PowerColor Reaper Radeon RX 9060 XT 16GB

Name: PowerColor Reaper Radeon RX 9060 XT 16GB
Brand: PowerColor
SKU: 6781

Manufacturer: PowerColor

The PowerColor Reaper Radeon RX 9060 XT 16GB is a graphics card based on AMD's RDNA 4.0 architecture, manufactured using a 4 nm process and housing 29,700 million transistors. It operates at a base clock of 1700 MHz and reaches a boost clock of 3230 MHz, delivering 26.46 TFLOPS of floating-point performance alongside a pixel rate of 206.7 GPixels/s and a texture rate of 413.4 GTexels/s.

On the memory side, the card carries 16GB of GDDR6 across a 128-bit bus, with an effective speed of 20,000 MHz and a maximum bandwidth of 322.3 GB/s, with ECC support included. It supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, and is compatible with ray tracing and AMD FSR4. Connectivity covers up to three displays simultaneously through one HDMI 2.1b port and two DisplayPort outputs, while AMD SAM support is present. The card has a TDP of 160W, measures 220 mm by 120 mm, and connects via PCIe 5.0.

Pros

The 16GB of GDDR6 VRAM provides a generous frame buffer for handling demanding workloads and high-resolution textures
Boost clock reaching 3230 MHz paired with 26.46 TFLOPS of floating-point performance reflects a high computational throughput for this class of card
AMD FSR4 upscaling support offers a practical way to maintain smoother frame rates without relying on native rendering
Ray tracing is supported, enabling hardware-accelerated lighting effects in compatible titles
ECC memory support adds a layer of data reliability useful for compute-oriented tasks alongside gaming
AMD SAM support allows compatible systems to access the full VRAM pool, which can improve frame delivery in supported scenarios

Cons

The 128-bit memory bus is relatively narrow for a 16GB configuration, which limits the scalability of memory bandwidth under heavy loads
DLSS and XeSS upscaling are not supported, restricting upscaling options to AMD FSR4 only
No USB-C video output is available, which may limit compatibility with certain modern monitors and portable displays
Air-water cooling is not included, leaving thermal management entirely dependent on the card's air cooler
RGB lighting is absent, which may matter to users building visually coordinated systems

Who is this for?

This card is well-suited to users who work with high-resolution gaming and GPU compute tasks simultaneously, as the 16GB GDDR6 frame buffer and ECC memory support accommodate both scenarios without requiring separate hardware. The combination of ray tracing support, AMD FSR4 upscaling, and a boost clock of 3230 MHz makes it a reasonable fit for those who want hardware-accelerated visual effects with a fallback to upscaling when needed. Users building a multi-display setup of up to three screens will also find the output configuration practical, and the 160W TDP keeps power draw relatively contained for a card at this performance level.

Who is this NOT for?

Users who rely on DLSS or XeSS upscaling — common in workflows tied to specific game engines or professional applications — will find this card incompatible with those technologies, as neither is supported. The 128-bit memory bus may also present a bottleneck for workloads that push sustained, high-bandwidth data throughput, making this card less suitable for memory-intensive professional compute tasks where bus width has a direct impact on throughput. Additionally, users who require a USB-C video output for connecting modern portable displays or specific professional monitors will need to look elsewhere, as no such port is available on this model.

Performance:

GPU clock speed	1700 MHz
GPU turbo	3230 MHz
pixel rate	206.7 GPixel/s
floating-point performance	26.46 TFLOPS
texture rate	413.4 GTexels/s
GPU memory speed	2518 MHz
shading units	2048
texture mapping units (TMUs)	128
render output units (ROPs)	64
Has Double Precision Floating Point (DPFP)	✓

The Performance section of the PowerColor Reaper Radeon RX 9060 XT 16GB centers on a base GPU clock of 1700 MHz that scales up to a boost clock of 3230 MHz, enabling a floating-point throughput of 26.46 TFLOPS. The card features 2048 shading units, 128 texture mapping units, and 64 render output units, which together yield a pixel rate of 206.7 GPixel/s and a texture rate of 413.4 GTexels/s. GPU memory runs at 2518 MHz, and the card includes support for Double Precision Floating Point (DPFP), adding flexibility for workloads that require higher numerical precision.

Memory:

effective memory speed	20000 MHz
maximum memory bandwidth	322.3 GB/s
VRAM	16GB
GDDR version	GDDR6
memory bus width	128-bit
Supports ECC memory	✓

The card is equipped with 16GB of GDDR6 VRAM running across a 128-bit memory bus, with an effective memory speed of 20,000 MHz and a maximum bandwidth of 322.3 GB/s. ECC memory support is included, which helps maintain data integrity by detecting and correcting memory errors during operation.

Features:

DirectX version	DirectX 12 Ultimate
OpenGL version	4.6
OpenCL version	2.2
Supports multi-display technology	✓
supports ray tracing	✓
Supports 3D	✓
supports DLSS	✕
has FSR4	✓
has XeSS (XMX)	✕
AMD SAM / Intel Resizable BAR	AMD SAM
has LHR	✕
has RGB lighting	✕
supported displays	3

The PowerColor Reaper Radeon RX 9060 XT 16GB supports DirectX 12 Ultimate, OpenGL 4.6, and OpenCL 2.2, covering a broad range of graphics and compute APIs. Ray tracing and stereoscopic 3D are both supported, and AMD FSR4 is available as an upscaling solution; DLSS and XeSS (XMX) are not supported. The card can drive up to three displays simultaneously through its multi-display technology, and AMD SAM (Smart Access Memory) is enabled for compatible system configurations. LHR (Lite Hash Rate) is not present, and the card does not feature RGB lighting.

Ports:

has an HDMI output	✓
HDMI ports	1
HDMI version	HDMI 2.1b
DisplayPort outputs	2
USB-C ports	0
DVI outputs	0
mini DisplayPort outputs	0

The card's output configuration consists of one HDMI 2.1b port and two DisplayPort outputs, providing a total of three video connections. There are no USB-C, DVI, or mini DisplayPort outputs present on this model.

General info:

GPU architecture	RDNA 4.0
Thermal Design Power (TDP)	160W
PCI Express (PCIe) version	5
semiconductor size	4 nm
number of transistors	29700 million
Has air-water cooling	✕
width	220 mm
height	120 mm

Built on the RDNA 4.0 architecture, the card uses a 4 nm manufacturing process and integrates 29,700 million transistors, connecting to the system via a PCIe 5.0 interface. It has a Thermal Design Power of 160W and does not include air-water cooling. Physical dimensions come in at 220 mm wide and 120 mm tall.

Final Verdict

The PowerColor Reaper Radeon RX 9060 XT 16GB is a graphics card that brings together AMD's RDNA 4.0 architecture, a 3230 MHz boost clock, and a notably large 16GB GDDR6 frame buffer within a 160W power envelope — a combination that makes it a practical choice for users who want ray tracing support, FSR4 upscaling, and multi-display capability without excessive power demands. Its 16GB of ECC-capable GDDR6 VRAM is a genuine strength for users who split time between gaming and compute workloads, though those with specific upscaling dependencies or high-bandwidth professional use cases may find certain limitations worth weighing carefully. Overall, the Reaper RX 9060 XT 16GB presents a well-defined feature set grounded in current API support and AMD's latest architecture, making it a focused option for users whose needs align squarely with what it offers.
