections. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	302 mm
height	133.5 mm

Built on the Blackwell architecture and fabricated using a 5 nm process, the GPU integrates 21,900 million transistors and connects to the system via PCIe 5.0. It carries a rated TDP of 145W and relies solely on air cooling, with no water-cooling support. The card measures 302 mm in width and 133.5 mm in height.

Final Verdict

The Asus TUF Gaming GeForce RTX 5060 OC Edition is a well-specified card for users building or upgrading a current-generation gaming system, bringing Blackwell architecture, PCIe 5.0 support, and GDDR7 memory with 448 GB/s of bandwidth to a mainstream form factor. Its hardware ray tracing, DLSS support, and four-display capability give it genuine versatility across gaming and light creative use, while ECC memory compatibility adds a degree of reliability for compute-adjacent tasks. The 8GB VRAM and 128-bit bus do place a ceiling on how far it can stretch in demanding, memory-heavy scenarios, but within its intended scope it delivers a feature set that aligns well with modern platform requirements. For users seeking a capable, feature-complete card on a current-gen platform without moving into high-end GPU territory, this TUF Gaming model makes a coherent and technically grounded choice.
