Gigabyte GeForce RTX 5060 Eagle OC

Name: Gigabyte GeForce RTX 5060 Eagle OC
Brand: Gigabyte
SKU: 6567

Manufacturer: Gigabyte

The Gigabyte GeForce RTX 5060 Eagle OC is a mid-range graphics card based on NVIDIA's Blackwell architecture, manufactured on a 5 nm process with 21.9 billion transistors. It ships with 8GB of GDDR7 memory over a 128-bit bus, delivering an effective memory speed of 28000 MHz and a peak bandwidth of 448 GB/s. The card measures 208 mm in length and 120 mm in height, fitting comfortably within typical mid-tower builds, and operates within a 145W thermal design power envelope.

On the compute side, the RTX 5060 Eagle OC carries 3840 shading units, 120 texture mapping units, and 48 render output units, translating to a texture rate of 306 GTexels/s and 19.58 TFLOPS of floating-point performance. The GPU runs at a base clock of 2280 MHz with a turbo frequency of 2550 MHz. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3, ray tracing, DLSS, and Intel Resizable BAR. Display output consists of one HDMI 2.1b port and three DisplayPort outputs, supporting up to four monitors simultaneously.

Pros

Supports ray tracing and DLSS, enabling hardware-accelerated lighting and AI-based upscaling in compatible titles
GDDR7 memory with an effective speed of 28000 MHz and 448 GB/s bandwidth provides fast data throughput for the GPU
Four display outputs — three DisplayPort and one HDMI 2.1b — allow flexible multi-monitor configurations of up to four screens
ECC memory support adds a layer of data integrity for workloads sensitive to memory errors
Intel Resizable BAR support allows the CPU to access the full GPU framebuffer, which can improve rendering efficiency
At 145W TDP with dimensions of 208 x 120 mm, the card fits within a compact footprint suitable for mid-tower and smaller builds

Cons

The 128-bit memory bus width is relatively narrow, which can limit memory throughput in bandwidth-demanding scenarios despite the fast GDDR7 modules
8GB of VRAM may prove limiting in memory-intensive workloads or higher-resolution textures
No USB-C output is available, restricting direct connectivity to certain modern displays or headsets that rely on that port
Water cooling is not supported, limiting thermal management options to air cooling only
XeSS is not supported, reducing upscaling options to DLSS alone with no alternative AI upscaling path

Who is this for?

This card is a solid fit for users running games and applications that take advantage of ray tracing and DLSS, as hardware support for both is built in. Its compact 208 x 120 mm footprint and 145W TDP make it a practical choice for smaller form-factor builds where power and space constraints matter. The inclusion of ECC memory support and OpenCL 3 also makes it viable for users who occasionally run compute or data-integrity-sensitive workloads alongside general graphics tasks. Those who need to drive up to four displays simultaneously will also find the output configuration accommodating.

Who is this NOT for?

Users working with memory-intensive workloads such as high-resolution texture editing or large dataset processing may find the 8GB VRAM limit and 128-bit bus width a constraint over time. The absence of water cooling support means the card is not suited for heavily overclocked or thermally demanding enclosed systems where active liquid cooling would be preferred. Additionally, users who rely on USB-C connectivity for modern displays or VR headsets will find no such output available, making it a poor match for setups that depend on USB-C display or device integration.

Performance:

GPU clock speed	2280 MHz
GPU turbo	2550 MHz
pixel rate	122.4 GPixel/s
floating-point performance	19.58 TFLOPS
texture rate	306 GTexels/s
GPU memory speed	1750 MHz
shading units	3840
texture mapping units (TMUs)	120
render output units (ROPs)	48
Has Double Precision Floating Point (DPFP)	✓

The Performance section of the Gigabyte GeForce RTX 5060 Eagle OC reveals a GPU with a base clock of 2280 MHz and a turbo frequency of 2550 MHz, supported by 3840 shading units, 120 texture mapping units, and 48 render output units. These figures translate into a texture rate of 306 GTexels/s, a pixel rate of 122.4 GPixel/s, and 19.58 TFLOPS of floating-point performance. The GPU memory runs at 1750 MHz, and the card includes support for Double Precision Floating Point, broadening its usability across compute-oriented workloads.

Memory:

effective memory speed	28000 MHz
maximum memory bandwidth	448 GB/s
VRAM	8GB
GDDR version	GDDR7
memory bus width	128-bit
Supports ECC memory	✓

The RTX 5060 Eagle OC is equipped with 8GB of GDDR7 VRAM running across a 128-bit memory bus, with an effective memory speed of 28000 MHz and a peak bandwidth of 448 GB/s. The card also supports ECC memory, which helps detect and correct memory errors in workloads where data integrity is a priority.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	3
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	Intel Resizable BAR
has LHR	✕
has RGB lighting	✕
supported displays	4

The RTX 5060 Eagle OC supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 3, covering a broad range of graphics and compute APIs. It includes ray tracing, DLSS, and stereoscopic 3D support, alongside multi-display technology for up to four simultaneous outputs. Intel Resizable BAR is supported to allow the CPU broader access to GPU memory, while LHR, XeSS, and RGB lighting are not present on this model.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	3
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The RTX 5060 Eagle OC offers a total of four display outputs, consisting of three DisplayPort connectors and one HDMI 2.1b port. There are no USB-C, DVI, or mini DisplayPort outputs on this card.

General info:

GPU architecture	Blackwell
Thermal Design Power (TDP)	145W
PCI Express (PCIe) version	5
semiconductor size	5 nm
number of transistors	21900 million
Has air-water cooling	✕
width	208 mm
height	120 mm

The RTX 5060 Eagle OC is built on the Blackwell architecture, fabricated using a 5 nm process and integrating 21,900 million transistors. It connects via PCIe 5 and carries a thermal design power of 145W. The card measures 208 mm in width and 120 mm in height, and relies solely on air cooling, as water cooling is not supported.

Final Verdict

The Gigabyte GeForce RTX 5060 Eagle OC is a well-defined graphics card that brings together Blackwell architecture, GDDR7 memory, and a full suite of modern API support into a compact, power-efficient package. Its ray tracing and DLSS support, combined with four simultaneous display outputs and ECC memory capability, give it a versatile range of use cases spanning gaming and light compute workloads. The 8GB VRAM and 128-bit bus width do set a ceiling on how far it can scale in more demanding scenarios, and the lack of water cooling or USB-C output narrows its compatibility with certain high-end setups. Overall, the RTX 5060 Eagle OC is a well-rounded option for users who need a compact, feature-complete card with modern capabilities, provided their workloads stay within the bounds of what its memory configuration can comfortably handle.
