ASRock Radeon RX 9060 XT Steel Legend OC 16GB

Name: ASRock Radeon RX 9060 XT Steel Legend OC 16GB
Brand: ASRock
SKU: 31416

Manufacturer: ASRock

The ASRock Radeon RX 9060 XT Steel Legend OC is a graphics card based on AMD's RDNA 4.0 architecture, manufactured on a 4 nm process with 29,700 million transistors. It ships with 16GB of GDDR6 VRAM across a 128-bit memory bus, reaching an effective memory speed of 20,000 MHz and a maximum bandwidth of 322.3 GB/s. The card also includes RGB lighting and supports up to three simultaneous displays.

On the performance side, the ASRock Radeon RX 9060 XT Steel Legend OC operates at a base GPU clock of 1,900 MHz and a turbo frequency of 3,320 MHz, delivering 27.2 TFLOPS of floating-point throughput. It carries 2,048 shading units, 128 TMUs, and 64 ROPs, translating to a texture rate of 425 GTexels/s and a pixel rate of 212.5 GPixel/s. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, ray tracing, FSR4, AMD SAM, and ECC memory, while connectivity is handled through one HDMI 2.1b port and two DisplayPort outputs. The card has a rated TDP of 160W and connects via PCIe 5.0.

Pros

Supports ray tracing and AMD FSR4 upscaling, covering both modern rendering and image reconstruction workloads
Generous 16GB of GDDR6 VRAM gives substantial headroom for memory-intensive tasks
ECC memory support adds data integrity for workloads where accuracy matters
Three simultaneous display outputs via one HDMI 2.1b and two DisplayPort connections offer flexible multi-monitor setups
Built on a 4 nm process with RDNA 4.0 architecture, incorporating 29,700 million transistors in a relatively compact 298 x 131 mm footprint
PCIe 5.0 interface ensures compatibility with current-generation motherboard platforms

Cons

128-bit memory bus width is narrow relative to the 16GB VRAM capacity, which can limit memory bandwidth in demanding scenarios
No USB-C video output, which may be a limitation for users with USB-C monitors or displays
DLSS and XeSS (XMX) are not supported, restricting upscaling options to FSR4 only
Water cooling is not supported, leaving the card reliant solely on air cooling for thermal management

Who is this for?

This card is well-suited to users who work with memory-intensive rendering or compute tasks, given its 16GB of GDDR6 VRAM with ECC support, which helps maintain data integrity under sustained workloads. The combination of ray tracing support, FSR4 upscaling, and DirectX 12 Ultimate also makes it a practical fit for those engaged in modern 3D content creation or gaming pipelines that leverage current graphics APIs. Users who need to drive up to three displays simultaneously via HDMI 2.1b and dual DisplayPort outputs will find the connectivity arrangement straightforward and flexible.

Who is this NOT for?

The 128-bit memory bus may present a bottleneck for users running high-bandwidth workloads that demand sustained data throughput beyond what 322.3 GB/s can sustain at scale. Those who rely on DLSS or XeSS upscaling — whether for compatibility with specific software pipelines or personal preference — will find neither supported here, limiting upscaling to FSR4 exclusively. Additionally, users requiring USB-C display output or liquid cooling integration will need to look elsewhere, as neither is available on this card.

Performance:

GPU clock speed	1900 MHz
GPU turbo	3320 MHz
pixel rate	212.5 GPixel/s
floating-point performance	27.2 TFLOPS
texture rate	425 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The Performance section of this card centers on a base GPU clock of 1,900 MHz and a turbo frequency of 3,320 MHz, supported by a memory speed of 2,518 MHz. With 2,048 shading units, 128 texture mapping units, and 64 render output units, the card achieves a texture rate of 425 GTexels/s and a pixel rate of 212.5 GPixel/s. Floating-point performance is rated at 27.2 TFLOPS, and the GPU also supports Double Precision Floating Point (DPFP), extending its usefulness beyond standard rendering workloads.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	322.3 GB/s
VRAM	16GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

This card is equipped with 16GB of GDDR6 VRAM running across a 128-bit memory bus, reaching an effective memory speed of 20,000 MHz and delivering a maximum memory bandwidth of 322.3 GB/s. ECC memory support is also included, adding a layer of data integrity for workloads where memory accuracy is a consideration.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✓
supported displays	3

On the software and feature side, this card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of graphics and compute workloads. Ray tracing and stereoscopic 3D are both supported, and AMD FSR4 is available for upscaling, while DLSS and XeSS (XMX) are not supported. Multi-display technology is included, allowing connection of up to three screens simultaneously. AMD SAM (Smart Access Memory) is supported, though LHR is not present. The card rounds out its feature set with RGB lighting for those who factor aesthetics into their build.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and two DisplayPort outputs, providing a total of three video connections. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	160W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕
width	298 mm
height	131 mm

This card is built on the RDNA 4.0 architecture, manufactured using a 4 nm process node with 29,700 million transistors, and connects to the system via PCIe 5.0. It carries a Thermal Design Power (TDP) of 160W and relies on air cooling, as water cooling is not supported. Physically, the card measures 298 mm in width and 131 mm in height.

Final Verdict

The ASRock Radeon RX 9060 XT Steel Legend OC presents a well-rounded specification sheet anchored by its 16GB of GDDR6 VRAM with ECC support and RDNA 4.0 architecture, making it a credible option for users engaged in modern rendering, compute, or multi-display workflows. Its support for ray tracing, FSR4, DirectX 12 Ultimate, and PCIe 5.0 reflects a feature set aligned with current-generation demands, while the 160W TDP and compact physical dimensions keep system integration manageable. Users with specific requirements around memory bus bandwidth, alternative upscaling technologies, or USB-C connectivity will need to weigh those constraints carefully, but for those whose workloads align with what this card offers, it represents a technically coherent and capable choice within the RDNA 4.0 generation.
