Asus B650E Max Gaming Wi-Fi

Name: Asus B650E Max Gaming Wi-Fi
Brand: Asus
SKU: 2465

Manufacturer: Asus

The Asus B650E Max Gaming Wi-Fi is an ATX-form-factor motherboard built around AMD's AM5 platform, targeting users who want a feature-rich B650 chipset build with integrated wireless connectivity. It ships with Wi-Fi 6E (802.11ax) and Bluetooth 5.3 on board, removing the need for a separate wireless adapter, and includes RGB lighting for those who want a visually customized system. A three-year warranty backs the board.

Memory support runs on DDR5 across four slots with a maximum capacity of 256GB and a native speed ceiling of 4000 MHz, stretching to 8000 MHz with overclocking enabled through dual-channel configuration. Expansion options include one PCIe 5.0 x16 slot, one PCIe 4.0 x16 slot, and two PCIe 3.0 x16 slots, while storage connectivity is handled by three M.2 sockets, four SATA 3 connectors, and full RAID 0, 1, 5, and 10 support. The rear I/O provides three USB 3.2 Gen 2 Type-A ports, one USB 3.2 Gen 2 Type-C port, two USB 3.2 Gen 1 Type-A ports, HDMI 2.1, one DisplayPort output, and a single RJ45 Ethernet port, alongside a 7.1-channel audio solution with three audio connectors.

Pros

Supports Wi-Fi 6E alongside older Wi-Fi generations, providing broad wireless compatibility out of the box
DDR5 memory with overclocking headroom up to 8000 MHz across four slots and a 256GB capacity ceiling
A PCIe 5.0 x16 slot is available alongside a PCIe 4.0 x16 slot and two PCIe 3.0 x16 slots, offering versatile expansion options
Three M.2 sockets combined with four SATA 3 connectors give substantial storage flexibility
Full RAID support across RAID 0, 1, 5, and 10 configurations suits both performance and redundancy needs
Three-year warranty provides a solid coverage period

Cons

No dual BIOS means recovery options are limited if firmware issues occur
Easy CMOS reset is absent, making BIOS recovery more cumbersome
Only four fan headers may be restrictive in builds requiring extensive cooling management
S/PDIF optical output is not included, limiting audio connectivity for certain setups
No USB 4 or Thunderbolt ports restricts high-bandwidth peripheral options
ECC memory is not supported, ruling out use cases that require error-correcting RAM

Who is this for?

This board is a solid fit for enthusiasts building a capable AMD AM5 desktop system who want room to grow — the four DDR5 slots with up to 256GB capacity and 8000 MHz overclocking support cater well to users who push memory-intensive workloads or enjoy tuning their builds. The combination of a PCIe 5.0 x16 slot, three M.2 sockets, and full RAID 0/1/5/10 support makes it a practical choice for those who need fast storage configurations and flexible expansion. Built-in Wi-Fi 6E and Bluetooth 5.3 also make it well suited to desktop setups where running Ethernet cables is impractical.

Who is this NOT for?

Users who require ECC memory support for error-sensitive workloads such as scientific computing or server-adjacent tasks will find this board unsuitable, as that capability is absent. Those who rely on high-bandwidth peripherals will be limited by the lack of Thunderbolt or USB 4 ports, making the board a poor match for workflows dependent on ultra-fast external storage or daisy-chained devices. Additionally, the absence of dual BIOS and an easy CMOS reset makes it less forgiving for users who frequently experiment with aggressive overclocking and need straightforward recovery options.

