Asus Prime Radeon RX 9060 XT OC Edition 16GB

Name: Asus Prime Radeon RX 9060 XT OC Edition 16GB
Brand: Asus
SKU: 5829

Manufacturer: Asus

The Asus Prime Radeon RX 9060 XT OC Edition is a mid-range graphics card from Asus based on AMD's RDNA 4.0 architecture, fabricated on a 4 nm process with 29,700 million transistors. Designed with a dual-slot form factor measuring 304 mm in length and 126 mm in height, it ships with RGB lighting and a 160W TDP, drawing power through a standard PCIe 5.0 interface. The card carries a boost clock of 3130 MHz, backed by a base GPU clock of 1700 MHz, and delivers 25.64 TFLOPS of floating-point performance alongside a pixel rate of 200.3 GPixel/s.

On the memory side, the card is equipped with 16GB of GDDR6 running across a 128-bit bus at an effective speed of 20,000 MHz, yielding a maximum bandwidth of 322.3 GB/s, with ECC memory support also included. It features 2048 shading units, 128 texture mapping units, and 64 render output units. For display output, the card provides one HDMI 2.1b port and two DisplayPort outputs, supporting up to three simultaneous displays. Feature support includes DirectX 12 Ultimate, OpenGL 4.6, OpenCL 2.2, ray tracing, AMD FSR4, AMD SAM, and stereoscopic 3D, while DLSS and XeSS are not supported.

Pros

The 16GB GDDR6 VRAM allocation is generous for this GPU tier, providing ample headroom for high-resolution textures and memory-intensive workloads
A boost clock of 3130 MHz delivers a notably wide frequency range above the 1700 MHz base, indicating strong dynamic performance scaling
FSR4 upscaling support extends rendering flexibility for compatible titles without relying on third-party solutions
Ray tracing support is included, enabling hardware-accelerated lighting and shadow effects in supported applications
AMD SAM is supported, allowing the CPU to access the full VRAM pool for potentially smoother data throughput in compatible systems
RGB lighting is built into the card, offering visual customization without requiring additional hardware

Cons

The 128-bit memory bus is narrow for a card carrying 16GB of VRAM, which can limit sustained memory throughput in bandwidth-demanding scenarios
DLSS and XeSS upscaling are not supported, restricting upscaling options to AMD FSR4 only
At 304 mm in length, the card requires a sufficiently spacious chassis, which may rule out smaller form factor builds
Water cooling is not supported, leaving air cooling as the only thermal solution regardless of the user's cooling preference

Who is this for?

This card is well-suited for PC builders targeting high-resolution gaming and content creation at 1440p, where the 16GB of GDDR6 VRAM and 25.64 TFLOPS of compute performance provide meaningful headroom for demanding workloads. The inclusion of ray tracing, FSR4, and DirectX 12 Ultimate support makes it a practical fit for users who want access to modern rendering features in compatible titles. Systems built around AMD-compatible platforms will also benefit from AMD SAM, and the PCIe 5.0 interface ensures compatibility with current-generation motherboards without being a bottleneck.

Who is this NOT for?

Users who rely on DLSS or XeSS upscaling within their existing software or game library will find those options unavailable, as neither technology is supported. The 128-bit memory bus, while paired with fast GDDR6, may also be a limiting factor for workloads that demand sustained high bandwidth, making the card less suited for professional GPU compute or data-intensive creative tasks that stress memory throughput continuously. Additionally, builders working with compact or small form factor cases should note the 304 mm card length, which may not fit in tighter enclosures.

Performance:

GPU clock speed	1700 MHz
GPU turbo	3130 MHz
pixel rate	200.3 GPixel/s
floating-point performance	25.64 TFLOPS
texture rate	400.6 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The Asus Prime Radeon RX 9060 XT OC Edition operates at a base GPU clock of 1700 MHz, scaling up to a boost clock of 3130 MHz under load, while the GPU memory runs at 2518 MHz. Floating-point performance is rated at 25.64 TFLOPS, complemented by a texture rate of 400.6 GTexels/s and a pixel rate of 200.3 GPixel/s. The card is built around 2048 shading units, 128 texture mapping units, and 64 render output units, and it includes support for Double Precision Floating Point (DPFP).

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	322.3 GB/s
VRAM	16GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The card features 16GB of GDDR6 VRAM running across a 128-bit memory bus at an effective speed of 20,000 MHz, delivering a maximum memory bandwidth of 322.3 GB/s. ECC memory support is also included, adding a layer of data integrity for workloads that benefit from error correction.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✓
supported displays	3

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of graphics and compute workloads. Ray tracing and stereoscopic 3D are both supported, and AMD FSR4 is available for upscaling, while DLSS and XeSS (XMX) are not supported. Multi-display output is included with support for up to three simultaneous displays, and AMD SAM (Smart Access Memory) is present for optimized CPU-GPU data throughput. The card does not carry LHR (Lite Hash Rate) restrictions, and RGB lighting is built in for visual customization.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and two DisplayPort outputs, providing a total of three display connections. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	160W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕
width	304 mm
height	126 mm

The card is built on AMD's RDNA 4.0 architecture, manufactured using a 4 nm process and incorporating 29,700 million transistors. It connects via PCIe 5.0 and carries a Thermal Design Power (TDP) of 160W, with cooling handled exclusively by air — water cooling is not supported. Physically, the card measures 304 mm in width and 126 mm in height.

Final Verdict

The Asus Prime Radeon RX 9060 XT OC Edition 16GB positions itself as a capable mid-range graphics card built around AMD's RDNA 4.0 architecture, combining a generous VRAM allocation with modern feature support including ray tracing, FSR4, and DirectX 12 Ultimate. Its 16GB of GDDR6 memory stands out as a practical advantage for users running memory-intensive applications or high-resolution gaming, even if the 128-bit bus tempers the overall bandwidth ceiling. While the absence of DLSS and XeSS limits upscaling flexibility, and the 304 mm length calls for careful case planning, the card's overall specification set makes it a well-rounded option for AMD-platform builders seeking a current-generation GPU with a broad feature profile and solid compute throughput.
