Asus Prime GeForce RTX 5060 OC Edition

Name: Asus Prime GeForce RTX 5060 OC Edition
Brand: Asus
SKU: 6309

Manufacturer: Asus

The Asus Prime GeForce RTX 5060 OC Edition is a graphics card based on Nvidia's Blackwell architecture, manufactured on a 5 nm process with 21,900 million transistors. It operates at a base clock of 2280 MHz and reaches a boosted frequency of 2565 MHz, while its 19.7 TFLOPS of floating-point performance reflects the compute capability the GPU delivers under load. The card measures 268.3 mm in length and 120 mm in height, and its 145W TDP gives a clear picture of its thermal requirements.

On the memory side, the card carries 8GB of GDDR7 VRAM across a 128-bit bus, with an effective memory speed of 28000 MHz translating into up to 448 GB/s of bandwidth. It includes 3840 shading units, 120 texture mapping units, and 48 render output units, alongside a texture rate of 307.8 GTexels/s. Feature support covers DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, DLSS, Intel Resizable BAR, and multi-display output across up to four screens via one HDMI 2.1b port and three DisplayPort outputs. RGB lighting is also present on the card.

Pros

Supports ray tracing and DLSS, enabling more visually detailed rendering and frame rate optimization in compatible applications
GDDR7 memory with an effective speed of 28000 MHz and 448 GB/s bandwidth allows fast data throughput for demanding workloads
Three DisplayPort outputs alongside one HDMI 2.1b port allow connection to up to four displays simultaneously
Intel Resizable BAR support enables the CPU to access the full GPU frame buffer, which can improve rendering efficiency
ECC memory support helps detect and correct memory errors, adding a layer of reliability for compute-sensitive tasks
RGB lighting is present for users who want visible customization in their build

Cons

The 128-bit memory bus width is relatively narrow for a card with this level of compute specification, which may limit scalability in memory-intensive scenarios
No USB-C output is available, restricting direct connectivity to displays or devices that rely on that port type
Air-water cooling is not supported, so users are limited to the included air cooling solution with no hybrid cooling option
8GB of VRAM may be a limiting factor in workloads or applications that benefit from larger frame buffers

Who is this for?

This card is well-suited to users building a mid-range gaming or workstation PC who want access to modern rendering features without a large physical footprint. The combination of ray tracing and DLSS support makes it a practical fit for gamers running titles that leverage these technologies, while the 19.7 TFLOPS of floating-point performance and ECC memory support also make it a reasonable choice for users with light compute or content creation workloads. Those looking to drive a multi-monitor setup will also find the four-display output capacity, delivered through three DisplayPort and one HDMI 2.1b port, genuinely useful for productivity-oriented configurations.

Who is this NOT for?

Users working with applications that demand large frame buffers — such as high-resolution texture work, complex 3D scene rendering, or memory-intensive machine learning tasks — may find the 8GB VRAM ceiling over a 128-bit bus a limiting factor as asset sizes scale up. The card is also not a good fit for those seeking liquid or hybrid cooling options, since air-water cooling is not supported, which could be a concern in thermally constrained or high-ambient-temperature environments. Additionally, users who require USB-C display output for specific monitors or devices will need to look elsewhere, as no such port is present on this card.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2565 MHz
pixel rate	123.1 GPixel/s
floating-point performance	19.7 TFLOPS
texture rate	307.8 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The GPU runs at a base clock of 2280 MHz with a turbo frequency of 2565 MHz, and its 19.7 TFLOPS of floating-point performance reflects the card's compute output under sustained workloads. Rasterization throughput is handled by 3840 shading units, 120 texture mapping units delivering a texture rate of 307.8 GTexels/s, and 48 render output units contributing to a pixel rate of 123.1 GPixel/s. GPU memory operates at 1750 MHz, and the card also includes support for Double Precision Floating Point (DPFP), broadening its utility for tasks that require 64-bit compute accuracy.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus, reaching an effective memory speed of 28000 MHz and a maximum memory bandwidth of 448 GB/s. ECC memory support is also present, which helps detect and correct memory errors during operation.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. Ray tracing and DLSS are both supported, while XeSS (XMX) is not present on this card. It also supports stereoscopic 3D, multi-display output across up to four screens, and Intel Resizable BAR for improved CPU-to-GPU data access. LHR is not implemented, and the card includes RGB lighting. AMD SAM is not supported, with Intel Resizable BAR being the available option in that category.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, allowing connections to up to four displays simultaneously. There are no USB-C, DVI, or mini DisplayPort outputs present on this card.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	268.3 mm
height	120 mm

Built on the Blackwell architecture and fabricated using a 5 nm process, the GPU integrates 21,900 million transistors and connects to the system via PCIe 5. It carries a Thermal Design Power of 145W and does not feature air-water cooling. The card measures 268.3 mm in width and 120 mm in height, giving a clear sense of its physical footprint.

Final Verdict

The Asus Prime GeForce RTX 5060 OC Edition is a well-defined mid-range graphics card that brings Nvidia's Blackwell architecture to users who want modern rendering capabilities in a practical package. Its support for ray tracing, DLSS, and DirectX 12 Ultimate, combined with GDDR7 memory and a respectable 19.7 TFLOPS of compute output, gives it a solid foundation for contemporary gaming and light professional workloads. That said, the 8GB VRAM over a 128-bit bus and the absence of liquid cooling options mean it is best matched to users with clearly defined, moderate demands rather than those pushing the upper limits of resolution or memory-heavy applications. For its intended audience, it delivers a coherent and feature-complete specification set that covers the essentials without significant gaps.