General info:

CPU socket	AM5
chipset	B650
form factor	ATX
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Has Bluetooth	✓
Bluetooth version	5.3
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✕
Has dual BIOS	✕
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	244 mm
width	305 mm
Has integrated CPU	✕

The Asus B650E Max Gaming Wi-Fi is built around the AM5 socket with B650 chipset compatibility, housed in a standard ATX form factor measuring 305 mm wide and 244 mm tall. It supports Wi-Fi across multiple generations — 802.11n, 802.11ac, and up to Wi-Fi 6E (802.11ax) — alongside Bluetooth 5.3, though aptX audio is not included. The board carries an HDMI 2.1 output, features RGB lighting, and is noted as easy to overclock, while dual BIOS and an easy CMOS reset option are absent. There is one CPU socket, no integrated graphics or integrated CPU, and the board is backed by a three-year warranty.

Memory:

maximum memory amount	256GB
RAM speed (max)	4000 MHz
overclocked RAM speed	8000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

This motherboard uses DDR5 memory across four slots in a dual-channel configuration, supporting a maximum installed capacity of 256GB. The native RAM speed tops out at 4000 MHz, with overclocking pushing that ceiling up to 8000 MHz. ECC memory is not supported.

Ports:

USB 3.2 Gen 2 ports (USB-A)	3
USB 3.2 Gen 1 ports (USB-A)	2
USB 3.2 Gen 2 ports (USB-C)	1
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	2
USB 3.2 Gen 2x2 ports	0
USB 4 40Gbps ports	0
USB 4 20Gbps ports	0
Thunderbolt 4 ports	0
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	1
RJ45 ports	1
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The rear I/O panel offers a varied USB selection, including three USB 3.2 Gen 2 Type-A ports, two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2 Type-C port, and two USB 2.0 ports; USB 3.2 Gen 2x2, USB 4, Thunderbolt 3, and Thunderbolt 4 are not present. Display output is handled by an HDMI port and one DisplayPort output, while VGA, DVI, and eSATA connectors are absent. Networking is covered by a single RJ45 port, and there are no PS/2 ports on this board.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	2
USB 2.0 ports (through expansion)	6
SATA 3 connectors	4
fan headers	4
USB 3.0 ports (through expansion)	2
M.2 sockets	3
Has TPM connector	✓
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

Storage connectivity is well covered with three M.2 sockets and four SATA 3 connectors on board, while SATA 2, U.2, and mSATA are not available. For internal expansion, the board provides two USB 3.2 Gen 1 headers, two USB 3.0 headers, and six USB 2.0 headers, allowing front-panel and add-in connectivity to be extended across a range of devices. There are four fan headers for cooling management, and a TPM connector is also present.

Expansion slots:

PCIe 4.0 x16 slots	1
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	2
PCIe x1 slots	0
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	0
PCIe x8 slots	0

The board provides a total of four full-length PCIe slots: one PCIe 5.0 x16 slot, one PCIe 4.0 x16 slot, and two PCIe 3.0 x16 slots. There are no PCIe 2.0 x16, PCIe x8, PCIe x4, or PCIe x1 slots, and legacy PCI is not supported either.

Audio:

audio channels	7.1
Has S/PDIF Out port	✕
audio connectors	3

The audio setup supports 7.1-channel output with three analog audio connectors on the rear panel. An S/PDIF optical output is not included.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✓
Supports RAID 0	✓
Supports RAID 0+1	✕

The board supports four RAID configurations: RAID 0, RAID 1, RAID 5, and RAID 10 (1+0), covering striping, mirroring, parity-based redundancy, and a combined stripe-mirror setup. RAID 0+1 is not supported.

Final Verdict

The Asus B650E Max Gaming Wi-Fi is a well-equipped AM5 motherboard that covers the essentials for a capable DDR5 desktop build, with Wi-Fi 6E, a PCIe 5.0 x16 slot, and three M.2 sockets making it a practical choice for users who want modern connectivity and flexible storage without compromise. Its support for overclocked DDR5 up to 8000 MHz and four RAID configurations add meaningful depth for enthusiasts, though the absence of dual BIOS, Thunderbolt, and ECC support does define clear boundaries around its intended audience. For builders targeting a feature-rich AMD AM5 system with wireless built in and room to expand, it delivers a coherent and well-rounded package.
