ASRock X870 Pro-A Wi-Fi

Name: ASRock X870 Pro-A Wi-Fi
Brand: ASRock
SKU: 1337

Manufacturer: ASRock

The ASRock X870 Pro-A Wi-Fi is an ATX form factor motherboard built around the AM5 socket and X870 chipset, designed to accommodate current-generation AMD processors. It includes Wi-Fi 7 (802.11be) alongside Bluetooth 5.4, dual BIOS protection, RGB lighting, and an HDMI 2.1 output, making it a well-rounded option for desktop builds that benefit from integrated wireless connectivity and display output without additional expansion cards.

Memory support extends to four DDR5 slots across two channels, with a maximum capacity of 256GB and overclocked speeds reaching up to 8000 MHz. On the expansion side, the board provides one PCIe 5.0 x16 slot and three PCIe 4.0 x16 slots, along with three M.2 sockets and four SATA 3 connectors with RAID 0, 1, and 10 support. The rear I/O includes two USB 4 40Gbps ports, two Thunderbolt 4 ports, and four USB 2.0 ports, complemented by a single RJ45 Ethernet jack and a 7.1-channel audio solution across three audio connectors.

Pros

Includes two Thunderbolt 4 ports and two USB 4 40Gbps ports on the rear I/O, offering high-bandwidth connectivity options
Wi-Fi 7 support covers all major wireless standards from Wi-Fi 4 through 802.11be, ensuring broad compatibility and future-ready wireless
Dual BIOS provides a built-in fallback in case of a failed firmware update, adding a layer of reliability
Four DDR5 slots support up to 256GB of memory with overclocked speeds reaching 8000 MHz, giving substantial headroom for memory-intensive workloads
Three M.2 sockets alongside four SATA 3 connectors offer flexible storage configuration options
RAID 0, 1, and 10 support allows users to configure drives for either redundancy or performance

Cons

No USB-C ports among the USB 3.2 Gen 2 rear outputs, limiting high-speed connectivity to USB-A on that tier
Clear CMOS functionality is not available, making manual BIOS recovery less straightforward
ECC memory is not supported, restricting use in workloads that require error-correcting RAM
No S/PDIF output is present, which may inconvenience users who rely on digital audio passthrough
RAID 5 is not supported, removing a common option that balances redundancy and storage efficiency

Who is this for?

This motherboard is well matched for users building a high-end AMD AM5 desktop system who need strong connectivity and modern wireless capabilities. The combination of Wi-Fi 7 and Thunderbolt 4 makes it particularly fitting for content creators and power users who transfer large files frequently or connect high-bandwidth peripherals. The four DDR5 slots with support for up to 256GB at overclocked speeds up to 8000 MHz, alongside three M.2 sockets and RAID support, also make it a solid fit for those running memory- and storage-intensive workloads such as video editing, 3D rendering, or data processing.

Who is this NOT for?

Users who depend on ECC memory for error-correcting workloads — such as those in scientific computing or professional server environments — will find this board unsuitable, as ECC support is absent. It is also a poor fit for anyone requiring digital audio output via S/PDIF, or for those who need a clear CMOS button for quick BIOS recovery, as neither feature is available. Additionally, users who prioritize legacy storage configurations like RAID 5, or those needing multiple USB-C outputs at the rear I/O for modern peripherals, will find the board's options in these areas limiting.

General info:

CPU socket	AM5
chipset	X870
form factor	ATX
supports Wi-Fi	✓
Wi-Fi version	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Has Bluetooth	✓
Bluetooth version	5.4
HDMI version	HDMI 2.1
Easy to overclock	✓
has RGB lighting	✓
Easy to reset BIOS	✕
Has dual BIOS	✓
has aptX	✕
CPU sockets	1
Has integrated graphics	✕
warranty period	3 years
height	244 mm
width	305 mm
Has integrated CPU	✕

The ASRock X870 Pro-A Wi-Fi uses the AM5 socket paired with the X870 chipset and follows the standard ATX form factor, measuring 305 mm wide and 244 mm tall. It supports a broad range of wireless standards through its built-in Wi-Fi module, covering Wi-Fi 4 through Wi-Fi 7 (802.11be), and includes Bluetooth 5.4, though aptX audio codec support is not available. The board features an HDMI 2.1 output for display connectivity, RGB lighting, and a dual BIOS configuration for added firmware reliability, while BIOS reset via a dedicated clear CMOS button is not supported. Overclocking is accessible through the BIOS, and the board carries a 3-year warranty. It does not include an integrated CPU or onboard graphics, and accommodates a single processor.

