Gigabyte Radeon RX 9060 XT Gaming OC 16GB

Name: Gigabyte Radeon RX 9060 XT Gaming OC 16GB
Brand: Gigabyte
SKU: 7838

Manufacturer: Gigabyte

The Gigabyte Radeon RX 9060 XT Gaming OC 16GB is a high-performance graphics card designed for demanding gaming and graphical workloads. It features a base GPU clock speed of 1900 MHz and a turbo boost of 3320 MHz, ensuring smooth and efficient rendering of complex graphics.

Key specifications include 16GB of GDDR6 VRAM with an effective memory speed of 20000 MHz and a maximum memory bandwidth of 322.3 GB/s. The card supports technologies such as DirectX 12 Ultimate, ray tracing, and FSR4, while also offering PCIe 5.0 and a thermal design power of 160W. It is built on RDNA 4.0 architecture with a semiconductor size of 4 nm, providing impressive graphical capabilities for modern applications.

Pros

Supports up to three displays, making it suitable for multi-monitor setups.
Equipped with 16GB of GDDR6 VRAM, providing ample memory for demanding applications.
Supports modern technologies like ray tracing, DirectX 12 Ultimate, and AMD FSR4 for enhanced visual experiences.

Cons

Does not include USB-C, DVI, or mini DisplayPort outputs, limiting connectivity options for some users.
Lacks air-water cooling, which could affect cooling performance under heavy load.
Only has one HDMI port, which may limit connectivity for users needing multiple HDMI connections.

Who is this for?

This product is ideal for users who require a powerful graphics card for demanding gaming or creative applications. With its 16GB of GDDR6 VRAM and support for modern technologies like ray tracing and DirectX 12 Ultimate, it delivers high-quality graphics and performance. It's well-suited for multi-monitor setups, supporting up to three displays, making it a great choice for professionals or enthusiasts who need efficient, high-end graphical processing power for content creation, gaming, or simulation work.

Who is this NOT for?

This product may not be ideal for users with limited connectivity requirements or those who need specific outputs. Its single HDMI port and lack of USB-C, DVI, or mini DisplayPort outputs may be restrictive for users who rely on multiple HDMI connections or need diverse port options for different display setups. Additionally, the absence of air-water cooling may limit its performance during extended heavy loads, making it less suitable for users in environments where sustained, intensive rendering or mining tasks are common.

Performance:

GPU clock speed	1900 MHz
GPU turbo	3320 MHz
pixel rate	212.5 GPixel/s
floating-point performance	27.2 TFLOPS
texture rate	425 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The performance of the Gigabyte Radeon RX 9060 XT Gaming OC is powered by a GPU clock speed of 1900 MHz, which can boost up to 3320 MHz with GPU turbo. It delivers a pixel rate of 212.5 GPixel/s and a texture rate of 425 GTexels/s, ensuring high-quality graphics rendering. The card boasts 27.2 TFLOPS of floating-point performance and operates with a GPU memory speed of 2518 MHz. With 2048 shading units and 128 texture mapping units (TMUs), it is capable of handling complex visual tasks. Additionally, the 64 render output units (ROPs) enhance the overall graphical output, while the support for Double Precision Floating Point (DPFP) ensures precise computations.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	322.3 GB/s
VRAM	16GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The Gigabyte Radeon RX 9060 XT Gaming OC is equipped with 16GB of GDDR6 VRAM, providing ample memory for demanding applications. It operates with an effective memory speed of 20000 MHz and offers a maximum memory bandwidth of 322.3 GB/s, ensuring fast data transfer and seamless performance. The card also features a 128-bit memory bus width and supports ECC memory, enhancing stability and reliability during intensive tasks.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✓
supported displays	3

The Gigabyte Radeon RX 9060 XT Gaming OC offers a range of advanced features for modern gaming. It supports DirectX 12 Ultimate and ray tracing, ensuring immersive graphics and lighting effects. The card is also equipped with support for multi-display technology, making it ideal for multi-monitor setups. With technologies like FSR4 and stereoscopic 3D, it enhances visual quality, while RGB lighting adds an aesthetic touch. Additionally, it supports up to three displays and is compatible with AMD SAM for improved performance.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The Gigabyte Radeon RX 9060 XT Gaming OC offers versatile connectivity options with one HDMI 2.1b port and two DisplayPort outputs. It does not include USB-C, DVI, or mini DisplayPort outputs, but the HDMI port ensures compatibility with modern displays. The card is equipped to support a variety of monitor setups, making it ideal for multi-display configurations.

General info:

GPU architecture	RDNA 4.0
release date	June 2025
Thermal Design Power (TDP)	160W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕
width	281 mm
height	118 mm

The Gigabyte Radeon RX 9060 XT Gaming OC is built on the RDNA 4.0 architecture and features a 4 nm semiconductor size, ensuring advanced performance and efficiency. With a thermal design power (TDP) of 160W, the card is optimized for energy usage, while its PCIe 5.0 support ensures compatibility with the latest motherboards. Measuring 281 mm in width and 118 mm in height, it offers a compact form factor, but lacks air-water cooling capabilities.

Final Verdict

The Gigabyte Radeon RX 9060 XT Gaming OC is a robust graphics card ideal for users seeking high-performance gaming and creative workflows. With its impressive 16GB of GDDR6 VRAM and support for modern technologies like ray tracing and DirectX 12 Ultimate, it delivers a powerful graphical experience. While it offers solid connectivity options and support for multi-display setups, its single HDMI port and lack of USB-C or DVI outputs may limit certain users. Overall, it is an excellent choice for those in need of top-tier performance, but may not be suitable for users requiring extensive display connections or specialized cooling solutions.
