Apple iPhone 17 Pro Max

The Apple iPhone 17 Pro Max has a footprint of 163.4 × 78 mm with a thickness of 8.75 mm, weighing 233 g and occupying a total volume of 111.5205 cm³. It carries an IP68 ingress protection rating with a waterproof depth of 6 m, classifying it as fully waterproof rather than merely water-resistant. The device is not foldable and does not feature a rugged build. In terms of thermal operation, it is designed to function within a temperature range of 0 °C to 35 °C.

The iPhone 17 Pro Max uses a 6.9″ OLED/AMOLED touchscreen with a resolution of 1320 x 2868 px and a pixel density of 460 ppi, paired with a 120Hz refresh rate and matching 120Hz touch sampling rate. Typical brightness sits at 1000 nits, and the panel achieves a contrast ratio of 2000000:1, supported by HDR10 and Dolby Vision display compatibility, though HDR10+ is not supported. Always-On Display is available, keeping glanceable information visible without fully waking the screen. The display does not use branded damage-resistant glass and there is no secondary screen.

The iPhone 17 Pro Max is powered by the Apple A19 Pro chipset, built on a 3 nm process with 20 billion transistors and a thermal design power of 10W. The CPU runs a 6-thread configuration at 2 x 4.26 GHz and 4 x 2.51 GHz using big.LITTLE architecture with Heterogeneous Multi-Processing, and supports 64-bit processing, NX bit, and TrustZone security. Graphics are handled by the Apple A18 GPU, clocked at 1490 MHz with 128 shading units and integrated graphics support. The chip also integrates LTE directly on the SoC. On the memory side, the device carries 12 GB of DDR5 RAM running at 4800 MHz with a maximum bandwidth of 78.8 GB/s and a 16 MB L2 cache, though ECC memory and multithreading are not supported. Internal storage reaches up to 2048 GB, and benchmark results include an AnTuTu score of 2,885,786, a Geekbench 6 single-core result of 3933, and a multi-core result of 10,223.

The iPhone 17 Pro Max features a multi-lens rear camera system with three 48 MP sensors at apertures of f/1.78, f/2.2, and f/2.8, with pixel sizes of 1.22, 0.7, and 2.8 µm respectively, covering a focal range from 13 mm to 120 mm and offering 8x optical zoom. Each sensor uses a CMOS back-illuminated design, and the system includes optical image stabilization, phase-detection autofocus, laser autofocus, and touch autofocus, with continuous autofocus also available during video recording. Video capture reaches up to 2160p at 120 fps, with support for HDR10 and Dolby Vision recording, as well as slow-motion video. Lighting is handled by a dual-tone, two-LED flash, though an RGB flash is not included. Manual controls cover exposure, ISO, focus, shutter speed, and white balance, and the camera also supports burst mode, HDR, RAW capture, timelapse, and in-camera panoramas, though 360° panorama and 3D recording are not available. The 18 MP front camera sits at an aperture of f/1.9 and is a single-lens unit without an under-display placement or front-facing flash.

The operating system on the iPhone 17 Pro Max includes a broad set of privacy controls, covering clipboard warnings, location privacy options, camera and microphone access management, Mail Privacy Protection, the ability to block app tracking, and cross-site tracking prevention. Notification handling is fully customizable, focus modes are supported, and the system includes a media picker, full-page screenshots, Live Text for selecting text within images, and a child lock. Utility features include dark mode, Wi-Fi password sharing, battery health check, app offloading, widgets, Picture-in-Picture, AirPlay, SharePlay, sharing intents, Quick Start, device tracking, voice commands, and offline voice recognition. On-device machine learning is built in, and the device receives direct OS updates from the vendor. Theme customization, dynamic theming, extra dim mode, split-screen multitasking, and multi-user support are not available, nor can the device be used as a PC or play games while they are downloading. The OS is not free or open source.

The iPhone 17 Pro Max houses a 5088 mAh rechargeable battery with a rated battery life of 39 hours, and includes a battery level indicator. It supports fast wired charging at 40W as well as wireless charging at 30W, though reverse wireless charging is not available. The battery is non-removable, and no charger is included in the box.

The iPhone 17 Pro Max includes stereo speakers and a three-microphone array, but does not have a 3.5 mm headphone jack or a built-in radio. Wireless audio codec support is limited, with no aptX, aptX HD, aptX Adaptive, aptX Lossless, or LDAC available.

The iPhone 17 Pro Max supports 5G connectivity and is compatible with Wi-Fi 4, 5, 6, 6E, and Wi-Fi 7 (802.11be), alongside Bluetooth 6 and NFC. It accommodates one physical SIM and one eSIM, and connects via USB Type-C with USB 3.2, reaching download speeds of up to 10,000 Mbit/s and upload speeds of up to 3,500 Mbit/s. There is no external memory slot, HDMI output, or DLNA certification. The sensor suite includes a gyroscope, accelerometer, barometer, compass, GPS with Galileo support, and an infrared sensor, while 3D facial recognition handles biometric authentication — there is no fingerprint scanner, iris scanner, or heart rate monitor. Safety features include emergency SOS via satellite and crash detection. ANT+, motion tracking, optical tracking, and a built-in projector are not supported, and no stylus is included.

The iPhone 17 Pro Max includes a video light, while the display is flat rather than curved and uses neither sapphire glass nor an e-paper panel.
