Zotac Gaming GeForce RTX 5070 Ti Solid OC

Name: Zotac Gaming GeForce RTX 5070 Ti Solid OC
Brand: Zotac
SKU: 6677

Manufacturer: Zotac

The Zotac Gaming GeForce RTX 5070 Ti Solid OC is a graphics card based on NVIDIA's Blackwell architecture, targeting enthusiast-level desktop gaming and creative workloads. It ships with 16GB of GDDR7 memory across a 256-bit bus, delivering a maximum memory bandwidth of 896 GB/s and an effective memory speed of 28000 MHz. The card operates at a base GPU clock of 2295 MHz, with a boost frequency reaching up to 2482 MHz under load.

On the rendering side, the card houses 8960 shading units, 280 texture mapping units, and 96 render output units, yielding a texture rate of 695 GTexels/s and a pixel fill rate of 238.3 GPixel/s. It carries a 300W TDP and connects via PCI Express 5.0, with transistor density built on a 5nm process node totalling 45,600 million transistors. Display output consists of one HDMI 2.1b port and three DisplayPort connectors, supporting up to four simultaneous displays. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, DLSS, Intel Resizable BAR, and RGB lighting, with a three-year warranty included.

Pros

Supports up to four displays simultaneously, offering flexibility for multi-monitor setups
16GB of GDDR7 VRAM with a 256-bit bus provides substantial frame buffer capacity for demanding workloads
ECC memory support adds a layer of data integrity useful for compute-oriented tasks alongside gaming
Ray tracing and DLSS are both supported, expanding rendering options available to the user
Comes with a three-year warranty, which is a longer coverage period than many graphics cards offer
RGB lighting is included for users who want visual customization within their build

Cons

A 300W TDP places significant demands on the system power supply and case airflow
No USB-C output is available, limiting connectivity options for users with USB-C monitors
Does not include air-water cooling, so thermal performance depends entirely on the card's built-in fan assembly
At 329.7 mm in length, the card requires a case with sufficient clearance to accommodate it

Who is this for?

This card is well-suited to users running demanding rendering and compute workloads that benefit from 44.48 TFLOPS of floating-point throughput, 16GB of GDDR7 VRAM, and ECC memory support. Content creators, 3D artists, and technical users who need reliable memory integrity alongside high-throughput GPU tasks will find the hardware configuration practical. The support for up to four simultaneous displays, ray tracing, and DLSS also makes it a solid fit for enthusiast gamers and those building high-end multi-monitor workstations who want broad API coverage including DirectX 12 Ultimate and OpenCL 3.

Who is this NOT for?

Users working in space-constrained builds may find this card impractical, as its 329.7 mm length and 300W TDP demand a full-sized case with adequate clearance and a robust power delivery setup. Those specifically relying on USB-C monitor connectivity will need an adapter or an alternative solution, since no USB-C output is available on this model. Additionally, users looking for a card with integrated air-water cooling for quieter or thermally controlled environments will need to look elsewhere, as cooling here is limited to the card's built-in fan-based assembly.

Performance:

GPU clock speed	2295 MHz
GPU turbo	2482 MHz
pixel rate	238.3 GPixel/s
floating-point performance	44.48 TFLOPS
texture rate	695 GTexels/s
GPU memory speed	1750 MHz
shading units	8960
texture mapping units (TMUs)	280
render output units (ROPs)	96
Has Double Precision Floating Point (DPFP)	✓

The card runs at a base GPU clock of 2295 MHz, with the boost frequency climbing to 2482 MHz under sustained load, while GPU memory operates at 1750 MHz. Compute throughput is rated at 44.48 TFLOPS of floating-point performance, supported by a texture rate of 695 GTexels/s and a pixel fill rate of 238.3 GPixel/s. The GPU pairs 8960 shading units with 280 texture mapping units and 96 render output units to handle rendering workloads, and it also supports Double Precision Floating Point (DPFP), which extends its usefulness beyond gaming into compute-oriented tasks.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	896 GB/s
VRAM	16GB
GDDR version	GDDR7
memory bus width	256-bit
Supports ECC memory	✓

The card is equipped with 16GB of GDDR7 VRAM running across a 256-bit memory bus, reaching an effective memory speed of 28000 MHz and a maximum memory bandwidth of 896 GB/s. ECC memory support is included, which helps detect and correct memory errors during operation, making the card suitable for workloads where data integrity matters alongside standard graphics tasks.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✓
supported displays	4

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, alongside stereoscopic 3D and multi-display technology spanning up to four screens simultaneously. Intel Resizable BAR is enabled for improved CPU-to-GPU data throughput, and RGB lighting is present on the card itself. XeSS (XMX) and LHR are not featured on this model.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of three DisplayPort connectors and one HDMI 2.1b port, totalling four display outputs. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	300W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	45600 million
warranty period	3 years
Has air-water cooling	✕
width	329.7 mm
height	137.8 mm

Built on the Blackwell architecture and fabricated on a 5nm process node, the GPU integrates 45,600 million transistors and connects to the host system via PCI Express 5.0. It carries a 300W TDP and does not include an air-water cooling solution, meaning cooling is handled by the card's standard thermal assembly. The card measures 329.7 mm in width and 137.8 mm in height, and it comes backed by a three-year warranty.

Final Verdict

The Zotac Gaming GeForce RTX 5070 Ti Solid OC is a well-specified graphics card built around NVIDIA's Blackwell architecture, combining 16GB of GDDR7 VRAM with 44.48 TFLOPS of floating-point performance to address both high-end gaming and compute-adjacent workloads. Its support for ray tracing, DLSS, DirectX 12 Ultimate, ECC memory, and up to four simultaneous displays reflects a broad and capable feature set. That said, the 300W TDP and 329.7 mm card length mean it demands a well-equipped system to operate effectively, and the absence of USB-C output is a minor constraint worth noting. For users who can accommodate its physical and power requirements, this card represents a technically comprehensive option within the enthusiast graphics card segment.
