XFX Swift Radeon RX 9060 XT OC Gaming Edition 16GB

Manufacturer: XFX

XFX's Swift Radeon RX 9060 XT OC Gaming Edition is a mid-range graphics card built on AMD's RDNA 4.0 architecture, manufactured on a 4 nm process node with 29,700 million transistors. It targets users who want capable modern GPU performance with a reasonable power footprint, and it includes RGB lighting along with support for up to three simultaneous displays through its combination of HDMI and DisplayPort outputs.

Under the hood, the card operates at a base clock of 1900 MHz and reaches a turbo clock of 3320 MHz, delivering 27.2 TFLOPS of floating-point performance alongside a pixel rate of 212.5 GPixel/s and a texture rate of 425 GTexels/s. Its 16GB of GDDR6 memory runs across a 128-bit bus at an effective speed of 20,000 MHz, yielding up to 340 GB/s of bandwidth, while ECC memory support and AMD SAM compatibility are also part of the specification. The card carries a 160W TDP, connects via PCIe 5.0, supports DirectX 12 Ultimate, ray tracing, and AMD FSR4, and is backed by a three-year warranty.

Pros

16GB of GDDR6 VRAM provides a substantial frame buffer for demanding workloads and high-resolution content
Ray tracing support is included, enabling hardware-accelerated lighting effects in compatible applications
AMD FSR4 upscaling is available, offering a way to increase frame output with reduced rendering load
ECC memory support adds data integrity protection, making the card more suitable for compute-adjacent tasks
Supports up to three simultaneous displays via two DisplayPort outputs and one HDMI 2.1b port
A 3-year warranty offers a solid coverage period for a graphics card

Cons

The 128-bit memory bus is relatively narrow for a 16GB card, which can limit memory bandwidth headroom in bandwidth-sensitive scenarios
DLSS is not supported, limiting users to AMD FSR4 as the only hardware-accelerated upscaling option
There are no USB-C or DVI outputs, which reduces compatibility with certain monitors and display adapters
Liquid or hybrid water cooling is not included, leaving thermal management entirely dependent on the air cooler

Who is this for?

This card is a solid fit for users who work across high-resolution gaming or content creation at 1440p, where its 16GB GDDR6 frame buffer and 27.2 TFLOPS of compute throughput provide meaningful headroom. Those who run multi-display setups will appreciate the three-output configuration via HDMI 2.1b and dual DisplayPort connections. The inclusion of ECC memory support also makes it a reasonable choice for users with light compute or data-integrity-sensitive workloads alongside their general GPU tasks, and FSR4 support adds upscaling flexibility for AMD-ecosystem users.

Who is this NOT for?

Users who depend on DLSS for upscaling in their software or game library will find no support for it here, as the card is limited to FSR4. The 128-bit memory bus may also become a bottleneck for workflows that are highly sensitive to sustained memory bandwidth, making the card less appropriate for memory-intensive professional applications at scale. Additionally, those who require USB-C display output or need DVI connectivity for legacy monitor setups will need to look elsewhere, as neither port type is available on this card.

Performance:

GPU clock speed	1900 MHz
GPU turbo	3320 MHz
pixel rate	212.5 GPixel/s
floating-point performance	27.2 TFLOPS
texture rate	425 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The XFX Swift Radeon RX 9060 XT OC Gaming Edition runs at a base GPU clock of 1900 MHz and reaches a turbo clock of 3320 MHz, with its 2048 shading units, 128 texture mapping units, and 64 render output units collectively delivering a texture rate of 425 GTexels/s and a pixel rate of 212.5 GPixel/s. Overall floating-point performance lands at 27.2 TFLOPS, while the GPU memory operates at 2518 MHz. The card also supports Double Precision Floating Point (DPFP), broadening its suitability beyond typical consumer workloads.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	340 GB/s
VRAM	16GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

This card is equipped with 16GB of GDDR6 VRAM running across a 128-bit memory bus, with an effective memory speed of 20,000 MHz that translates into a maximum memory bandwidth of 340 GB/s. ECC memory support is also included, adding a layer of data integrity protection for workloads where memory accuracy is a priority.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✓
supported displays	3

The card supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of modern graphics and compute APIs. Ray tracing and stereoscopic 3D are both supported, and AMD FSR4 is available as the card's upscaling solution — DLSS and XeSS are not supported. Multi-display setups are accommodated with support for up to three displays simultaneously, and AMD SAM (Smart Access Memory) is included to help optimize CPU-to-GPU data throughput. The card does not have LHR restrictions, and RGB lighting is built in for those who want visual customization.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and two DisplayPort outputs, providing a total of three display connections. There are no USB-C, DVI, or mini DisplayPort outputs included.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	160W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
warranty period	3 years
Has air-water cooling	✕
width	270 mm
height	124 mm

Built on the RDNA 4.0 architecture and fabricated on a 4 nm process node, this card packs 29,700 million transistors and connects to the system via PCIe 5.0. It carries a thermal design power of 160W and relies on air cooling, as liquid or hybrid water cooling is not included. The card measures 270 mm in width and 124 mm in height, and it is backed by a 3-year warranty.

Final Verdict

The XFX Swift Radeon RX 9060 XT OC Gaming Edition is a well-rounded graphics card that delivers a clear sense of purpose through its specification set. Built on the RDNA 4.0 architecture with a 4 nm die, it combines a 3320 MHz turbo clock with 16GB of GDDR6 VRAM — a generous allocation that supports high-resolution workloads and gives the card practical longevity for demanding use cases. FSR4, ray tracing, and a three-display output configuration round out a feature set that aligns well with modern AMD-ecosystem users. Its narrower 128-bit memory bus and absence of DLSS or USB-C output do define the card's boundaries, and prospective buyers should weigh those constraints against their specific workflow. Taken as a whole, this is a card that covers the essentials competently and suits users who prioritize VRAM capacity and AMD platform compatibility above all else.
