Asus Dual Radeon RX 9060 XT 16GB

Name: Asus Dual Radeon RX 9060 XT 16GB
Brand: Asus
SKU: 5437

Manufacturer: Asus

The Asus Dual Radeon RX 9060 XT is a mid-range graphics card from Asus based on AMD's RDNA 4.0 architecture, manufactured on a 4 nm process with 29,700 million transistors. It operates at a base clock of 1700 MHz and reaches a turbo frequency of 3230 MHz, delivering 26.46 TFLOPS of floating-point performance alongside support for ray tracing and AMD FSR4 upscaling technology.

On the memory side, the card is equipped with 16GB of GDDR6 VRAM across a 128-bit bus, achieving an effective memory speed of 20,000 MHz and a maximum bandwidth of 322.3 GB/s. It supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, and connects to up to three displays via one HDMI 2.1b port and two DisplayPort outputs. With a TDP of 160W and PCIe 5.0 compatibility, the card also includes AMD SAM support, ECC memory, and RGB lighting.

Pros

Supports ray tracing and AMD FSR4 upscaling, enabling modern rendering features for compatible titles
16GB of GDDR6 VRAM provides substantial video memory headroom for memory-intensive workloads
Can drive up to three displays simultaneously via two DisplayPort outputs and one HDMI 2.1b port
HDMI 2.1b output supports current-generation display connectivity standards
ECC memory support adds data integrity protection useful for compute and professional workloads
RGB lighting is included for users who want visual customization in their build

Cons

128-bit memory bus width is relatively narrow, limiting memory bandwidth scalability
Does not support DLSS or XeSS upscaling technologies, restricting upscaling options to FSR4 only
No USB-C output is available, limiting compatibility with USB-C monitors or adapters
Water cooling is not supported; the card relies solely on air cooling
PCIe 5.0 is required, which may limit compatibility with older motherboard platforms

Who is this for?

This card is well-matched for users building a capable gaming or compute-oriented system around modern AMD hardware, particularly those who want ray tracing and FSR4 upscaling support without stepping up to a higher power bracket. Its 16GB of GDDR6 VRAM also makes it a reasonable fit for content creators and compute workloads that benefit from larger memory pools, especially given ECC memory support. Users looking to run a triple-monitor setup via the three available display outputs will find the connectivity straightforward, and those building into a PCIe 5.0 platform will have no compatibility concerns.

Who is this NOT for?

Users who rely on DLSS or XeSS upscaling — common in Nvidia-optimized or Intel-integrated workflows — will find those technologies absent here, limiting upscaling flexibility. The 128-bit memory bus may also be a bottleneck for workloads demanding very high sustained memory throughput, making the card a less compelling fit for bandwidth-intensive professional applications. Additionally, those working in thermally constrained or liquid-cooled builds will note that water cooling is not supported, and users on older platforms without PCIe 5.0 motherboards may face compatibility limitations.

Performance:

GPU clock speed	1700 MHz
GPU turbo	3230 MHz
pixel rate	206.7 GPixel/s
floating-point performance	26.46 TFLOPS
texture rate	413.4 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The Asus Dual Radeon RX 9060 XT runs at a base GPU clock of 1700 MHz, boosting up to 3230 MHz under load. Its 2048 shading units work alongside 128 texture mapping units and 64 render output units to deliver a texture rate of 413.4 GTexels/s and a pixel rate of 206.7 GPixel/s. Floating-point performance reaches 26.46 TFLOPS, while the GPU memory operates at 2518 MHz. The card also supports Double Precision Floating Point (DPFP), rounding out a well-specified performance profile for its class.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	322.3 GB/s
VRAM	16GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The card comes equipped with 16GB of GDDR6 VRAM running at an effective speed of 20,000 MHz across a 128-bit memory bus, yielding a maximum memory bandwidth of 322.3 GB/s. ECC memory support is also included, adding a layer of data integrity for workloads where memory accuracy matters.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✓
supported displays	3

The Asus Dual Radeon RX 9060 XT supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of graphics and compute APIs. Ray tracing and stereoscopic 3D are both supported, and AMD FSR4 is available as an upscaling solution; DLSS and XeSS (XMX) are not supported. The card can drive up to three displays simultaneously via its multi-display technology, and includes AMD SAM for CPU-GPU memory access optimization. It does not feature LHR (Lite Hash Rate) restrictions, and RGB lighting is present on the card itself.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and two DisplayPort outputs, allowing connection to up to three monitors. There are no USB-C, DVI, or mini DisplayPort outputs on this model.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	160W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕
width	202 mm
height	120 mm

Built on AMD's RDNA 4.0 architecture, the card is fabricated using a 4 nm process and integrates 29,700 million transistors. It has a Thermal Design Power of 160W and connects via PCIe 5.0. Cooling is handled by an air-based solution, as water cooling is not supported. The card measures 202 mm in width and 120 mm in height.

Final Verdict

The Asus Dual Radeon RX 9060 XT presents a well-rounded specification sheet for users building around AMD's RDNA 4.0 ecosystem, with its 16GB of GDDR6 VRAM and ray tracing support standing out as practical strengths for both gaming and light compute tasks. FSR4 upscaling and ECC memory add further versatility, while the three-display output configuration suits multi-monitor users without additional hardware. That said, the 128-bit bus width and absence of competing upscaling technologies like DLSS or XeSS place some constraints on its broader appeal. For users invested in an AMD-centric, PCIe 5.0-ready platform who prioritize memory capacity and modern rendering support, this card delivers a focused and technically coherent package.
