Gigabyte X870E Aorus Pro X3D Ice

Name: Gigabyte X870E Aorus Pro X3D Ice
Brand: Gigabyte
SKU: 9291

Manufacturer: Gigabyte

The Gigabyte X870E Aorus Pro X3D Ice is a high-performance motherboard designed for gamers and enthusiasts. It features a sleek ATX form factor and supports the latest AM5 CPU socket, making it compatible with cutting-edge processors. One of its standout features is Wi-Fi 7 support, ensuring fast and stable wireless connectivity for demanding applications.

In terms of memory, the motherboard can accommodate up to 256GB of DDR5 RAM, with a maximum RAM speed of 5200 MHz and overclocking potential up to 9000 MHz. For expansion, it offers a PCIe 5.0 x16 slot and four M.2 sockets, while also providing multiple USB 3.2 Gen 2 ports and Thunderbolt 4 support. Additionally, it comes with robust audio features, including a 120 dB signal-to-noise ratio and 7.1 channel audio support, ensuring an immersive sound experience.

Pros

Supports a wide range of Wi-Fi versions, including Wi-Fi 4, 5, 6, 6E, and the latest Wi-Fi 7 for high-speed wireless connectivity.
Offers easy overclocking and customizable RGB lighting, enhancing both performance and aesthetic customization for users.
Equipped with multiple USB ports, including USB 4 40Gbps and Thunderbolt 4 ports, offering fast data transfer capabilities.
Provides extensive RAID support with RAID 0, 1, 5, and 10, enabling flexible storage configurations for improved data reliability and performance.
Includes an HDMI 2.1 output, allowing for modern display connectivity without requiring additional graphics hardware.

Cons

Lacks support for dual BIOS, limiting recovery options in case of BIOS failure.
Does not support ECC memory, which may be a drawback for users requiring error-correcting capabilities for critical workloads.
Does not include mSATA or U.2 connectors, restricting options for certain types of storage devices.
Lacks integrated graphics, requiring a discrete GPU for video output, which may not be ideal for users looking for an all-in-one solution.

Who is this for?

This motherboard is ideal for users looking for a high-performance system with extensive connectivity options, such as gamers or professionals building powerful PCs. With support for the latest Wi-Fi 7, multiple USB 4.0 and Thunderbolt 4 ports, and robust RAID configurations, it excels in offering both speed and flexibility. The inclusion of easy overclocking and RGB lighting makes it a good choice for those who value customization and performance tuning in their builds.

Who is this NOT for?

This product may not be ideal for users who require a motherboard with more comprehensive redundancy features or enhanced stability, such as those needing ECC memory support for critical applications. Additionally, the lack of dual BIOS makes it less suited for users concerned about fail-safe options during overclocking or BIOS failures. The absence of integrated graphics also limits its use for those looking for a simple, all-in-one solution without the need for a discrete GPU.

General info:

CPU socket	AM5
chipset	X870
form factor	ATX
release date	September 2025
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Has Bluetooth	✓
Bluetooth version	5.4
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✓
Has dual BIOS	✕
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	244 mm
width	305 mm
Has integrated CPU	✕

The Gigabyte X870E Aorus Pro X3D Ice motherboard features an AM5 CPU socket and supports the X870 chipset. Its ATX form factor is designed to fit standard PC cases, and it includes built-in Wi-Fi 7 support, covering a wide range of wireless standards, from Wi-Fi 4 to Wi-Fi 7. The motherboard also comes with Bluetooth 5.4 for seamless device connectivity, along with HDMI 2.1 for video output. Notable features include easy overclocking and customizable RGB lighting, allowing for a personalized system setup. The motherboard is designed for single CPU use and does not have integrated graphics or dual BIOS functionality. It also includes a 3-year warranty for peace of mind.

