MSI GeForce RTX 5070 Ti Inspire 3X Plus

Manufacturer: MSI

The MSI GeForce RTX 5070 Ti Inspire 3X Plus is a graphics card from MSI's Inspire series, designed around NVIDIA's Blackwell architecture and manufactured on a 5nm process node. It houses 8,960 shading units alongside 280 texture mapping units and 96 render output units, reflecting a substantial compute configuration across its silicon. The card operates at a base GPU clock of 2,295 MHz, with boost speeds reaching up to 2,452 MHz under load.

On the memory side, the card is equipped with 16GB of GDDR7 VRAM running across a 256-bit bus, delivering an effective memory speed of 28,000 MHz and a maximum bandwidth of 896 GB/s. Floating-point throughput is rated at 43.94 TFLOPS, while the texture rate reaches 686.6 GTexels/s. The card supports DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3.0, ray tracing, and DLSS, and includes Intel Resizable BAR support. For display connectivity, it offers three DisplayPort outputs and one HDMI 2.1b port, supporting up to four displays simultaneously. Its physical dimensions measure 288mm in width and 112mm in height, with a thermal design power of 300W.

Pros

Supports up to four displays simultaneously, making it practical for multi-monitor setups
GDDR7 memory with a 896 GB/s bandwidth ceiling allows substantial data throughput for demanding workloads
ECC memory support adds a layer of data integrity, useful for workloads where accuracy matters
Ray tracing and DLSS are both supported natively, covering two widely used rendering technologies
The 256-bit memory bus paired with 16GB of VRAM provides a solid capacity for high-resolution workloads
Intel Resizable BAR support enables the CPU to access the full GPU memory pool more efficiently

Cons

A 300W TDP places meaningful demands on system power delivery and case airflow
No USB-C output is available, limiting compatibility with certain modern displays and adapters
Water cooling is not supported, leaving thermal management entirely dependent on the air cooler
The card has no RGB lighting, which may not suit users who prefer illuminated builds
No DVI or mini DisplayPort outputs are present, ruling out connectivity with older display hardware

Who is this for?

This card is well-suited to users who work with high-resolution rendering and compute-intensive workloads, given its 43.94 TFLOPS of floating-point throughput, 16GB of GDDR7 VRAM, and ECC memory support — the latter being particularly relevant for tasks where data accuracy is critical. The native support for ray tracing and DLSS, combined with DirectX 12 Ultimate compatibility, makes it a practical fit for demanding real-time graphics workloads. Users who need to drive multiple displays simultaneously will also benefit from the four-output configuration spanning three DisplayPort and one HDMI 2.1b connection.

Who is this NOT for?

This card is not a natural fit for users with constrained system power delivery, as its 300W TDP requires a capable PSU and well-ventilated case — those with compact or low-power builds may find it impractical. Since air-water cooling is not supported, users operating in thermally demanding environments who rely on custom liquid cooling loops will need to look elsewhere. Additionally, the absence of USB-C video output and any DVI or mini DisplayPort connections makes this card unsuitable for users who depend on older display hardware or USB-C-equipped monitors.

Performance:

GPU clock speed	2295 MHz
GPU turbo	2452 MHz
pixel rate	235.4 GPixel/s
floating-point performance	43.94 TFLOPS
texture rate	686.6 GTexels/s
GPU memory speed	1750 MHz
shading units	8960
texture mapping units (TMUs)	280
render output units (ROPs)	96
Has Double Precision Floating Point (DPFP)	✓

The MSI GeForce RTX 5070 Ti Inspire 3X Plus operates at a base GPU clock speed of 2,295 MHz, climbing to 2,452 MHz in turbo mode, underpinning its compute throughput figures of 43.94 TFLOPS for floating-point performance and a texture rate of 686.6 GTexels/s. The card's 8,960 shading units work alongside 280 texture mapping units and 96 render output units, contributing to a pixel rate of 235.4 GPixel/s. GPU memory runs at 1,750 MHz natively, and the card also carries support for Double Precision Floating Point (DPFP), broadening its applicability beyond standard rendering workloads.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	896 GB/s
VRAM	16GB
GDDR version	GDDR7
memory bus width	256-bit
Supports ECC memory	✓

The card is equipped with 16GB of GDDR7 VRAM running across a 256-bit memory bus, reaching an effective memory speed of 28,000 MHz and delivering a maximum memory bandwidth of 896 GB/s. ECC memory support is also present, which helps maintain data integrity during demanding computational tasks.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The MSI GeForce RTX 5070 Ti Inspire 3X Plus supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported natively, alongside stereoscopic 3D and multi-display technology allowing up to four displays to be connected simultaneously. Intel Resizable BAR is included for improved CPU-to-GPU data access, while XeSS (XMX), LHR, and RGB lighting are not features of this card.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's connectivity consists of three DisplayPort outputs and a single HDMI 2.1b port, providing four video outputs in total. There are no USB-C, DVI, or mini DisplayPort connections on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	300W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	45600 million
Has air-water cooling	✕
width	288 mm
height	112 mm

Built on the Blackwell architecture and fabricated using a 5nm process, the card integrates 45,600 million transistors and connects via a PCIe 5 interface. It carries a Thermal Design Power of 300W and relies on air cooling, as water cooling support is not included. Physically, the card measures 288mm in width and 112mm in height.

Final Verdict

The MSI GeForce RTX 5070 Ti Inspire 3X Plus is a well-specified graphics card built around NVIDIA's Blackwell architecture, bringing together a strong compute profile — highlighted by 16GB of GDDR7 VRAM with 896 GB/s of memory bandwidth — alongside broad API support, ray tracing, DLSS, and a flexible four-display output configuration. Its ECC memory support and Intel Resizable BAR inclusion add practical value for users with precision-sensitive workloads. That said, its 300W power requirement and reliance solely on air cooling mean it demands a thoughtfully built system to operate at its best. For users whose setup can accommodate those requirements, this card represents a capable and feature-complete option within its category.