Memory:

maximum memory amount	256GB
overclocked RAM speed	8000 MHz
memory slots	4
DDR memory version	5
memory channels	2
Supports ECC memory	✕

The board supports DDR5 memory across four slots arranged in a dual-channel configuration, with a maximum supported capacity of 256GB. Overclocked RAM speeds can reach up to 8000 MHz, offering headroom for high-frequency memory kits. ECC memory is not supported.

Ports:

USB 3.2 Gen 2 ports (USB-A)	2
USB 3.2 Gen 1 ports (USB-A)	1
USB 3.2 Gen 2 ports (USB-C)	0
USB 3.2 Gen 1 ports (USB-C)	0
USB 2.0 ports	4
USB 3.2 Gen 2x2 ports	0
USB 4 40Gbps ports	2
USB 4 20Gbps ports	0
Thunderbolt 4 ports	2
Thunderbolt 3 ports	0
has an HDMI output	✓
DisplayPort outputs	0
RJ45 ports	1
Has USB Type-C	✓
eSATA ports	0
DVI outputs	0
has a VGA connector	✕
PS/2 ports	0

The rear I/O panel includes two USB 4 40Gbps ports and two Thunderbolt 4 ports, all in USB-C form factor, alongside two USB 3.2 Gen 2 USB-A ports, one USB 3.2 Gen 1 USB-A port, and four USB 2.0 ports. No USB 3.2 Gen 2x2, USB 4 20Gbps, or Thunderbolt 3 ports are present. For display output, there is one HDMI port, while DisplayPort, DVI, and VGA connectors are absent. Network connectivity is handled by a single RJ45 port, and legacy PS/2 and eSATA ports are not included.

Connectors:

USB 3.2 Gen 1 ports (through expansion)	4
USB 2.0 ports (through expansion)	4
SATA 3 connectors	4
fan headers	6
USB 3.0 ports (through expansion)	4
M.2 sockets	3
Has TPM connector	✓
U.2 sockets	0
Has mSATA connector	✕
SATA 2 connectors	0

Internal connectivity includes three M.2 sockets and four SATA 3 connectors for storage, while SATA 2 and U.2 sockets are absent, and mSATA is not supported. For USB expansion via headers, the board provides four USB 3.2 Gen 1 ports, four additional USB 3.0 ports, and four USB 2.0 ports. Cooling is managed through six fan headers, and a TPM connector is present for security module support.

Expansion slots:

PCIe 4.0 x16 slots	3
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	0
PCIe x1 slots	0
PCI slots	0
PCIe 2.0 x16 slots	0
PCIe x4 slots	0
PCIe x8 slots	0

The board offers a total of four full-length PCIe slots, consisting of one PCIe 5.0 x16 slot and three PCIe 4.0 x16 slots. Older PCIe generations — including PCIe 3.0, 2.0, and legacy PCI — are not represented, and there are no PCIe x1, x4, or x8 slots present.

Audio:

audio channels	7.1
Has S/PDIF Out port	✕
audio connectors	3

The onboard audio supports a 7.1-channel configuration and is accessible through three analog audio connectors. An S/PDIF output port is not included.

Storage:

Supports RAID 1	✓
Supports RAID 10 (1+0)	✓
Supports RAID 5	✕
Supports RAID 0	✓
Supports RAID 0+1	✕

The board supports RAID 0, RAID 1, and RAID 10 configurations for storage arrays, while RAID 5 and RAID 0+1 are not available.

Final Verdict

The ASRock X870 Pro-A Wi-Fi is a feature-rich ATX motherboard that covers a broad range of connectivity and storage needs for AM5-based desktop builds. Its standout strength lies in its combination of Wi-Fi 7, Thunderbolt 4, and USB 4 40Gbps ports, which together position it well for users who demand fast wireless and wired peripheral connectivity. DDR5 support across four slots with generous capacity headroom and multiple M.2 and SATA storage options round out a capable platform for demanding workloads. Where it falls short — notably the absence of ECC support, S/PDIF output, and a clear CMOS button — reflects tradeoffs that matter primarily in niche professional or enthusiast scenarios. Overall, the X870 Pro-A Wi-Fi is a well-specified board for power users and content-focused desktop builders who want modern connectivity without compromise on storage flexibility.