Memory:

maximum memory amount	256GB
RAM speed (max)	5200 MHz
overclocked RAM speed	9000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

The Gigabyte X870E Aorus Pro X3D Ice motherboard supports a maximum memory size of 256GB, utilizing DDR5 memory for high-speed performance. With a maximum RAM speed of 5200 MHz, it also allows for overclocking up to 9000 MHz, offering enhanced flexibility for demanding tasks. The motherboard features 4 memory slots and supports dual-channel memory, but does not support ECC memory, ensuring optimal performance for most standard applications.

Ports:

USB 3.2 Gen 2 ports (USB-A)	5
USB 3.2 Gen 1 ports (USB-A)	3
USB 3.2 Gen 2 ports (USB-C)	2
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	0
USB 3.2 Gen 2x2 ports	0
USB 4 40Gbps ports	2
USB 4 20Gbps ports	0
Thunderbolt 4 ports	2
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	0
RJ45 ports	1
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The Gigabyte X870E Aorus Pro X3D Ice motherboard offers a variety of connectivity options, including 5 USB 3.2 Gen 2 USB-A ports, 3 USB 3.2 Gen 1 USB-A ports, and 2 USB 3.2 Gen 2 USB-C ports. It also features 2 Thunderbolt 4 ports and 2 USB 4 40Gbps ports for high-speed data transfer. Additionally, the motherboard includes an HDMI output, 1 RJ45 Ethernet port, and USB Type-C support, but does not have DisplayPort, eSATA, or VGA connectors.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	4
USB 3.2 Gen 2x2 ports (through expansion)	1
USB 2.0 ports (through expansion)	4
SATA 3 connectors	4
fan headers	8
USB 3.0 ports (through expansion)	4
M.2 sockets	4
Has TPM connector	✓
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

The Gigabyte X870E Aorus Pro X3D Ice motherboard offers extensive connector options, including 4 USB 3.2 Gen 1 ports and 1 USB 3.2 Gen 2x2 port through expansion. It also features 4 additional USB 2.0 ports, 4 USB 3.0 ports, and 4 M.2 sockets for flexible storage options. The board provides 8 fan headers for comprehensive cooling solutions and includes a TPM connector for added security. It supports 4 SATA 3 connectors, but lacks U.2 and mSATA support, offering full compatibility with modern storage technologies.

Expansion slots:

PCIe 4.0 x16 slots	0
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	0
PCIe x1 slots	0
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	1
PCIe x8 slots	0

The Gigabyte X870E Aorus Pro X3D Ice motherboard features a variety of expansion slots, including 1 PCIe 5.0 x16 slot and 1 PCIe x4 slot. This setup allows for high-speed expansion, although it lacks PCIe 4.0 x16, PCIe 3.0 x16, and PCIe 2.0 x16 slots. Additionally, the motherboard does not include PCI or PCIe x1 slots, providing a more streamlined option for modern hardware setups.

Audio:

Signal-to-Noise ratio (DAC)	120 dB
audio channels	7.1
Has S/PDIF Out port	✓
audio connectors	2

The Gigabyte X870E Aorus Pro X3D Ice motherboard delivers high-quality audio performance with a 120 dB signal-to-noise ratio for crystal-clear sound. It supports 7.1 channel audio for immersive surround sound and includes an S/PDIF Out port for digital audio output. Additionally, it features 2 audio connectors for flexible audio device connections.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✓
Supports RAID 0	✓
Supports RAID 0+1	✕

The Gigabyte X870E Aorus Pro X3D Ice motherboard supports multiple RAID configurations, including RAID 1, RAID 10 (1+0), RAID 5, and RAID 0, offering flexibility in data redundancy and performance optimization. However, it does not support RAID 0+1, limiting its options for certain redundancy setups.

Final Verdict

The motherboard is a powerful and versatile choice for users looking to build a high-performance system with advanced connectivity options. With support for Wi-Fi 7, Thunderbolt 4, and multiple RAID configurations, it delivers top-tier speed and flexibility. Its design also caters well to those interested in customization, with features like easy overclocking and RGB lighting. However, it may not be the best fit for users requiring ECC memory support or dual BIOS for fail-safe operation. Overall, this product is highly recommended for gamers and professionals seeking a feature-packed, future-proof motherboard.
