Palit GeForce RTX 4070 Ti Super Infinity 3 OC

Name: Palit GeForce RTX 4070 Ti Super Infinity 3 OC
Brand: Palit
SKU: 5581

Manufacturer: Palit

The Palit GeForce RTX 4070 Ti Super Infinity 3 OC is a graphics card based on NVIDIA's Ada Lovelace architecture, manufactured on a 5 nm process and housing 76,300 million transistors. It operates at a base clock of 2340 MHz with a boost up to 2640 MHz, and delivers 44.61 TFLOPS of floating-point performance, making it a capable option for demanding rendering workloads. The card measures 294 mm in length and 116 mm in height, and carries a thermal design power rating of 285W.

On the memory side, the card is equipped with 16GB of GDDR6X across a 256-bit bus, reaching an effective speed of 21,000 MHz and a peak bandwidth of 672 GB/s. It supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, alongside ray tracing and DLSS. Connectivity includes one HDMI 2.1a port and three DisplayPort outputs, supporting up to four displays simultaneously. Intel Resizable BAR is supported, and ECC memory is available, while the card connects via PCIe 4.0.

Pros

Supports up to four displays simultaneously, making it suitable for multi-monitor setups
16GB of GDDR6X memory with a 256-bit bus and 672 GB/s bandwidth handles large textures and complex scenes without running short on VRAM
Ray tracing and DLSS are both supported, enabling advanced lighting effects alongside AI-based rendering optimizations
ECC memory support adds a layer of data integrity for workloads that require reliable computation
Intel Resizable BAR is included, allowing the CPU to access the full GPU memory pool for improved data throughput
HDMI 2.1a output alongside three DisplayPort connections provides flexible connectivity for a range of modern displays

Cons

A 285W TDP places considerable demand on the power supply and system cooling
No USB-C output limits compatibility with certain modern monitors and displays that rely on that connection
Air-water cooling is not supported, restricting cooling options to standard air solutions only
No RGB lighting, which may not suit users who prefer visual customization within their build

Who is this for?

This card is well-suited to users running demanding 3D rendering, simulation, or compute workloads that benefit from high floating-point throughput and ECC memory support. The 16GB of GDDR6X VRAM and 672 GB/s of memory bandwidth make it a solid fit for working with large textures, complex scenes, or data-intensive GPU compute tasks. Users who rely on multi-display setups will also find the four-output configuration practical, and the inclusion of DLSS and ray tracing support makes it appropriate for high-fidelity real-time graphics workloads as well.

Who is this NOT for?

Users looking to build a compact or small-form-factor system may find the 294 mm width and 285W TDP difficult to accommodate, as both the physical footprint and power demands require a well-ventilated full-size case with a capable power supply. The absence of air-water cooling support rules it out for those seeking liquid cooling integration as a thermal management option. Additionally, users who need USB-C display output for newer monitors or external displays will need to look elsewhere, as this card provides no USB-C connectivity.

Performance:

GPU clock speed	2340 MHz
GPU turbo	2640 MHz
pixel rate	253.4 GPixel/s
floating-point performance	44.61 TFLOPS
texture rate	697 GTexels/s
GPU memory speed	1313 MHz
shading units	8448
texture mapping units (TMUs)	264
render output units (ROPs)	96
Has Double Precision Floating Point (DPFP)	✓

The Performance section of this card is anchored by a base GPU clock of 2340 MHz that boosts up to 2640 MHz, paired with 44.61 TFLOPS of floating-point performance and Double Precision Floating Point support. It features 8,448 shading units, 264 texture mapping units, and 96 render output units, translating into a texture rate of 697 GTexels/s and a pixel rate of 253.4 GPixel/s. GPU memory operates at 1313 MHz, rounding out a performance profile suited to compute-intensive and graphics-heavy tasks alike.

Memory:

effective memory speed	21000 MHz
maximum memory bandwidth	672 GB/s
VRAM	16GB
GDDR version	GDDR6X
memory bus width	256-bit
Supports ECC memory	✓

This card carries 16GB of GDDR6X memory running across a 256-bit bus, reaching an effective speed of 21,000 MHz and delivering a maximum bandwidth of 672 GB/s. ECC memory is supported, which helps maintain data integrity during sustained workloads that place heavy demands on the memory subsystem.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute workloads. Ray tracing and DLSS are both included, while stereoscopic 3D and multi-display technology are also supported, with the card capable of driving up to four displays simultaneously. Intel Resizable BAR is present to help improve data transfer between the CPU and GPU. XeSS (XMX) and LHR are not featured, and the card does not include RGB lighting.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1a
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of three DisplayPort outputs and one HDMI 2.1a port, offering a total of four video outputs. There are no USB-C, DVI, or mini DisplayPort connections included in the layout.

General info:

GPU architecture	Ada Lovelace
Thermal Design Power (TDP)	285W
PCI Express (PCIe) version	4
semiconductor size	5 nm
number of transistors	76300 million
Has air-water cooling	✕
width	294 mm
height	116 mm

Built on the Ada Lovelace architecture and fabricated using a 5 nm process, this card packs 76,300 million transistors and connects to the system via PCIe 4.0. It carries a thermal design power of 285W and does not include air-water cooling. Physically, the card measures 294 mm in width and 116 mm in height.

Final Verdict

The Palit GeForce RTX 4070 Ti Super Infinity 3 OC brings together a well-rounded set of specifications anchored by its Ada Lovelace architecture, with 16GB of GDDR6X memory and 672 GB/s of bandwidth giving it the headroom needed for data-heavy rendering and compute tasks. Ray tracing, DLSS, ECC memory support, and a four-display output configuration round out a feature set that serves both creative professionals and demanding real-time graphics workloads. Its 285W TDP and physical dimensions do require thoughtful system planning, and the absence of USB-C output and liquid cooling support will be limiting factors for some configurations. Overall, users who can accommodate its power and space requirements will find it a capable and well-equipped card for serious workloads.
