Gigabyte GeForce RTX 5060 Ti Eagle OC Ice 16GB

Name: Gigabyte GeForce RTX 5060 Ti Eagle OC Ice 16GB
Brand: Gigabyte
SKU: 61703

Manufacturer: Gigabyte

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice is a high-performance graphics card designed to deliver excellent gaming and creative application performance. With 16GB of VRAM, it offers solid memory bandwidth and supports advanced technologies like ray tracing and DLSS, making it a reliable choice for demanding tasks.

In terms of technical specifications, the card boasts a 2407 MHz GPU clock speed with a turbo boost up to 2617 MHz. It also offers a memory bandwidth of 448 GB/s, powered by GDDR7 memory, and features 4608 shading units. The card supports multi-display technology, HDMI 2.1b, and DisplayPort outputs, all backed by a 180W TDP and the efficient 5nm Blackwell architecture.

Pros

Supports multi-display technology, allowing for up to 4 connected displays.
Equipped with 16GB of VRAM, providing ample memory for demanding applications and high-resolution textures.
Supports ray tracing, enhancing graphical realism with realistic lighting effects.
Features Intel Resizable BAR, which improves performance in supported systems.
Supports DLSS, enabling improved frame rates and better image quality in compatible games.

Cons

Does not support USB-C, DVI, or mini DisplayPort outputs, limiting some display connection options.
Does not have air-water cooling, potentially limiting cooling efficiency in high-performance scenarios.
The 128-bit memory bus width may restrict memory bandwidth compared to higher-end graphics cards.

Who is this for?

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice is ideal for users who need a powerful graphics card for gaming and creative work, especially with demanding graphical workloads. It excels with its 16GB of VRAM, which is well-suited for handling high-resolution textures and large-scale applications. The support for ray tracing and DLSS ensures enhanced visual quality and performance in supported games, making it a great choice for gamers and content creators looking to maximize their visual experience.

Who is this NOT for?

This graphics card may not be the best choice for users who need extensive display connectivity options or for those who require a higher level of memory bandwidth. The lack of USB-C, DVI, and mini DisplayPort outputs may limit flexibility for users with specific display setups. Additionally, those who require advanced cooling solutions may find its absence of air-water cooling a drawback, especially in high-performance or overclocking scenarios.

Performance:

GPU clock speed	2407 MHz
GPU turbo	2617 MHz
pixel rate	125.6 GPixel/s
floating-point performance	24.12 TFLOPS
texture rate	376.8 GTexels/s
GPU memory speed	1750 MHz
shading units	4608
texture mapping units (TMUs)	144
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The performance of the Gigabyte GeForce RTX 5060 Ti Eagle OC Ice is driven by a 2407 MHz GPU clock speed, with a turbo boost reaching up to 2617 MHz for improved processing power. It features a high pixel rate of 125.6 GPixel/s and a texture rate of 376.8 GTexels/s, ensuring smooth visual rendering. Additionally, the card is capable of delivering 24.12 TFLOPS of floating-point performance, thanks to its 4608 shading units and 144 texture mapping units. The GPU also supports Double Precision Floating Point (DPFP), which enhances its capability for complex calculations.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	16GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice is equipped with 16GB of VRAM, providing ample memory for demanding applications and high-resolution textures. It features an impressive effective memory speed of 28000 MHz and a maximum memory bandwidth of 448 GB/s, ensuring fast data transfer rates. The memory uses the GDDR7 standard with a 128-bit memory bus width and also supports ECC (Error Correction Code) memory for enhanced reliability.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice supports a range of advanced features for a more immersive and flexible experience. It is compatible with DirectX 12 Ultimate, enabling the latest graphics technologies, and supports ray tracing for realistic lighting effects. Additionally, it supports DLSS for improved frame rates and image quality, and can handle up to 4 displays simultaneously, making it suitable for multi-display setups.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice provides a versatile range of ports for connectivity. It includes 1 HDMI 2.1b port and 3 DisplayPort outputs, allowing for flexible display setups. However, it does not feature any USB-C, DVI, or mini DisplayPort outputs, focusing on HDMI and DisplayPort connectivity for high-quality video output.

General info:

GPU architecture	Blackwell
release date	April 2025
Thermal Design Power (TDP)	180W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	215 mm
height	122 mm

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice features the Blackwell GPU architecture, built on a 5 nm semiconductor size for improved efficiency and performance. With a thermal design power (TDP) of 180W, it balances power consumption and performance. The card also supports PCIe 5.0, offering faster data transfer speeds, and is equipped with 21.9 billion transistors. Its dimensions are 215 mm in width and 122 mm in height, and it does not include air-water cooling systems.

Final Verdict

The Gigabyte GeForce RTX 5060 Ti Eagle OC Ice is a strong contender for gamers and content creators seeking high performance with features like 16GB of VRAM and ray tracing support. Its ability to handle demanding graphical tasks makes it a great choice for immersive gaming and visual work, while the support for DLSS enhances performance in compatible titles. However, its limited display connectivity options and lack of advanced cooling solutions may limit its appeal for users with specific requirements. Overall, it's a reliable option for users focused on graphics performance, though those with particular display or cooling needs may want to explore other options.
