Palit GeForce RTX 5060 Ti Dual OC 8GB

Name: Palit GeForce RTX 5060 Ti Dual OC 8GB
Brand: Palit
SKU: 1641

Manufacturer: Palit

The Palit GeForce RTX 5060 Ti Dual OC 8GB is a mid-range graphics card based on NVIDIA's Blackwell architecture, manufactured on a 5 nm process with 21,900 million transistors. It operates at a base clock of 2407 MHz and reaches a boost frequency of 2632 MHz, while its RGB lighting and dual-fan cooling setup reflect a design aimed at mainstream desktop builds. The card supports up to four simultaneous displays and comes with Intel Resizable BAR support.

On the memory side, the card is equipped with 8GB of GDDR7 VRAM across a 128-bit bus, delivering an effective memory speed of 28,000 MHz and a maximum bandwidth of 448 GB/s. Floating-point performance is rated at 24.26 TFLOPS, accompanied by a texture rate of 379 GTexels/s and a pixel rate of 126.3 GPixels/s across 4,608 shading units. The card supports DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, and DLSS, and connects via one HDMI 2.1b port and three DisplayPort outputs over a PCIe 5.0 interface.

Pros

Supports DLSS and ray tracing, enabling hardware-accelerated rendering features in compatible applications
GDDR7 memory delivers an effective speed of 28,000 MHz and 448 GB/s of bandwidth over a 128-bit bus
Can drive up to four displays simultaneously through a combination of three DisplayPort and one HDMI 2.1b output
Built on a 5 nm process with 21,900 million transistors, reflecting a dense and modern chip design
ECC memory support adds data integrity for workloads that require it
RGB lighting is included for users who want visual customization in their build

Cons

128-bit memory bus width is relatively narrow, which may limit sustained throughput in memory-intensive scenarios
Only 8GB of VRAM, which can become a constraint in high-resolution or asset-heavy workloads
No USB-C output is available, limiting connectivity options for certain modern displays
Does not support liquid cooling, relying entirely on air cooling to manage its 180W TDP

Who is this for?

This card is a solid fit for desktop users building or upgrading a system for 1080p and 1440p gaming, where its 24.26 TFLOPS of compute performance, DLSS support, and ray tracing capability can be put to practical use. The four-display output — combining three DisplayPort and one HDMI 2.1b connection — also makes it a reasonable choice for multi-monitor productivity setups. Users who need ECC memory support for light compute or data-sensitive workloads will find that feature useful, and those building a visually cohesive system will appreciate the onboard RGB lighting.

Who is this NOT for?

Users working with high-resolution textures, large 3D scenes, or memory-intensive creative applications may find the 8GB VRAM ceiling restrictive, particularly as asset sizes in modern workflows continue to grow. The 128-bit memory bus, while partially offset by GDDR7 speeds, can become a bottleneck in sustained bandwidth-heavy tasks, making this card less suited for demanding professional GPU compute workloads. Additionally, the absence of a USB-C output means users with newer displays or devices that rely on that connection will need to look elsewhere, and the 180W TDP with air-only cooling may not suit compact or thermally constrained enclosures.

Performance:

GPU clock speed	2407 MHz
GPU turbo	2632 MHz
pixel rate	126.3 GPixel/s
floating-point performance	24.26 TFLOPS
texture rate	379 GTexels/s
GPU memory speed	1750 MHz
shading units	4608
texture mapping units (TMUs)	144
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The card runs at a base GPU clock of 2407 MHz with a boost frequency of 2632 MHz, and its 24.26 TFLOPS of floating-point performance is backed by 4,608 shading units and 144 texture mapping units delivering a texture rate of 379 GTexels/s. A pixel rate of 126.3 GPixel/s is handled through 48 render output units, while the GPU memory operates at 1750 MHz. The card also supports Double Precision Floating Point (DPFP), rounding out a performance profile that spans both graphics and compute workloads.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running at an effective speed of 28,000 MHz across a 128-bit memory bus, yielding a maximum memory bandwidth of 448 GB/s. ECC memory support is also included, adding a layer of data integrity for workloads that require it.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, while stereoscopic 3D and multi-display technology are also on board, with up to four displays supported simultaneously. Intel Resizable BAR is included, whereas XeSS (XMX) and LHR are not present. On the aesthetic side, the card features RGB lighting.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of three DisplayPort outputs and one HDMI 2.1b port, totalling four display connections. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	180W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	262.1 mm
height	126.3 mm

Built on the Blackwell architecture using a 5 nm manufacturing process, the GPU integrates 21,900 million transistors and connects via a PCIe 5.0 interface. It carries a Thermal Design Power of 180W and relies solely on air cooling, with no liquid cooling option included. The card measures 262.1 mm in width and 126.3 mm in height.

Final Verdict

The Palit GeForce RTX 5060 Ti Dual OC 8GB brings together a modern Blackwell architecture, GDDR7 memory, and a capable feature set — including ray tracing, DLSS, and multi-display support — into a package clearly aimed at mainstream desktop use. Its 28,000 MHz effective memory speed and 448 GB/s bandwidth help offset the constraints of the 128-bit bus, and the overall specification profile makes it a competent choice for 1080p and 1440p workloads. Where it runs into natural limits — namely VRAM capacity and the absence of USB-C output — users with more demanding or specialized requirements will need to factor those gaps into their decision. For the mainstream desktop builder seeking a feature-rich card built on current-generation technology, this model delivers a well-rounded specification sheet with few surprises.
