Asus Dual GeForce RTX 5060 Ti OC Edition 16GB

Name: Asus Dual GeForce RTX 5060 Ti OC Edition 16GB
Brand: Asus
SKU: 2409

Manufacturer: Asus

The Asus Dual GeForce RTX 5060 Ti OC Edition is a desktop graphics card based on NVIDIA's Blackwell architecture, manufactured on a 5 nm process with 21,900 million transistors. It ships with 16GB of GDDR7 VRAM across a 128-bit memory bus, delivering an effective memory speed of 28,000 MHz and a maximum bandwidth of 448 GB/s. The card operates within a 180W TDP envelope and measures 229 mm in length and 120 mm in height, making it a relatively compact dual-slot solution.

On the compute side, the card houses 4,608 shading units, 144 texture mapping units, and 48 render output units, yielding a floating-point throughput of 23.98 TFLOPS and a texture fill rate of 374.7 GTexels/s. It supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, along with ray tracing and DLSS. Connectivity is handled by one HDMI 2.1b port and three DisplayPort outputs, supporting up to four displays simultaneously. The card also supports Intel Resizable BAR and ECC memory, and connects to the host system via a PCIe 5 interface.

Pros

Equipped with 16GB of GDDR7 VRAM on a 128-bit bus, delivering up to 448 GB/s of memory bandwidth — a notable amount for this memory bus width
Supports up to four simultaneous displays through a combination of one HDMI 2.1b and three DisplayPort outputs
ECC memory support adds a layer of data integrity useful for compute-adjacent workloads
Ray tracing and DLSS are both supported, expanding rendering options for compatible applications
Intel Resizable BAR support allows the CPU to access the full VRAM pool, which can improve frame delivery in supported scenarios
At 229 mm long and 120 mm tall with a 180W TDP, the card has a relatively contained physical footprint

Cons

The 128-bit memory bus width is narrow for a card with this VRAM capacity, which may limit sustained memory throughput in bandwidth-intensive scenarios
No USB-C display output is available, limiting compatibility with monitors or devices that rely on that connection type
Air-water cooling is not supported, so users requiring liquid cooling solutions for thermal management will need to look elsewhere
XeSS (XMX) support is absent, restricting upscaling options to DLSS only
No RGB lighting for users who factor aesthetics into their build choices

Who is this for?

This card is well-suited for users who work with compute-intensive or graphics workloads that benefit from a large VRAM pool, as the 16GB of GDDR7 memory with ECC support makes it a practical choice for tasks requiring both capacity and data integrity. It also fits users building a multi-monitor setup, given the four display outputs spanning HDMI 2.1b and three DisplayPort connections. Additionally, those running applications that leverage ray tracing or DLSS will find both features readily available, making the card a reasonable fit for rendering and content creation workflows alongside gaming use cases.

Who is this NOT for?

Users who require high memory bandwidth for sustained, bandwidth-heavy workloads — such as large-scale texture streaming or certain machine learning tasks — may find the 128-bit bus width a limiting factor despite the GDDR7 specification. The card is also less suitable for those who need USB-C display connectivity, as no such output is available. Furthermore, system builders who prefer or require liquid cooling integration will find no native support for that here, which could be a drawback in thermally constrained or high-ambient-temperature environments.

Performance:

GPU clock speed	2407 MHz
GPU turbo	2602 MHz
pixel rate	124.9 GPixel/s
floating-point performance	23.98 TFLOPS
texture rate	374.7 GTexels/s
GPU memory speed	1750 MHz
shading units	4608
texture mapping units (TMUs)	144
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The Asus Dual GeForce RTX 5060 Ti OC Edition runs its GPU at a base clock of 2407 MHz, boosting up to 2602 MHz under load, while the GPU memory operates at 1750 MHz. With 4,608 shading units, 144 texture mapping units, and 48 render output units, the card achieves a texture fill rate of 374.7 GTexels/s and a pixel rate of 124.9 GPixel/s. Its floating-point throughput of 23.98 TFLOPS reflects the compute capacity available for rendering and general workloads, and the inclusion of Double Precision Floating Point support broadens its utility for tasks that require higher numerical precision.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	16GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 16GB of GDDR7 VRAM running across a 128-bit memory bus, with an effective memory speed of 28,000 MHz that translates to a maximum bandwidth of 448 GB/s. ECC memory support is also present, which helps detect and correct memory errors during operation — a feature relevant for workloads where data integrity is a priority.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The Asus Dual GeForce RTX 5060 Ti OC Edition supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. Ray tracing and DLSS are both supported, along with stereoscopic 3D and multi-display technology for up to four simultaneous outputs. Intel Resizable BAR is included to help the CPU access the full VRAM more efficiently. XeSS (XMX) and LHR are not present, and the card does not feature RGB lighting.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and three DisplayPort outputs, offering a total of four display connections. There are no DVI, mini DisplayPort, or USB-C ports on this model.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	180W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	229 mm
height	120 mm

Built on the Blackwell architecture and fabricated using a 5 nm process, the card integrates 21,900 million transistors and connects to the host system via PCIe 5. It carries a thermal design power rating of 180W and relies solely on air cooling, with no liquid cooling support. Physically, the card measures 229 mm in width and 120 mm in height.

Final Verdict

The Asus Dual GeForce RTX 5060 Ti OC Edition brings together a well-rounded set of specifications for a mid-range graphics card, with its most notable strength being 16GB of GDDR7 VRAM paired with ECC support and a 448 GB/s bandwidth ceiling — a combination that broadens its usefulness beyond pure gaming into compute and content creation scenarios. Built on the Blackwell architecture at 5 nm, it also covers the practical bases with ray tracing, DLSS, four display outputs, and Intel Resizable BAR support, all within a compact 229 mm frame and a 180W power envelope. The 128-bit bus width and absence of USB-C or liquid cooling support do place some limits on its ceiling, but for users whose workloads align with what the card genuinely offers, the Asus Dual RTX 5060 Ti OC Edition represents a focused and capable option within its class.
