MSI GeForce RTX 5060 Ti Ventus 2X Plus 16GB

Manufacturer: MSI

The MSI GeForce RTX 5060 Ti Ventus 2X Plus is a mid-range graphics card from MSI based on NVIDIA's Blackwell architecture. It carries a compact dual-fan cooler design within a 227 mm × 127 mm footprint and operates within a 180W TDP envelope, making it suitable for a range of standard ATX builds. The card connects via PCIe 5.0 and supports up to four displays simultaneously through its combination of one HDMI 2.1b port and three DisplayPort outputs.

On the memory side, the card is equipped with 16GB of GDDR7 VRAM running across a 128-bit bus at an effective speed of 28,000 MHz, delivering up to 448 GB/s of bandwidth. Its GPU features 4,608 shading units, 144 texture mapping units, and 48 render output units, with a base clock of 2,407 MHz and a boost of 2,572 MHz translating to 23.7 TFLOPS of floating-point throughput. The card supports DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, and DLSS, along with Intel Resizable BAR and ECC memory support. It is manufactured on a 5 nm process node and contains approximately 21.9 billion transistors.

Pros

16GB of GDDR7 VRAM on a 128-bit bus delivers 448 GB/s of memory bandwidth, which is a substantial amount for this memory interface width
Supports up to four simultaneous displays through a practical mix of one HDMI 2.1b and three DisplayPort outputs
Ray tracing and DLSS support are both present, enabling access to modern rendering and upscaling pipelines
ECC memory support adds data integrity checking, useful for compute-oriented or reliability-sensitive workloads
Double Precision Floating Point (DPFP) support broadens the card's usability beyond purely graphical tasks
At 227 mm x 127 mm with a 180W TDP, the card maintains a relatively compact and modest power footprint for its specification tier

Cons

The 128-bit memory bus width is narrow for a card with this level of compute throughput, which may create bottlenecks in memory-intensive scenarios
No USB-C output is available, limiting connectivity options for users with USB-C or Thunderbolt-dependent displays
RGB lighting is absent, which may be a drawback for users building visually themed systems
Water cooling is not supported, leaving air cooling as the only thermal solution regardless of use case or environment
XeSS (XMX) is not supported, restricting upscaling options to DLSS only

Who is this for?

This card is well-matched to users who prioritize VRAM capacity and memory bandwidth in their workloads, making it a practical choice for those working with large textures, high-resolution assets, or GPU-accelerated compute tasks that benefit from ECC memory and DPFP support. Its compact 227 mm × 127 mm footprint and 180W TDP make it a reasonable fit for mid-tower and smaller form-factor builds where power delivery and physical space are considerations. Users who rely on multi-display setups of up to four screens will find the port configuration — combining HDMI 2.1b with three DisplayPort outputs — well suited to productivity-oriented or content-heavy desktop environments.

Who is this NOT for?

Users who require a wider memory bus for sustained high-bandwidth workloads will find the 128-bit interface a limiting factor, particularly in scenarios involving large framebuffers or memory-intensive parallel compute tasks where bus width directly affects throughput. The absence of water cooling support makes this card less suitable for users running thermally demanding workloads in confined or high-ambient-temperature environments where more aggressive cooling solutions would be preferable. Additionally, those with displays or docking setups that rely on USB-C connectivity will need to look elsewhere, as the card provides no USB-C output whatsoever.

Performance:

GPU clock speed	2407 MHz
GPU turbo	2572 MHz
pixel rate	123.5 GPixel/s
floating-point performance	23.7 TFLOPS
texture rate	370.4 GTexels/s
GPU memory speed	1750 MHz
shading units	4608
texture mapping units (TMUs)	144
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The MSI GeForce RTX 5060 Ti Ventus 2X Plus runs at a base GPU clock of 2,407 MHz, boosting up to 2,572 MHz under load, while the memory operates at 1,750 MHz. Its 4,608 shading units are paired with 144 texture mapping units and 48 render output units, producing a texture rate of 370.4 GTexels/s and a pixel rate of 123.5 GPixel/s. Overall floating-point throughput sits at 23.7 TFLOPS, and the card also includes support for Double Precision Floating Point (DPFP), broadening its applicability to compute-oriented workloads alongside graphics tasks.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	16GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 16GB of GDDR7 VRAM running across a 128-bit memory bus at an effective speed of 28,000 MHz, yielding a maximum memory bandwidth of 448 GB/s. ECC memory support is also included, adding a layer of data integrity protection that can be relevant in compute and professional workloads.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute API requirements. Ray tracing and DLSS are both supported, while XeSS (XMX) is not. Multi-display technology is included with support for up to four simultaneous displays, and stereoscopic 3D is also available. Intel Resizable BAR is supported to allow the CPU broader access to GPU memory, whereas LHR and RGB lighting are absent on this model.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, providing a total of four video connections. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	180W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	227 mm
height	127 mm

Built on the Blackwell architecture and fabricated on a 5 nm process node, the GPU integrates approximately 21,900 million transistors and connects to the host system via PCIe 5.0. It carries a rated TDP of 180W and relies solely on air cooling, with no water cooling option included. The card measures 227 mm in width and 127 mm in height, giving a sense of its physical footprint within a system.

Final Verdict

The MSI GeForce RTX 5060 Ti Ventus 2X Plus 16GB presents a well-rounded specification set anchored by its 16GB of GDDR7 VRAM with 448 GB/s of bandwidth, a combination that gives it genuine headroom for memory-demanding workloads well beyond typical consumer graphics tasks. Built on the Blackwell architecture with DPFP and ECC memory support, it extends its relevance into compute-adjacent scenarios, while features like ray tracing, DLSS, and a four-display output configuration keep it grounded in practical, everyday usability. Its compact dimensions and 180W TDP make integration straightforward in most standard builds, though users with specific needs around memory bus width, cooling flexibility, or USB-C connectivity should weigh those limitations carefully before committing. Overall, this card occupies a clear and coherent position for users who need substantial VRAM and modern feature support within a modest physical and power footprint.
