Asus TUF Gaming B850-BTF Wi-Fi W

Name: Asus TUF Gaming B850-BTF Wi-Fi W
Brand: Asus
SKU: 6689

Manufacturer: Asus

The Asus TUF Gaming B850-BTF Wi-Fi W is a high-performance motherboard designed for gaming and advanced computing. Featuring an AM5 CPU socket, it supports the latest technologies like Wi-Fi 7 and comes with RGB lighting for a custom look. Its robust design is built for stability and performance in demanding setups.

This motherboard is equipped with 4 memory slots, supporting up to 256GB of DDR5 RAM with speeds up to 8000 MHz. It also offers PCIe 5.0 x16 slots for fast graphics card installation and multiple M.2 sockets for fast storage options. With a 3-year warranty and advanced features like dual BIOS, this board is ideal for users seeking reliability and future-proofing in their builds.

Pros

Supports multiple Wi-Fi standards, including Wi-Fi 4, 5, 6, 6E, and the latest Wi-Fi 7 for fast and reliable wireless connectivity.
Equipped with dual BIOS, providing an added layer of security and recovery options for users.
Includes a 120 dB signal-to-noise ratio, ensuring high-quality audio performance with clear sound reproduction.
Offers extensive storage flexibility with support for RAID 1, RAID 5, and RAID 10, improving data redundancy and performance options.
Has a generous 256GB maximum memory capacity and supports high-speed RAM overclocking up to 8000 MHz, ideal for demanding applications.

Cons

Does not support RAID 0+1 for combined speed and redundancy.
Lacks USB 4 ports, which could limit ultra-fast data transfer options.
No Thunderbolt 3 or 4 support, limiting compatibility with some high-performance devices.
Does not support mSATA or U.2 connectors, which may restrict certain storage expansions.
No integrated graphics, meaning a discrete GPU is required for video output.

Who is this for?

This motherboard is ideal for users looking for robust performance and future-proofing in gaming or high-performance computing setups. With support for Wi-Fi 7 and a 256GB memory capacity, it caters to demanding applications, fast networking, and large-scale multitasking. The inclusion of dual BIOS ensures added reliability and recovery options, making it a solid choice for users who require stability during overclocking or critical tasks.

Who is this NOT for?

This motherboard may not be ideal for users requiring extreme portability or compact builds due to its ATX form factor and size. Additionally, those looking for ultra-fast data transfer speeds might find the lack of USB 4 and Thunderbolt support limiting for high-speed peripherals. It is also unsuitable for users needing integrated graphics, as this board does not include such functionality.

General info:

CPU socket	AM5
chipset	B850
form factor	ATX
release date	May 2025
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Has Bluetooth	✓
Bluetooth version	5.4
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✓
Has dual BIOS	✓
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	244 mm
width	305 mm
Has integrated CPU	✕

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard features an AM5 CPU socket and supports the B850 chipset, making it compatible with the latest processors. It has a standard ATX form factor and offers extensive wireless connectivity with support for Wi-Fi 4, 5, 6, 6E, and the latest Wi-Fi 7. Additionally, it includes built-in Bluetooth 5.4, RGB lighting for custom aesthetics, and an HDMI 2.1 output. The motherboard is equipped with dual BIOS for added reliability, and a 3-year warranty ensures long-term support.

Memory:

maximum memory amount	256GB
overclocked RAM speed	8000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard supports up to 256GB of DDR5 memory, providing ample capacity for demanding applications and multitasking. It features 4 memory slots and operates with 2 memory channels for efficient data transfer. The motherboard also supports overclocked RAM speeds up to 8000 MHz, enabling high-performance memory configurations, though it does not support ECC memory for error correction.

Ports:

USB 3.2 Gen 2 ports (USB-A)	3
USB 3.2 Gen 1 ports (USB-A)	4
USB 3.2 Gen 2 ports (USB-C)	0
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	2
USB 3.2 Gen 2x2 ports	1
USB 4 40Gbps ports	0
USB 4 20Gbps ports	0
Thunderbolt 4 ports	0
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	1
RJ45 ports	1
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard provides a wide range of connectivity options. It includes 3 USB 3.2 Gen 2 (USB-A) ports, 4 USB 3.2 Gen 1 (USB-A) ports, and 2 USB 2.0 ports for various peripherals. For faster data transfer, it also features a USB 3.2 Gen 2x2 (USB-C) port. Additionally, the motherboard is equipped with HDMI and DisplayPort outputs, as well as an RJ45 port for network connectivity. It supports USB Type-C, though it does not include Thunderbolt ports or VGA connectivity.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	2
USB-C 3.2 Gen 2 ports (through expansion)	1
USB 2.0 ports (through expansion)	4
SATA 3 connectors	4
fan headers	6
USB 3.0 ports (through expansion)	2
M.2 sockets	3
Has TPM connector	✕
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard offers a variety of connectors for expansion and customization. It includes 2 USB 3.2 Gen 1 ports and 1 USB-C 3.2 Gen 2 port through expansion, as well as 4 additional USB 2.0 ports and 2 USB 3.0 ports for peripherals. The board also provides 4 SATA 3 connectors and 3 M.2 sockets for fast storage options, along with 6 fan headers to ensure adequate cooling. Notably, it lacks support for TPM, mSATA, and U.2 connectors.

Expansion slots:

PCIe 4.0 x16 slots	1
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	0
PCIe x1 slots	1
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	0
PCIe x8 slots	0

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard offers a strong selection of expansion slots for high-performance components. It features 1 PCIe 5.0 x16 slot and 1 PCIe 4.0 x16 slot, providing support for the latest graphics cards and expansion cards. Additionally, the board includes 1 PCIe x1 slot for smaller expansion cards, but lacks support for PCIe x4, x8, or PCI slots.

Audio:

Signal-to-Noise ratio (DAC)	120 dB
audio channels	7.1
Has S/PDIF Out port	✓
audio connectors	5

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard delivers high-quality audio performance with a 120 dB signal-to-noise ratio for clear sound reproduction. It supports 7.1 audio channels, ideal for immersive sound experiences, and includes an S/PDIF Out port for digital audio output. Additionally, the motherboard provides 5 audio connectors for various speaker and headphone configurations.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✓
Supports RAID 0	✓
Supports RAID 0+1	✕

The Asus TUF Gaming B850-BTF Wi-Fi W motherboard supports multiple RAID configurations for flexible storage management, including RAID 1, RAID 5, and RAID 10 (1+0) for improved data redundancy and performance. It also supports RAID 0 for maximum speed, but does not support RAID 0+1 for combined speed and redundancy.

Final Verdict

The motherboard offers excellent performance for high-demand users, particularly those looking for Wi-Fi 7 support and dual BIOS for added stability during overclocking. Its robust memory capacity of up to 256GB and support for multiple RAID configurations make it well-suited for intensive workloads and large-scale computing. However, its ATX form factor and lack of Thunderbolt or USB 4 support may limit its appeal to users seeking compact or ultra-fast data transfer capabilities. Overall, this motherboard is a strong choice for performance-driven builds but may not meet the needs of those with specific portability or cutting-edge connectivity requirements.
