Gigabyte H810M Gaming Wi-Fi6

Name: Gigabyte H810M Gaming Wi-Fi6
Brand: Gigabyte
SKU: 5709

Manufacturer: Gigabyte

The Gigabyte H810M Gaming Wi-Fi6 is a Micro-ATX motherboard designed for the LGA 1851 platform, offering a compact form factor at 244 × 215 mm that suits space-conscious builds without sacrificing connectivity. It includes integrated Wi-Fi 6 (802.11ax) alongside Bluetooth 5.3, RGB lighting, and an HDMI 2.1 output, making it a well-rounded option for a modern desktop system.

On the memory side, the board accommodates up to 128GB of DDR5 RAM across two slots at speeds reaching 6400 MHz in dual-channel configuration. Storage options include four SATA 3 connectors with full RAID 0, 1, 5, and 10 support, plus one M.2 socket and a PCIe 4.0 x16 slot for a discrete graphics card. The rear I/O provides one USB 3.2 Gen 1 Type-A port, five USB 2.0 ports, DisplayPort, HDMI, and a single RJ45 Ethernet jack, while the board delivers 7.1-channel audio through three audio connectors.

Pros

Supports Wi-Fi 6 (802.11ax) with backward compatibility for Wi-Fi 5 and Wi-Fi 4, covering a wide range of wireless devices
DDR5 memory support with a maximum capacity of 128GB and speeds up to 6400 MHz in dual-channel configuration
Includes Bluetooth 5.3 for modern wireless peripheral connectivity
Full RAID support across RAID 0, 1, 5, and 10 configurations provides flexible storage redundancy and performance options
Three-year warranty offers a solid coverage period
RGB lighting is built in, allowing for visual customization

Cons

Only one M.2 socket limits high-speed NVMe storage expansion
No USB Type-C ports on the rear I/O restricts connectivity for newer devices
Just three fan headers may be insufficient for builds with more demanding cooling setups
No dual BIOS means there is no built-in fallback if a firmware update causes issues
Limited high-speed USB on the rear panel, with only one USB 3.2 Gen 1 Type-A port alongside five USB 2.0 ports

Who is this for?

This board is a practical fit for users building a compact desktop system on the LGA 1851 platform who want integrated wireless connectivity without relying on add-in cards — the built-in Wi-Fi 6 and Bluetooth 5.3 cover modern wireless needs out of the box. With support for up to 128GB of DDR5 RAM and RAID 0, 1, 5, and 10, it also works well for home or small office setups that require reliable storage redundancy alongside capable memory headroom. The Micro-ATX form factor suits builders who need a reasonably space-efficient build without going fully mini-ITX.

Who is this NOT for?

Users who need high-speed USB connectivity on the rear I/O will find this board limiting, as it offers no USB Type-C, no USB 3.2 Gen 2, and only a single USB 3.2 Gen 1 Type-A port alongside five USB 2.0 ports. It is also a poor match for enthusiasts who want to push system performance to its limits, since overclocking is not facilitated and there is no dual BIOS for safer firmware experimentation. Additionally, builds requiring multiple fast NVMe drives will be constrained by the single M.2 socket.

General info:

CPU socket	LGA 1851
form factor	Micro-ATX
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Has Bluetooth	✓
Bluetooth version	5.3
HDMI version	HDMI 2.1
Easy to overclock	✕
has RGB lighting	✓
Easy to reset BIOS	✕
Has dual BIOS	✕
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	215 mm
width	244 mm
Has integrated CPU	✕

The Gigabyte H810M Gaming Wi-Fi6 uses the LGA 1851 CPU socket and follows the Micro-ATX form factor, measuring 244 × 215 mm, making it suitable for compact builds. It features a single CPU socket and does not include an integrated CPU or integrated graphics. Wireless connectivity is covered by Wi-Fi 6 (802.11ax), with backward compatibility for Wi-Fi 5 and Wi-Fi 4, alongside Bluetooth 5.3, though aptX audio codec support is not included. Video output is handled through an HDMI 2.1 port, and the board also includes RGB lighting. Overclocking is not simplified through dedicated tooling, and neither a dual BIOS nor an easy CMOS reset function is provided. The board carries a 3-year warranty.

Memory:

maximum memory amount	128GB
RAM speed (max)	6400 MHz
memory slots	2
DDR memory version	5
memory channels	2
Supports ECC memory	✕

This board supports DDR5 memory across two slots in a dual-channel configuration, with a maximum capacity of 128GB and a peak supported speed of 6400 MHz. ECC memory is not supported.

Ports:

USB 3.2 Gen 2 ports (USB-A)	0
USB 3.2 Gen 1 ports (USB-A)	1
USB 3.2 Gen 2 ports (USB-C)	0
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	5
USB 3.2 Gen 2x2 ports	0
USB 4 40Gbps ports	0
USB 4 20Gbps ports	0
Thunderbolt 4 ports	0
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	1
RJ45 ports	1
Has USB Type-C	✕
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	1

The rear I/O panel provides five USB 2.0 ports and one USB 3.2 Gen 1 Type-A port for peripheral connectivity, while USB Type-C, higher-speed USB 3.2 Gen 2, USB 4, Thunderbolt 3, and Thunderbolt 4 ports are absent. Display output is handled by an HDMI port and one DisplayPort output, with no DVI or VGA connectors present. Networking is covered by a single RJ45 port, and there is also one PS/2 port, while eSATA is not included.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	2
USB 2.0 ports (through expansion)	4
SATA 3 connectors	4
fan headers	3
USB 3.0 ports (through expansion)	2
M.2 sockets	1
Has TPM connector	✓
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

For internal storage, the board offers four SATA 3 connectors and one M.2 socket, while SATA 2, mSATA, and U.2 are not supported. Expansion USB connectivity is available through two USB 3.2 Gen 1 headers and four USB 2.0 headers, allowing additional ports to be added via a case or expansion bracket. Cooling is managed through three fan headers, and a TPM connector is present for security module support.

Expansion slots:

PCIe 4.0 x16 slots	1
PCIe 5.0 x16 slots	0
PCIe 3.0 x16 slots	0
PCIe x1 slots	1
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	0
PCIe x8 slots	0

The board provides one PCIe 4.0 x16 slot for a discrete graphics card and one PCIe x1 slot for smaller expansion cards. There are no PCIe 5.0, PCIe 3.0, PCIe 2.0, PCIe x4, PCIe x8, or legacy PCI slots present.

Audio:

audio channels	7.1
Has S/PDIF Out port	✕
audio connectors	3

The board supports 7.1-channel audio output through three analog audio connectors on the rear I/O. A S/PDIF Out port is not included.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✓
Supports RAID 0	✓
Supports RAID 0+1	✕

The board supports RAID 0, 1, 5, and 10 configurations for flexible storage setups ranging from performance striping to mirroring and parity-based redundancy. RAID 0+1 is not supported.

Final Verdict

The Gigabyte H810M Gaming Wi-Fi6 is a Micro-ATX motherboard that delivers a focused feature set for LGA 1851 platform builds where space efficiency and modern wireless connectivity are priorities. Its built-in Wi-Fi 6 with DDR5 memory support up to 128GB makes it a capable foundation for everyday desktop and light productivity workloads, and the broad RAID support adds practical value for users who want storage redundancy. That said, the limited rear USB selection and single M.2 socket mean it is better matched to straightforward builds than to setups with demanding peripheral or storage requirements. For users whose needs align with its capabilities, it represents a solid and well-rounded Micro-ATX option on the current Intel platform.
