KFA2 GeForce RTX 5060 1-Click OC

Name: KFA2 GeForce RTX 5060 1-Click OC
Brand: KFA2
SKU: 6034

Manufacturer: KFA2

The KFA2 GeForce RTX 5060 1-Click OC is a graphics card that sits within NVIDIA's Blackwell generation lineup, offering a factory-overclocked configuration straight out of the box. With a base clock of 2280 MHz and a boosted frequency reaching 2512 MHz, the card is designed to operate at elevated speeds without manual tuning. It also includes RGB lighting and supports up to four displays simultaneously, making it a versatile option for multi-monitor setups.

On the memory side, the RTX 5060 1-Click OC uses 8GB of GDDR7 VRAM across a 128-bit bus, delivering an effective memory speed of 28000 MHz and a maximum bandwidth of 448 GB/s. The GPU houses 3840 shading units, 120 texture mapping units, and 48 render output units, contributing to a texture rate of 301.4 GTexels/s and a floating-point throughput of 19.29 TFLOPS. It supports DirectX 12 Ultimate, OpenGL 4.6, ray tracing, and DLSS, and connects via PCIe 5.0. The card has a TDP of 145W and is manufactured on a 5 nm process node with approximately 21.9 billion transistors. Outputs include one HDMI 2.1b port and three DisplayPort connections.

Pros

Supports ray tracing and DLSS, enabling advanced rendering features in compatible applications
GDDR7 memory with an effective speed of 28000 MHz and 448 GB/s bandwidth provides substantial data throughput for the GPU
Four display outputs, combining one HDMI 2.1b port and three DisplayPort connections, allow flexible multi-monitor configurations
Intel Resizable BAR support enables the CPU to access the full VRAM pool, which can improve frame delivery in supported titles
ECC memory support adds a layer of data integrity protection, useful for tasks sensitive to memory errors
RGB lighting is included for users who prioritize visual customization within their build

Cons

The 128-bit memory bus width is relatively narrow for an 8GB GDDR7 configuration, which may limit headroom in bandwidth-intensive scenarios
No USB-C output is available, which can be a limitation for users with USB-C or Thunderbolt-based displays
Water cooling is not supported, leaving thermal management entirely dependent on the air cooler
At 237 mm in length, the card requires adequate case clearance, which may not suit all compact builds

Who is this for?

This card is well-suited for users who want to run games or applications with ray tracing and DLSS enabled, as both features are supported and can meaningfully improve visual output and frame rates in compatible software. The four display outputs, including HDMI 2.1b and three DisplayPort connections, make it a practical choice for anyone running a multi-monitor setup of up to four screens. The inclusion of ECC memory support and OpenCL 3 compatibility also makes it relevant for users who occasionally handle compute or data-sensitive workloads alongside their primary graphics tasks.

Who is this NOT for?

Users working with memory-intensive workloads such as high-resolution texture editing, large 3D scene rendering, or AI model inference may find the 8GB VRAM ceiling limiting over time, particularly given the 128-bit bus width. The absence of a USB-C output makes this card a poor fit for anyone relying on USB-C or Thunderbolt-connected displays. Additionally, users building in compact or small-form-factor cases may face challenges, as the card measures 237 mm in width and depends entirely on air cooling, which can demand more physical clearance and airflow than tightly constrained enclosures allow.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2512 MHz
pixel rate	120.6 GPixel/s
floating-point performance	19.29 TFLOPS
texture rate	301.4 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The KFA2 GeForce RTX 5060 1-Click OC operates at a base GPU clock of 2280 MHz, with a boost frequency reaching 2512 MHz under load. It delivers a floating-point throughput of 19.29 TFLOPS alongside a texture rate of 301.4 GTexels/s and a pixel rate of 120.6 GPixel/s. The card is equipped with 3840 shading units, 120 texture mapping units, and 48 render output units, while the GPU memory runs at 1750 MHz. Double Precision Floating Point is supported, adding flexibility for workloads that rely on higher numerical precision.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 8GB of GDDR7 VRAM running at an effective memory speed of 28000 MHz across a 128-bit bus, yielding a maximum memory bandwidth of 448 GB/s. ECC memory support is included, which helps maintain data integrity by detecting and correcting memory errors during operation.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

This card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. Ray tracing and DLSS are both supported, while XeSS (XMX) is not available on this model. Multi-display technology is present with support for up to four simultaneous displays, and stereoscopic 3D is also included. On the system integration side, Intel Resizable BAR is supported, though LHR is not present. The card features RGB lighting and does not carry any hardware-level mining limitations.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, providing a total of four display connections. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	237 mm
height	131 mm

Built on the Blackwell architecture and manufactured using a 5 nm process, the GPU integrates approximately 21,900 million transistors and connects to the system via PCIe 5.0. It carries a TDP of 145W and relies on air cooling, with no water cooling support. The card measures 237 mm in width and 131 mm in height.

Final Verdict

The KFA2 GeForce RTX 5060 1-Click OC is a capable Blackwell-generation graphics card that delivers a well-rounded feature set for its category, with GDDR7 memory running at 28000 MHz effective speed and broad software support including ray tracing, DLSS, and DirectX 12 Ultimate. Its factory overclock, four display outputs, and ECC memory support give it practical versatility across both gaming and light compute scenarios. That said, the 8GB VRAM capacity on a 128-bit bus and the absence of USB-C output place natural boundaries on where it performs best. For users building a multi-display system or looking to take advantage of modern rendering technologies without venturing into higher-tier hardware, the RTX 5060 1-Click OC represents a focused and coherent option within its segment.
